LG Tone Infinim HBS900 User manual

English
繁體中文
简体中文
Rev 1.0 TW
All rights reserved.
LG Electronics Inc., 2014
Note: For the best performance and
to prevent any damage to, or misuse of the
HBS-900, please read all of the information
carefully prior to using the HBS-900.
Any modications or changes to this manual due to
typographical errors or inaccuracies of stated information
shall only be made by LG Electronics Inc.
HBS-900 User Manual
Bluetooth®Stereo Headset
ON
OFF
h
a
r
m
a
n
/
k
a
r
d
o
n

2
ENG
Description of parts
Ear Gels (2 Sets) User Manual
USB Charging Cable
Item Description
Bluetooth
®
specication 3.0 (Headset / Hands-Free / A2DP Proles)
Battery Battery 3.7 V / 220 mAh Li-Polymer
Standby time / Talk Time Up to 550 hours / Up to 17 hours
Music play time Up to 14 hours
Charging time Less than 2 hours
Charging rated input DC 4.75 V ~ 5.6 V, 400 mA
Operation temperature -10°C ~ 60°C
Dimension / weight 155 mm (W) x 178 mm (L) x 15 mm (H)/54 g
Package Contents
Specications
ON
OFF
h
a
r
m
a
n
/
k
a
r
d
o
n
FF/REW Switch
Charging Port
Microphone
Earbud (L)
LED Indicator CALL Button
Earbud Wire
Retraction Button
PLAY/PAUSE/STOP
Button
Earbud (R)
ON
OFF
h
a
r
m
a
n
/
k
a
r
d
o
n
Power Switch
Earbud Wire
Retraction Button
VOLUME Switch (+/-)

3
ENG
Power On / Power Off
- Slide the Power switch to the ON or OFF position.
Charging
- When the charger is connected (with the power on or off) the headset will turn off.
- While charging, the LED indicator will show a solid red light and then change to
violet when charged 80% and above.
- When charging is completed, the LED indicator will show a solid blue light.
Low Battery
- An announcement will be made once every 2 minutes.
- If the battery is not charged, the headset will turn off.
Battery Status Alert
- Slide the VOLUME switch to the - position for 1 second.
- There are 3 levels of battery power.
Battery Status High Medium Low
Voice Prompt Battery High Battery Medium Battery Low
LED Indicator
Blinking
Blue
3 times
Blinking
Violet
3 times
Blinking
Red
3 times
- The HBS-900 battery status indicator will appear on the G3 and iPhone screen.
Retractable Earbud Wire
- By pulling the left or right earbuds, the earbud wires can be extended.
- Pressing the Earbud Wire Retraction button winds the earbud wire automatically.
How to Use

4
ENG
How to Use
Pairing
- Before using the headset for the rst time, you must pair it with a Bluetooth-enabled
handset.
- To pair your headset with an additional handset, the headset must be placed in
Pairing Mode.
- There are 2 Pairing Mode Methods with the HBS-900.
Easy Pairing (First Time Pairing)
1. Slide the Power switch to the ON position to turn on the HBS-900. When the
headset enters Pairing Mode, the LED indicator will show a solid blue light.
2. Using your handset, nd the Bluetooth Menu and search for or add new devices.
• Select LG HBS900 from the list of devices and pair it with your handset.
3. If asked for the Pass/PIN code please enter 0000 (4 Zeros).
* Note : If your handset supports Secure Simple Pairing (SSP), you will not need to
enter Pass/PIN code.
• Once pairing has completed successfully, you will hear “Your headset paired.”
• The HBS-900 will automatically turn off if not paired within 3 minutes.
Manual Pairing (Pairing with another phone or re-pairing)
• With the power off, press the CALL button and slide the Power switch to the ON
position at the same time for 2 seconds.
• When the headset enters Pairing Mode, the LED indicator will show a solid blue
light. After the procedure repeat Easy Pairing steps 2 through 3.

5
ENG
Advanced Multipoint
The HBS-900 is capable of having two devices connected to the headset at the
same time. This will give you the freedom of using call waiting between calls on
both of your connected phones.
Connection
- Pair the headset with one of your Bluetooth-enabled handsets (see the pairing
instructions on page 2).
- Turn off the headset.
- With the power off, press the CALL button and slide the Power switch to the ON
position at the same time for 2 seconds to enter Manual Pairing mode.
- Pair and connect the headset with your other Bluetooth-enabled handset. (this
will be your primary handset).
- Once this handset is paired and connected, go back and connect the originally
paired handset to the headset. This will now be your secondary handset.
* NOTE: When the HBS-900 is connected to two handsets at the same time
(Multipoint), the headset calling functions will work with the primary handset.
* NOTE: In case of failure to connect to the primary phone through Easy Pairing,
HBS-900 will enter pairing mode.
Calling Function
- Voice Dialing and Last Number Redial features work with the primary handset (or
handset which made the last outgoing call).
Call Waiting
- While speaking on an active call, press the CALL button for 1 second to switch
to an incoming call.
- To switch between 2 active calls, press the CALL button for 1 second.
- To terminate the active call or both calls at once, briey press the CALL button.
- If both handsets are receiving an incoming call, the headset will default to the
primary device.
Multi-connection
How to Use

6
ENG
- If the HBS-900 is turned off (either accidentally or intentionally) while connected
to a handset, the headset and handset will disconnect. The headset and handset
will automatically reconnect when the HBS-900 is turned back on while in range.
- The secondary handset need to be connected via selecting LG HBS900 from the
list of devices at Bluetooth menu.
Out of range
- If the paired devices are separated by a range of 10 meters(33 feet) or more, the
headset and handset will disconnect and HBS-900 will vibrate to alert.
* If vibrate is set to off by sliding the VOLUME switch to the + position and hold for
2 seconds, HBS-900 will not vibrate.
- If the headset and handset do not automatically reconnect when they are back
within the required range, briey press the CALL button on the HBS-900 to
reconnect manually.
* It is possible to use these functions only when your handset supports them. For
further information about using these features, please consult your handset’s
user manual.
- While in multi-connection and streaming, the inactive paired device, which is
out of range, will be disconnected. The HBS-900 will alert once with no attempt
to reconnect.
How to Use
Auto Reconnect
Answering a call / Ending a call
- When there is an incoming call, the headset will ring and vibrate.
* HBS-900 will not vibrate if vibration function is on ‘off’.
- Briey slide the VOLUME switch to the - position to stop the vibration.
- Briey press the CALL button.
Transferring a call
- While on a call on your handset, press the PLAY/PAUSE/STOP button twice
on the HBS-900 to transfer the audio either from headset to handset or from
handset to headset.
Calling

7
ENG
Voice dialing
- Briey press the CALL button to activate Voice Command.
Note: If the handset does not support Voice Dialing, it is possible that performing
this action will activate Last Number Redial.
Last number redial
- Press and hold the CALL button for 1second to activate Last Number Redial.
The headset will beep, and call the last number dialed.
Call waiting
- Answer a second call without hanging up the rst call by pressing the CALL
button for 1 second (you will hear a beep). Press the CALL button for 1second to
turn to the original call.
- Briey press the CALL button to terminate the active call or both calls at once.
(subject to handset’s support)
Rejecting a Call
- Press the CALL button for 2 seconds when the handset rings.
Mic Mute
- Slide the VOLUME switch to the + position and the FF/REW switch to the
REW position at the same time for 1 second to mute/unmute the Mic during
conversation.
* Precaution : For your safety, do not operate microphone mute during driving.
- Slide the VOLUME switch to the + or - position.
Volume control
Audio streaming controls
- PLAY : Briey press the PLAY/PAUSE button.
- PAUSE : Briey press the PLAY/PAUSE button.
- STOP : Press and hold the PLAY/PAUSE button.
- NEXT SONG : Briey slide the FF/REW switch to the FF position.
- PREVIOUS SONG : Briey slide the FF/REW switch to the REW position.
- FAST FORWARD : Slide and hold the FF/REW switch to the FF position.
- REWIND : Slide and hold the FF/REW switch to the REW position.
How to Use

8
ENG
Equalizer
- While playing music, press the PLAY/PAUSE/STOP button twice to switch between
Bass Boost (default), Normal, and Treble Boost.
- The bass coming from the speakers can vary as a result of the size of the ear gel
that is being used.
aptX®
- The HBS-900 features aptX®technology that ensures audio content transmitted via
Bluetooth is instant and crystal-clear.
- aptX®is automatically enabled as long as the source device supports it.
How to Use
Vibrate Control
- To activate or deactivate the Vibrate function, slide the VOLUME switch to the +
position for 2 seconds. You will hear “Vibrate on” or “Vibrate off” when it is activated
or deactivated.
- When the HBS-900 is set to vibrate off, the headset will not vibrate when receiving an
incoming call or when it is out of range.
- By powering the unit off and then powering the unit back on, the vibration functionality
will be activated.

9
ENG
SMS Reader
The HBS-900 Bluetooth headset supports SMS reading on
AndroidTM based devices.
In Google Play™ search for the LG Tone & TalkTM application
and install it on your device to use this function.
* The QR code shown here helps you download the LG Tone
& TalkTM application from Google Play. Google Play is a
trademark of Google, Inc.
Function Action
Current time alert Slide the FF/REW switch to the FF position for 1 second.
Read latest SMS or MMS Slide the FF/REW switch to the REW position for 1 second.
Direct dial Press the CALL button twice (select Direct dial and set the
telephone number from Speed Dial menu of Tone & Talk
TM
).
Favorite call
1. Press the CALL button twice.
2. Select the name to call by sliding the FF/REW switch
for 1 second.
3. Press the CALL button twice to call (select Favorite call
and set telephone number from the Speed Dial menu of
Tone & Talk
TM
).
Dial using Call History
1. Press the CALL button twice.
2. Select the name to call by sliding the FF/REW switch
for 1 second.
3. Press the CALL button twice to call (select Call history
and set the telephone number from the Speed Dial menu
of Tone & Talk
TM
).
Tone & TalkTM
How to Use

10
ENG
LED Indicator
Issue Possible problem Resolution
Does not
turn on
Check whether the battery of
the HBS-900 is fully charged. Charge the battery.
Unable to
communicate
with the LG
Bluetooth®
Headset
HBS-900
Check whether the handset
supports the headset or
hands-free Bluetooth proles.
Determine whether your
handset supports the headset
or hands-free Bluetooth proles.
Check whether the battery of
the HBS-900 is low.
Charge the battery.
Unable to pair
the HBS-900
with the
Bluetooth®
device
Check and make sure the
headset is on.
Slide the Power switch to the
ON position to turn on the
headset.
Check and make sure the
headset is placed in pairing
mode.
With the power off, press the
CALL button and slide the
Power switch to the ON position
at the same time for 1 second
to place the headset in Manual
Pairing mode.
Low sound
(speaker) Check the speaker volume. lncrease the volume level.
Function HBS-900 Status Action
Operating
Power on The blue LED light ickers 4 times.
Power off
The blue LED light ickers 4 times and then
turns off.
Pairing mode The blue LED light stays on.
Headset / hands-free
prole connected
The blue LED light ickers 1 time every 5
seconds.
Call connected The blue LED light ickers 1 time every 5
seconds.
Charging Charging The red LED light stays on and changes to
violet when charged 80% and above.
Charging complete The blue LED light stays on.
Troubleshooting

11
ENG
Do not drop the unit from high places.
Do not modify, repair, or take apart.
Do not expose directly to water, alcohol, benzene, etc., for cleaning.
Do not expose directly to ammables.
Do not place or keep the unit near ammables.
Keep unit away from humidity & dust.
Do not place heavy objects on the unit.
Only use the headset with an original LG charger, otherwise it may be damaged.
• Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• There is a risk of explosion if the battery is replaced by an incorrect type.
• Dispose of used batteries according to the instructions.
• The neck strap is made of a shape memory alloy. However, bending the neck strap
repeatedly is not recommended.
FCC NOTICE TO USERS :
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE :
To comply with the FCC RF exposure compliance requirements, no change to the
antenna or the device is permitted. Any change to the antenna or the device could result
in the device exceeding the RF exposure requirements and void user’s authority to
operate the device.
CE NOTICE TO USERS :
Hereby, LG Electronics Inc. declares that this HBS-900 is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
FCC ID: BEJHBS900
Precautions
Declaration of Conrmation

12
Additional Information
ENG
1. Radio frequency exposure
This Bluetooth®Stereo Headset HBS-900 is a radio transmitter and receiver. When in
operation, it communicates with a Bluetooth®equipped mobile device by receiving and
transmitting radio frequency (RF) electromagnetic elds (microwaves) in the frequency
range 2.4 to 2.4835 GHz.
Your Bluetooth®Headset is designed to operate in compliance with the RF exposure
guidelines and limits set by national authorities and international health agencies when
used with any compatible LG Electronics mobile phone.
2. Potentially explosive atmosphere
Turn off your electronic device when in any area with a potentially explosive atmosphere.
It is rare, but your electronic device could generate sparks. Sparks in such areas could
cause an explosion or re resulting in bodily injury or even death. Areas with a potentially
explosive atmosphere are often, but not always, clearly marked.
3. Battery information
A rechargeable battery has a long service life if treated properly. A new battery or one that
has not been used for a long period of time could have reduced capacity the rst few times
it is used. Do not expose the battery to extreme temperatures, never above +60°(+140°F)
or below -20°(-4°F). For maximum battery capacity, use the battery in room temperature.
If the battery is used in low temperatures, the battery capacity will be reduced. The battery
can only be charged in temperatures between +10°(+50°F) and +45°(+113°F). For your
safety, do not remove the battery incorperated with the product.
If you need to replace the battery, take it to the nearest authorised LG Electronics service
point or dealer for assistance.
4. Recycling the battery in your Bluetooth®Headset
The battery in your Bluetooth®Headset must be disposed of properly and should never
be placed in municipal waste. The LG Electronics service partner removing battery will
dispose of it according to local regulations.

13
SUBJECT TO THE CONDITIONS OF THIS LIMITED WARRANTY, LG
ELECTRONICS WARRANTS THIS PRODUCT TO BE FREE FROM DEFECTS
IN DESIGN, MATERIAL AND WORKMANSHIP AT THE TIME OF ITS ORIGINAL
PURCHASE BY A CONSUMER, AND FOR A SUBSEQUENT PERIOD OF ONE
(1) YEAR. SHOULD YOUR PRODUCT NEED WARRANTY SERVICE, PLEASE
RETURN IT TO THE DEALER FROM WHOM IT WAS PURCHASED OR CONTACT
YOUR LOCAL LG ELECTRONICS CONTACT CENTER TO GET FURTHER
INFORMATION.
5. Conditions
- The warranty is valid only if the original receipt issued to the original purchaser by the
dealer, specifying the date of purchase and serial number, is presented with the product
to be repaired or replaced. LG Electronics reserves the right to refuse warranty service if
this information has been removed or changed after the original purchase of the product
from the dealer.
- If LG Electronics repairs or replaces the product, the repaired or replaced product
shall be warranted for the remaining time of the original warranty period or for ninety
(90) days from the date of repair, whichever is longer. Repair or replacement may
involve the use of functionally equivalent reconditioned units. Replaced parts or
components will become the property of LG Electronics.
- This Warranty does not cover any failure of the product due to normal wear and
tear, or due to misuse, including but not limited to use in other than the normal and
customary manner, in accordance with instructions for use and maintenance of the
product. Nor does this warranty cover any failure of the product due to accident,
modication or adjustment, acts of God or damage resulting from liquid.
- This warranty does not cover product failures due to improper repair installations,
modications or service performed by a non-LG Electronics authorized person.
Tampering with any of the seals on the product will void the warranty.
Additional Information
Limited Warranty
ENG

14
Important safety information
ENG
Avoiding hearing damage
Permanent hearing loss may occur if you use your Handsfree car kit at a high
volume. Set the volume to a safe level. You can adapt over time to a higher volume of
sound that may sound normal but can be damaging to your hearing.
If you experience ringing in your ears or mufed speech, stop listening and have your
hearing checked. The louder the volume, the less time is required before your hearing
could be affected. Hearing experts suggest that to protect your hearing:
• Limit the amount of time you use Headset at high volume.
• Avoid turning up the volume to block out noisy surroundings.
• Turn the volume down if you can’t hear people speaking near you.
Please refer to your handset user guide for more information on how to adjust
listening levels on your handset.
Using headsets safely
Use of Headset to listen to music while operating a vehicle is not recommended and
is illegal in some areas. Be careful and attentive while driving. Stop using this device
if you nd it disruptive or distracting while operating any type of vehicle or performing
any other activity that requires your full attention.

繁體中文
保留一切權利。
LG Electronics Inc., 2014
備註：為了讓 HBS-900 發揮最佳效能，
並避免損壞或發生不當使用的情況，在使用 HBS-900
之前，請先仔細閱讀本手冊中的所有資訊。
任何因印刷錯誤或資訊不正確
而須對本手冊進行的修改或變更，應由
LG Electronics Inc. 進行。
本手冊的所有資訊若有變更，將不另行通知。
HBS-900 使用手冊
Bluetooth®立體聲耳機
ON
OFF
h
a
r
m
a
n
/
k
a
r
d
o
n

2
繁體中文
各部份說明
耳塞 (2 組) 使用手冊
USB 充電纜線
項目 說明
Bluetooth
®
規格 3.0 (耳機 / 免持裝置 / A2DP 操作模式)
電池 電池 3.7 V / 220 mAh 鋰聚合物電池
待機時間/通話時間 多達 550 小時 / 多達 17 小時
音樂播放時間 多達 14 小時
充電時間 低於 2 小時
額定充電輸入 DC 4.75 V ~ 5.6 V，400 mA
操作溫度 -10°C ~ 60°C
尺寸 / 重量 155 公釐 (寬) x 178 公釐 (長) x 15 公釐 (高)/54 公克
包裝盒內容
規格
ON
OFF
h
a
r
m
a
n
/
k
a
r
d
o
n
[快轉/倒轉] 開關
充電連接埠
麥克風
耳塞 (左)
LED 指示燈 [通話] 按鈕
[耳塞收線] 按鈕
[播放/暫停/停止] 按鈕
耳塞 (右)
ON
OFF
h
a
r
m
a
n
/
k
a
r
d
o
n
電源開關
[耳塞收線] 按鈕
[音量] 開關 (+/-)

3
繁體中文
開機/關機
- 將電源開關滑動至 [ON] 或 [OFF] 位置。
充電中
- 連接充電器時，不論耳機為開機或關機狀態，耳機都會關閉。
- 充電時，LED 指示燈會顯示恆亮的紅燈，然後會在充電至 80% 和更多時變成紫色。
- 充電完成後，LED 指示燈會顯示恆亮的藍燈。
電量不足
- 每 2 分鐘會出現一次通知。
- 若不為電池充電，耳機則會關閉。
電池狀態提示
- 將 [音量] 開關滑動至 [-] 位置 1 秒鐘。
- 電池電量分為 3 個等級。
電池狀態 高 中 低
語音提示 電量充足 電量中等 電量不足
LED 指示燈
閃爍
藍色燈
3 次
閃爍
紫色燈
3 次
閃爍
紅色燈
3 次
- HBS-900 電池狀態指示燈會出現在 G3 和 iPhone 畫面上。
耳塞線可收起
- 拉出左耳塞或右耳塞，就可將耳塞線延長。
- 壓下 [耳塞收線] 按鈕，耳塞線就會自動收起。
如何使用

4
繁體中文
如何使用
配對
- 第一次使用耳機之前，必須先將耳機與已啟用藍牙功能的手機進行配對。
- 若要將耳機與其他手機進行配對，耳機必須處於「配對」模式。
- HBS-900 有 2 種配對模式方法。
簡單配對 (首次配對)
1. 將電源開關滑動至 [ON] 位置，以開啟 HBS-900 的電源。 當耳機進入「配對」模
式，LED 指示燈會顯示恆亮的藍燈。
2. 使用手機找到藍牙功能表，然後搜尋或新增新裝置。
• 從裝置清單選擇 [LG HBS900]，然後將其與手機配對。
3. 如果系統要求 Pass/PIN 碼，請輸入 0000 (4 個零)。
*備註： 如果您的手機支援安全簡易配對 (SSP)，您將不需要輸入 Pass/PIN 碼。
• 配對成功完成後，您會聽到「Your headset paired」(您的耳機已配對)。
• 若未在 3 分鐘內進行配對，HBS-900 就會自動關閉。
手動配對 (與其他手機配對或重新配對)
• 在電源關閉時，按下 [通話] 按鈕並同時將電源開關滑動至 [ON] 位置 2 秒鐘。
• 當耳機進入「配對」模式，LED 指示燈就會顯示恆亮的藍燈。 該程序完成後，
請重複「簡單配對」的步驟 2 到 3。

5
繁體中文
進階多點連接功能
HBS-900 能同時將兩部裝置連線到耳機。 這能讓您在連線的手機上，自由地在通
話之間使用來電等候。
連線
- 將耳機與一個已啟用藍牙功能的手機配對 (請參閱第 2 頁的配對指示)。
- 關閉耳機電源。
- 在電源關閉時，按下 [通話] 按鈕並同時將 [電源] 開關滑動至 [ON] 位置 2 秒鐘，
以進入「手動配對」模式。
- 將耳機與已啟用藍牙功能的另一支手機配對並連線。 (這將會是您的主要手機)。
- 在此手機完成配對與連線後，請回頭將原先配對的手機連線到耳機。 這個現在
會是您的次要手機。
* 注意：HBS-900 同時連線到兩支手機 (多點連接) 時，耳機通話功能是與主要手
機搭配運作。
* 注意：若無法透過「簡單配對」與主要手機連線，HBS-900 就會進入配對模式。
通話功能
- [語音撥號] 與 [重撥最後撥出號碼] 功能是與主要手機 (或最後撥出號碼的手機)
搭配運作。
來電等候
- 通話進行中時，按下 [通話] 按鈕 1 秒鐘即可切換至來電。
- 若要在 2 個進行中通話之間切換，請按下 [通話] 按鈕 1 秒鐘。
- 若要結束目前通話或一次結束兩個通話，請短按 [通話] 按鈕。
- 如果兩支手機同時接到來電，根據預設，耳機將選擇主要手機。
多重連線
如何使用

6
繁體中文
- 如果 HBS-900 在連線到手機時意外或刻意關閉，耳機和手機都會中斷連線。
在範圍內重新開啟 HBS-900 時，耳機和手機都會自動重新連線。
- 必須在藍牙功能表的裝置清單中選擇 [LG HBS900]，才能連接次要手機。
超出範圍
- 配對的裝置之間若距離 10 公尺 (33 英呎) 以上，耳機和手機都會中斷連線，而且
HBS-900 會以震動提示您。
* 若將 [音量] 開關滑動到 [+] 位置並按住 2 秒鐘，使震動設為關閉，那麼 HBS-900
就不會震動。
- 若耳機與手機在回到要求範圍內時，並未自動重新連線，請短按 HBS-900 上的
[通話] 按鈕來手動重新連線。
* 這些功能僅在手機支援時可供使用。 如需使用這些功能的詳細資訊，請參閱手
機的使用手冊。
- 在多重連線與串流模式中，非使用中的配對裝置在涵蓋範圍之外時將會中斷連
線。 HBS-900 會提示您一次，但不會嘗試重新連線。
如何使用
自動重新連線
接聽來電 / 結束通話
- 有來電時，耳機會響鈴並震動。
* 震動功能設定為 [關閉] 時，HBS-900 就不會震動。
- 將音量開關短暫滑動至 [-] 位置，即可停止震動。
- 短按 [通話] 按鈕。
轉接電話
- 在手機上進行通話時，按下 HBS-900 的 [播放/暫停/停止] 按鈕兩次，即可將聲音從
耳機傳輸至手機，或從手機傳輸至耳機。
新進化智慧接聽
- 拿起手機靠近耳朵時，自動選擇以手機接聽電話而非透過藍牙耳機。 (LG G3 適用)
來電身份提示
- 當手機有來電時，即可透過語音通知獲得來電者資訊。 (LG G3 適用)
通話
