LG TONE ACTIVE+ User manual

ESPAÑOLENGLISH
User’s Guide
Bluetooth®Wireless Stereo Headset
Please read the Important Safety Information for the proper use of this product.
After reading, store this User’s Guide in an easily accessible place for all users.
NOTE: Please read all information carefully prior to using the HBS-A100 in order to enjoy
the best performance and prevent damage to the product.
WARNING: This product contains chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm. Call [phone] for more information.
Wash hands after handling.
HBS-A100 www.lg.com
Rev 1.0 US
All rights reserved.
© 2016 LG Electronics Inc.
LG TONE ACTIVE
+™

ENGLISH
ENGLISH
ENGLISH
ENGLISH
Contents
Safety Cautions....................................................................................................................1
HD Speaker.............................................................................................................................2
Qualcomm® aptX™ / Qualcomm® aptX™ HD audio.........................................2
Product Components........................................................................................................2
Product Description ..........................................................................................................3
Replacing the Stabilizer Tips .........................................................................................4
Battery Charging and Alerts .........................................................................................4
HBS-A100 Pairing and Connecting...........................................................................5
Indicator Lamp ......................................................................................................................6
Mobile Calling Functions..................................................................................................7
Playing Music.........................................................................................................................8
Speaker Mode........................................................................................................................8
Vibration Alert Settings...................................................................................................8
Out of Range..........................................................................................................................9
LG Tone & Talk™ ...................................................................................................................9
Tracking Physical Activity.............................................................................................10
Summary of HBS-A100 Functions.........................................................................11
Troubleshooting.................................................................................................................12
Specications and Features........................................................................................13
Declaration of Conrmation.......................................................................................14
Additional Information...................................................................................................15
Limited Warranty..............................................................................................................17
Important Safety Information ...................................................................................18

1
ENGLISH
ENGLISH
ENGLISH
ENGLISH
The LG TONE ACTIVE+(HBS-A100) is a lightweight wireless headset that uses Bluetooth
technology.
This product can be used as an audio accessory for devices supporting either the A2DP or
Hands-Free Bluetooth Prole.
Safety Cautions
Do not disassemble, adjust, or repair the product arbitrarily.
Do not place the product near excessive heat or ammable material.
Do not arbitrarily replace the battery as it may explode.
The product may be damaged if an incompatible recharger is used.
Make sure that any infant or child does not swallow a magnet or a small component of the product.
Make sure that foreign objects do not enter the charger’s connectors (charging port and power plug).
Failing to do so may result in re or electric shock.
For your safety, do not wear the product while it is being charged.
If you have a medical device implanted, contact your doctor before use.
Do not pull the earphone cable with excessive force.
For your safety, do not remove the battery incorporated in the product.
Lithium-ion polymer Battery is hazardous component which can cause injury.
Battery replacement by non-qualied professional can cause damage to your device.
The battery should be recycled or disposed of separately from household waste.
Do not drop the product from a high place.
Make sure there is no alcohol or benzene in contact with the product.
Do not store the product in a wet or dusty place.
Do not place any heavy objects on the product.
Product is sweat and water resistant (IPX4).
It is not waterproof and should not be submerged in water.
If the product is exposed to excessive sweat, clean the product.
Keep the earbud of the earphone always clean.
NOTE
!WARNING
!CAUTION

2
ENGLISH
ENGLISH
HD Speaker
If the communication network of the device you are connecting to supports HD Voice Calling, you
can enjoy making voice calls and listening to music in high denition.
Qualcomm® aptX™ / Qualcomm® aptX™ HD audio
LG HBS-A100 is powered by Qualcomm aptX / Qualcomm aptX HD audio. Qualcomm aptX /
Qualcomm aptX HD audio is Bluetooth wireless technology that provides clearer audio for listening
to music and watching movies.
Qualcomm aptX HD audio supports 24-bit audio, so you can wirelessly enjoy studio-quality sound.
Qualcomm aptX / Qualcomm aptX HD audio is automatically enabled when a mobile phone or audio
device supports it.
Product Components
TONE ACTIVE+
HBS-A100
(Medium ear gels &
standard size stabilizer
tips installed)
Extra Ear Gels
(small & large)
Micro USB Charging
Cable Extra Stabilizer Tips (large)
LG TONE ACTIVE
+
TM
User’s Guide
Bluetooth® Wireless Stereo Headset
ENGLISH
ESPAÑOL
LG TONE ACTIVE
+
TM
Quick Start Guide
Bluetooth® Wireless StereoHeadset
User’s Guide Warranty Card Quick Start Guide
NOTE: Actual product design may differ from images shown in manual.

3
ENGLISH
ENGLISH
Make sure authentic LG Electronics components are used. Using a non-authentic component
may damage the product and thus void the warranty.
!CAUTION
Product Description
OFFON
NOTE: When you control the volume (level 15), you will hear a control sound two times or as a
long sound from volume level 10 and higher.
Indicator lamp
Speaker/
Earphones
mode switch
Power switch
Volume button
Previous/
Next button
Play/Pause/Stop
button
Earbud (right)
Earbud (left)
Stabilizer Tip (right)
Speaker (right)
Speaker (left)
Stabilizer Tip (left)
Charging port
Call button
Microphone
HD Speaker
If the communication network of the device you are connecting to supports HD Voice Calling, you
can enjoy making voice calls and listening to music in high denition.
Qualcomm® aptX™ / Qualcomm® aptX™ HD audio
LG HBS-A100 is powered by Qualcomm aptX / Qualcomm aptX HD audio. Qualcomm aptX /
Qualcomm aptX HD audio is Bluetooth wireless technology that provides clearer audio for listening
to music and watching movies.
Qualcomm aptX HD audio supports 24-bit audio, so you can wirelessly enjoy studio-quality sound.
Qualcomm aptX / Qualcomm aptX HD audio is automatically enabled when a mobile phone or audio
device supports it.
Product Components
TONE ACTIVE+
HBS-A100
(Medium ear gels &
standard size stabilizer
tips installed)
Extra Ear Gels
(small & large)
Micro USB Charging
Cable Extra Stabilizer Tips (large)
LG TONE ACTIVE
+
TM
User’s Guide
Bluetooth® Wireless Stereo Headset
ENGLISH
ESPAÑOL
LG TONE ACTIVE
+
TM
Quick Start Guide
Bluetooth® Wireless StereoHeadset
User’s Guide Warranty Card Quick Start Guide
NOTE: Actual product design may differ from images shown in manual.

4
ENGLISH
ENGLISH
Replacing the Stabilizer Tips
You can replace the current stabilizer tips with the extra pair if they do not t by:
Removing the stabilizer tips
Replacing the stabilizer tips
Battery Charging and Alerts
Open the Charging port cover and connect the charger to the Charging
port.
Indicator Lamp Red Purple Blue
Battery Status Charging 80% Completed
Press and hold the Volume (-) button for 1 second to check the battery level using voice prompts and the
indicator lamp.
Battery Status Sufcient Normal Insufcient
Indicator Lamp Blue ashes three times Purple ashes three times Red ashes three times

5
ENGLISH
ENGLISH
HBS-A100 Pairing and Connecting
If you start the process after putting in your earbuds, you can easily pair and
connect following the voice prompts.
If you hear that the battery is insufcient, recharge the battery before
proceeding with pairing.
If pairing is not completed within 3 minutes, the power automatically turns off.
When the power automatically turns off, slide the Power switch from the OFF
to the ON position to turn the power on.
Connecting Quickly
1 Slide the Power switch toward the ON position to turn on the power.
2 The blue Indicator lamp turns on and the HBS-A100 switches to Search mode.
3 From the mobile phone or device list, select LG HBSA100 to connect.
4 A voice message will indicate that the connection is completed.
5 Use the same process to pair the HBS-A100 with other devices.
Connecting Manually
1 Press and hold the Call button and slide the Power switch to the ON position to turn it on.
2 The blue Indicator lamp turns on and the HBS-A100 switches to Search mode.
3 Select LG HBSA100 from the device list to connect.
Replacing the Stabilizer Tips
You can replace the current stabilizer tips with the extra pair if they do not t by:
Removing the stabilizer tips
Replacing the stabilizer tips
Battery Charging and Alerts
Open the Charging port cover and connect the charger to the Charging
port.
Indicator Lamp Red Purple Blue
Battery Status Charging 80% Completed
Press and hold the Volume (-) button for 1 second to check the battery level using voice prompts and the
indicator lamp.
Battery Status Sufcient Normal Insufcient
Indicator Lamp Blue ashes three times Purple ashes three times Red ashes three times
ON
OFF
ON OFF
ON
OFF
ON OFF
LG HBSA100
Phone
Search for devices
AVAILABLE DEVICES
Allow other Bluetooth devices to nd
my phone
MAKE PHONE VISIBLE

6
ENGLISH
ENGLISH
Multiple Connections
The HBS-A100 can be connected to a mobile phone and a PC simultaneously.
The HBS-A100 can be connected to an additional device while it is already connected to a device.
1 Press and hold the Call button and slide the Power switch to the ON position to turn it on.
2 The blue Indicator lamp turns on and the HBS-A100 switches to Search mode.
3 From the mobile phone or device list, select LG HBSA100 to connect.
4 A voice message will indicate that the connection is completed. This device becomes the
“Main Connected Device.”
5 Try to connect to HBS-A100 using a previously connected device. This device becomes the
“Sub Connected Device.”
NOTE: If simultaneously connected to two devices, the device that was connected most recently is
the “Main Connected Device.”The main functions work based on the “Main Connected Device.”
Automatic Reconnection
If you turn on HBS-A100, it will automatically connect to the most recent (main or peripheral)
device it was connected to. (If a device cannot be found, Search mode will be activated.)
If the product does not automatically connect to the device you want, Search for your product on
the device you want to connect to and connect it manually.
Indicator Lamp
HBS-A100 Status Description
Power On The blue Indicator lamp ashes four times.
Power Off The blue Indicator lamp ashes four times.
Search Mode The blue Indicator lamp is on.
Connected to a device The Indicator lamp will ash blue once every 5 seconds.
LG Health/ LG Tone & Health
Feature On The green Indicator lamp ashes once every 5 seconds.

7
ENGLISH
ENGLISH
Mobile Calling Functions
Functions Description
Receiving a Call/
Hanging Up
Briey press the Call button.
To turn off the vibration alert, briey press the Volume (-) button.
Making a Call
If you make a call using a mobile phone, the call is automatically connected to
the HBS-A100.
For some mobile phones, you should briey press the Play/Pause/Stop button
two times to switch calls.
Redial Press and hold the Call button for more than 1 second to place a call to the last
number you called.
Voice Dial
Briey press the Call button.
If the mobile phone does not support the Voice Dial function, you can use the
Redial function.
Switching Calls
Briey press the Play/Pause/Stop button two times during a call.
(Every time you press one of these buttons, the call switches to the mobile phone
or the HBS-A100.)
Receiving a Call
While on the
Phone
You can receive another call while on the phone by pressing and holding the
Call button for 1 second.
The existing call switches to a call waiting status. Press and hold the Call button
again for 1 second to switch back to the previous call.
Briey press the Call button to hang up in the middle of a call or to hang up
both calls.
(It works differently depending on the mobile phone settings.)
Rejecting a Call Press and hold the Call button for 2 seconds.
Enabling/
Disabling Mute During a call, simultaneously press and hold the Volume (+) button and the Previous ( ) button for 1 second.
CAUTION: Do not disable/enable the Mute function while driving, as you need to use both hands.
NOTE: The Voice Dial and Redial functions work on the Main Connected Device or on the device
on which you made the last call. (The Voice Dial and Redial functions may work differently
depending on the mobile phone being used.)
Multiple Connections
The HBS-A100 can be connected to a mobile phone and a PC simultaneously.
The HBS-A100 can be connected to an additional device while it is already connected to a device.
1 Press and hold the Call button and slide the Power switch to the ON position to turn it on.
2 The blue Indicator lamp turns on and the HBS-A100 switches to Search mode.
3 From the mobile phone or device list, select LG HBSA100 to connect.
4 A voice message will indicate that the connection is completed. This device becomes the
“Main Connected Device.”
5 Try to connect to HBS-A100 using a previously connected device. This device becomes the
“Sub Connected Device.”
NOTE: If simultaneously connected to two devices, the device that was connected most recently is
the “Main Connected Device.”The main functions work based on the “Main Connected Device.”
Automatic Reconnection
If you turn on HBS-A100, it will automatically connect to the most recent (main or peripheral)
device it was connected to. (If a device cannot be found, Search mode will be activated.)
If the product does not automatically connect to the device you want, Search for your product on
the device you want to connect to and connect it manually.
Indicator Lamp
HBS-A100 Status Description
Power On The blue Indicator lamp ashes four times.
Power Off The blue Indicator lamp ashes four times.
Search Mode The blue Indicator lamp is on.
Connected to a device The Indicator lamp will ash blue once every 5 seconds.
LG Health/ LG Tone & Health
Feature On The green Indicator lamp ashes once every 5 seconds.

8
ENGLISH
ENGLISH
Playing Music
Functions Description
Play Briey press the Play/Pause/Stop button.
Music will play from the activated player of the connected device.
Pause Briey press the Play/Pause/Stop button.
Stop Press and hold the Play/Pause/Stop button for 1 second.
Play Previous/Next Song Briey press the Previous ( ) button or the Next ( ) button.
Fast Rewind/Forward Press and hold the Previous ( ) button or the Next ( ) button
until you reach the desired part.
Change Equalizer Mode
Briey press the Play/Pause/Stop button twice. Changes modes with a
beeping sound in the following order:
Bass (default) > Normal > Treble.
(The Equalizer Mode cannot be changed in Speaker Mode.)
NOTE: To switch to a different music playback device when multiple devices are connected, stop
the currently playing music and then play music from the device of your choice.
Speaker Mode
If you slide the Speaker mode switch to the ON position, the
device will enter Speaker mode.
(Only the right speaker will work during a voice call.)
Vibration Alert Settings
Press and hold the Volume (+) button for 2 seconds when the HBS-A100 is not in use
(for playing music, etc.).
If you turn off the vibration alerts, it will not vibrate even when a call is being received or you are
out of communication range.
NOTE: The vibration alert is automatically set to the ON position when you turn on the power.
