30" (30" VIS) WXGA ACTIVE MATRIX TFT COLOR LCD MONITOR/TV
TM
◗Screen Size: 30" Widescreen (15:9)
◗Native Resolution: 1280 x 768 (WXGA)
◗Stereo TV Function and Multi-A/V Capabilities
◗176o/176oUltra Wide Viewing
◗Versatile Picture-In-Picture/Side By Side/Picture Outside Picture
◗S-Video, A/V, Component, DVI, and PC Inputs
◗Detachable Speakers (8W x 2) and Deskstand Included
◗Full Function Remote Control
◗EPA Energy Star and VESA DPMS Compliant
◗RS-232C Control

FLATRON L3020T
FLATRON L3020T
FLATRON L3020T
MW-30LZ10
BACK
LIVE: 1/2”From Trim
TRIM: 8 1/2”x 11”
BLEED: 1/8”All Around
(All Black)
30" (30" VIS) WXGA ACTIVE MATRIX TFT COLOR LCD MONITOR/TV
www.LGusa.com
The LG FLATRON L3020T is a masterpiece of design and engineering.The
impressive 30" WXGA Active Matrix TFT LCD screen provides a sensational display
of any image.With PIP/POP/Dual Windows, S-IPS Wide Viewing Technology,
Multi-A/V Capabilities, a Remote Control and Detachable Speakers - this sleek
30" LCD Monitor/TV is a technological work of art.
©2003 LG Electronics U.S.A., Inc. All trademarks are property of their respective owners. Design and specifications subject to change without notice. 11/03
LG ELECTRONICS U.S.A., INC.
HEADQUARTERS
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 ◗Tel: [phone], Fax: [phone] ◗ www.LGusa.com
Saved: 08/14/2002 09:18 PM
Printed: 08/15/2002 02:05 PM
Document Name: G3071 MW-30LZ10 spec sheet
Fonts: HelveticaNeue LightCond, Eurostile BoldCondensed, Zapf Dingbats, BLI Frutiger BlackItalic, HelveticaNeue Condensed, Eurostile BoldExtendedTwo, HelveticaNeue BoldCond, BL Frutiger Black, R
Frutiger Roman, L Frutiger Light,BI Frutiger BoldItalic, UB Frutiger UltraBlack,Helvetica
Graphics: Digitally, logo with icon#1/eps, LG Group/2000 CIP, MW-30LZ10 greyscale.eps, LG Electronics, MW-30LZ10.eps, gold_bar.eps, blue_bar.eps, red_bar.eps, Glowing Line (Sell Sheet)/EPS,
BW_bar.eps,BW_bar.eps, Glowing Line (B&W)/EPS,GRAY ISO 9001/EPS, 3year quickswap logo.eps,tco B&W logo/eps, ES.clr B&W
Colors: Black, Cyan, Magenta, Yellow
Speakers Included
SCREEN TYPE/SIZE 30" (30"VIS) WXGA Active Matrix TFT Color LCD
DISPLAY AREA 25.3" x 15.2" (643mm x 386mm)
VIDEO Aspect Ratio: 15:9 Pixel Clock: 108Mhz
Contrast Ratio: 400:1 Response Time: 25ms (Typical)
Peak Brightness: 450 cd/m2
Native Display Resolution: 1280 x 768 (WXGA)
Cell Pitch (HxV): 0.5025mm x 0.1675mm x RGB Input Freq. Range: For PC:Autoscanning
Backlighting: 16 CCFL Lamps Hf: 31~66KHz Vf: 56~85Hz
Displayable Colors: 16.77 Million (8 Bit) Surface Treatment: Hard Coating 3H,Anti-Glare
Viewing Angle: 176o/176oÆS-IPS Technology Electronic Interface: LVDS
AUTO-SYNC SUPPORT640 x 350 up to 70Hz, 640 x 480 up to 85Hz, 720 x 400 up to 70Hz, 800 x 600 up to 85Hz,
832 x 624 up to 75Hz, 1024 x 768 up to 75Hz, 1280 x 768 up to 60Hz, 1280 x 1024 up to 60Hz
VIDEO SYSTEM NTSC
INPUT/OUTPUT TERMINALS TV Antenna: F Type Connector
PC Analog: D-Sub 15 (VGA Type)
PC Digital: DVI-I (24 Pin) S-Video: Mini DIN 4-Pin
AUDIO (SPEAKER) OUTPUT: 8 Watts X 2, Push-Type Terminals
DPMS POWER CONSUMPTION On: 145W Max., Standby: < 5W
FRONT PANEL CONTROLS Power,Source,,Menu, Adjust (Left/Right/Up/Down), Auto/Select, Main Power Switch
ON-SCREEN CONTROLS
Sharpness, Color, Tint, Audio (SSM(User/Flat/Movie/Music/Sports)), Auto Volume Leveler, SRS WOW,
28.9" x 21.3" x 7.5" (734mm x 540mm x 190mm) Monitor + Base Only,
40.0" x 21.1" x 7.1" (1016mm x 540mm x 190mm) Monitor + Base + Speakers
SHIPPING DIMENSIONS (WxHxD)33.5" x 26.3" x 11.1" (852mm x 667mm x 283mm) (Without Speakers)
WEIGHT (WITH BASE) 38.8 lbs (17.6 kg) (Without Speakers)
SHIPPING WEIGHT (WITH BASE) 52.2 lbs (23.7 kg) (Without Speakers)
OPERATING TEMPERATURE 50°F~95°F (10°C~35°C)
SAFETY/REGULATORYUL, FCC (Class B), EPA Energy Star, CE, SEMKO, CSA, VCCI-2, CCC, GOST, TUV-GS
ACCESSORIES Remote Control, Power Cord,A/V Cable, PC VGA Cable, PC Audio Cable,
DVI-D 19-Pin Cable, S-VHS Cable, 2 (AAA) Batteries, User's Manual
OTHER FEATURES Advanced Picture in Picture and Side by Side Twin Picture, Picture Out Picture, Image Zoom Function,
RS-232C Control Jack, Closed Caption, V-Chip System, SRS WOW Audio Enhancement Technology,
PRODUCT WARRANTY 3 Year
VESA MOUNTING COMPLIANCE Standard VESA Mounting, 200mm x 100mm Screw Spacing
UPC# 719192176874
MonitorFunction Brightness, Contrast, Color Temp., H/V Position, Tracking (Auto, Clock, Phase), Language,
Image Size, OSD Position, Transparency, Zoom, Information (Elapsed time, Mode), Special (Auto Adjust, OSD
Lock), PIP/POP/PBP (On/Off, Source, Size, Image, Sound, Swap)
AV/TV Function Channel Set-Up, Video (PSM(User/Game/Standard/Dynamic/Mild)), Brightness, Contrast,
HDTV/DVD SUPPORT HDTV:(480i,480p,720p,1080i) DVD: (480i)
PC Audio In: Mini Stereo Phone Jack Head Phone Jack: Mini Phone Jack
A/V In: Phono Jacks
HDTV Component + Audio: Phono Jacks
A/V Out: Phono Jacks
DVD Component + Audio: Phono Jacks
DIMENSIONS (WxHxD) 28.9" x 19.2" x 3.9" (734mm x 487mm x 99mm) Monitor Only,
Jack Panel (on the side)
Auto Volume Leveler, Sleep Function, Bulit-In Audio Amplifier, Matching Speakers, Anti-Theft Lock Port
Sound Select (Mono/Stereo/SAP), Mute, Balance, Bass, Treble, PIP/POP/PBP, Closed Caption & V-Chip
RS-232C Control: 9-Pin D-Sub
POWER REQUIREMENTS 100V~240V,50/60HZ
