LG 17HK700G-WP User manual

Please read this manual carefully before operating your set and retain it for future reference.
17HK700G-W
www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.
OWNER’S MANUAL
Flat Panel Digital X-ray Detector
0197
0123

2
ENGLISH
CONTENTS
OPEN SOURCE SOFTWARE
NOTICE INFORMATION---------------------------------3
ON CLEANING --------------------------------------------3
GENERAL DESCRIPTION -------------------------------3
PART NAME AND FUNCTION--------------------------6
SPECIFICATION AND
DIMENSION OF EACH PART -------------------------10
ENVIRONMENTAL REQUIREMENT----------------- 15
CALIBRATION SOFTWARE INSTALL ---------------15
CONNECTION TYPES ---------------------------------- 16

3
ENGLISH
OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing
such distribution (such as the cost of media, shipping, and handling) upon email request to
opensourc[email protected].
This offer is valid for a period of three years after our last shipment of this product. This offer is valid to anyone
in receipt of this information.
ON CLEANING
Recommended Cleaning Chemicals
•Isopropanol 70%
•Ethanol 70%
•Cidex® OPA
•0.9% NaCl solution
•
How to Use Cleaner
•Prior to cleaning, turn off the detector and remove the power cable.
•Soak a soft cloth in a recommended cleaner, then lightly rub the screen with no more than 1 N of force.
•The cleaner could cause serious damage if it leaks inside the detector while cleaning.
•Do not use benzene, thinner, acids or alkaline cleaners or other such solvents.
•Cleaning guidelines for detector must only be carried out by medical professionals (doctors or nurses) and
must not be handled by patients.
GENERAL DESCRIPTION
Overview
This model is an x-ray imaging device, a system that can acquire and process X-ray images as digital images. It
utilizes amorphous silicon and a high-performance scintillator to ensure sharp high-definition image quality
with the resolution of 3.6 lp/mm and the pixel pitches of 140 um. This device is a flat panel based X-ray image
acquisition device.This device must be used in conjunction with an operating PC and an X-ray Generator. This
device can be used for digitizing and transferring X-ray images for radiological diagnosis.The data transmission
between the detector and PC can be enabled with a wired (cable).
Product Components
•Detector:
•Control Box:
-AC Power Cord for the Control Box
•Cable
-Main Cable: Detector and Control Box link cable (Supply DC power, Ethernet data, control signals of X-ray
Generator)
-Trigger Cable: X-ray Generator to Control Box, transmit control signal between detector and X-ray
Generator. (Optional)
-LAN Cable: Control Box to PC, exchanges Ethernet data between PC and detector. (Optional)
•CD: Owner's Manual,
•Regulatory Manual, Inspection Report

4
ENGLISH
Basic Accessories
100kg
Detector 1 EA Main Cable 1 EA Regulatory Manual 1 EA CD (Owner's Manual / Calibration Software) 1EA
Control Box 1 EA AC Power Cord for the Control Box1 EA Inspection Report 1 EA

5
ENGLISH
Optional Accessories
Trigger Cable 1 EA LAN Cable 1 EA
•Some models may not include additional accessories.
CAUTION
•You must use the authorized components as per the specification below. Unauthorized components may cause damage and/or cause the product to malfunction.
Component Standard
LAN Cable More than CAT5E Standard
Power Cord US – Approved Medical grade regulation
Others – Approved country safety regulation

6
ENGLISH
PART NAME AND FUNCTION
Detector
FRONT BACK
100kg

7
ENGLISH
SIDE
2
1
3
1
Power Button: Power on/off switch
(On: press over 1 Sec, Off: press over 5 Sec)
2
LED Indicator: Indicating detector’s status
3
Connection to Main Cable
LED LED Color Status
Green Data connection
Off Data disconnected
Green Ethernet connection
Off Ethernet disconnected
Green Power On
Off Power Off

8
ENGLISH
Control Box
AC-IN T4L 250V
Ethernet Sync
DXD 1 DXD 2
Power Ethernet Ready Exposure
1
AC-IN T4L 250V
Ethernet Sync
DXD 1 DXD 2
Power Ethernet Ready Exposure
7
5
2 3
6
4
No. LED Indicator LED Color Status
1
Green Power normal operation
Off Power off (AC power cord no connection or Power error)
Green Ethernet normal operation
Green blink On data communication
Off Ethernet disconnected
Green Ready signal from X-ray Generator is active
Off Ready signal from X-ray Generator is inactive
Orange blink Power error
Orange Exposure signal from X-ray Generator is active
Off Exposure signal from X-ray Generator is inactive
Orange blink Power error

9
ENGLISH
No. LED Indicator Status
2
Connecting the Control Box and the Detector A. This connector supply power (24 V 2.1 A) to the Detector, transmits X-ray synchronization signals and Ethernet image data.
3
Connecting the Control Box and the Detector B.This connector supply power (24V 2.1 A) to the Detector, transmits X-ray synchronization signals and Ethernet image data.
Control Box supports 2 Detector connections. Usage is, one is for Bucky stand, the other is for table (bed). Generally, X-ray room of hospital installs 2 Detectors, Bucky stand and
table type, it's far more convenient and efficient working environment. These 2 Detectors are not operated simultaneously, control box selects the operating Detector by AWS
command.
4
Connects AC power cord.
5
Ethernet port to transmit image/command between the Detector and PC.
6
This is to synchronize the Detector and X-ray Generator.
7
Control box power fuses are 4A, 250V toType T fuse.
Power rating:

10
ENGLISH
SPECIFICATION AND DIMENSION OF EACH
PART
Specifications
The product specifications are subject to change without prior notice for product improvements.
~ Refers to alternating current (AC), refers to direct current (DC).
Detector
Category Specifications
Model
Sensor Type Amorphous Silicon TFT
Scintillator Type CsI:TI
Total Pixel Matrix 3072 x 3072 pixels
Total Pixel Area 430.08 mm x 430.08 mm
Pixel Pitch 140 um
Effective Pixel Matrix 3060 x 3060 pixels
A/D Conversion 16 bit
Data transmission Gigabit Ethernet Standard, 500Mbps
Cycle time Typ. 8 sec
Image Transmission Typ. 2 sec
Image Storage Stores up to 200 images
Energy Range 40 kVp ~ 150 kVp
MTF Typ. 89 % at 0.5 lp/mm
DQE Typ. 72 % at 0.1 lp/mm
Size (Width x Height x Depth) 460.0 x 460.0 x 15.6mm
Weight Typ. 3.4 kg
Category Specifications
Window Materials Carbon Fiber
Trigger Mode Manual Mode
Auto Mode (Auto Exposure Detection)
Power Consumption Typ. 19W (For shooting)
Rating 24 V 2.1 A
Applied part Type: BF
Location:The front side of the detector (Effective area only)
NOTE
•Images can be saved by the X-ray generator while the power of the detector is turned on without connecting
to a PC.To produce images, X-ray is irradiated at intervals of more than 10 seconds. Check and load the saved
images from

11
ENGLISH
Detector has been tested with below table’s X-ray condition.This table is only for reference.The legally certified
radiologist expert should control X-ray dose.
•Sensor Type: a-Si TFT, X-ray conditions
Adult
SID (inch / cm) Tube Voltage (KV) Tube Current (mA) Tube Current xTime
(mAs)
Chest P-A 72 inch / 182.8 cm 110 KV 320 mA 3.2 mAs
C-spine LAT 72 inch / 182.8 cm 75 KV 200 mA 20 mAs
L-spine A-P 40 inch / 101.6 cm 70 KV 250 mA 25 mAs
Abdomen A-P 40 inch / 101.6 cm 75 KV 320 mA 20.48 mAs
Pelvic A-P 40 inch / 101.6 cm 70 KV 250 mA 25 mAs
Wrist A-P 40 inch / 101.6 cm 50 KV 250 mA 5 mAs
Elbow A-P 40 inch / 101.6 cm 55 KV 250 mA 5 mAs
Shoulder AP 40 inch / 101.6 cm 65 KV 200 mA 8 mAs
Foot A-P 40 inch / 101.6 cm 50 KV 250 mA 5 mAs
Ankle A-P 40 inch / 101.6 cm 55 KV 100 mA 6.4 mAs
Knee A-P 40 inch / 101.6 cm 60 KV 100 mA 8 mAs
•Sensor Type: Oxide TFT, X-ray conditions
Adult
SID (inch / cm) Tube Voltage (KV) Tube Current (mA) Tube Current xTime
(mAs)
Chest P-A 72 inch / 182.8 cm 110 KV 320 mA 2.56 mAs
C-spine LAT 72 inch / 182.8 cm 75 KV 200 mA 16 mAs
L-spine A-P 40 inch / 101.6 cm 70 KV 250 mA 20 mAs
Abdomen A-P 40 inch / 101.6 cm 75 KV 250 mA 16 mAs
Pelvic A-P 40 inch / 101.6 cm 70 KV 250 mA 20 mAs
Wrist A-P 40 inch / 101.6 cm 50 KV 200 mA 4 mAs
Elbow A-P 40 inch / 101.6 cm 55 KV 200 mA 4 mAs
Shoulder AP 40 inch / 101.6 cm 65 KV 200 mA 6.4 mAs
Foot A-P 40 inch / 101.6 cm 50 KV 200 mA 4 mAs
Ankle A-P 40 inch / 101.6 cm 55 KV 100 mA 4.8 mAs
Knee A-P 40 inch / 101.6 cm 60 KV 100 mA 6.4 mAs
NOTE
•In the case of the Oxide TFT X-ray condition table, it is only applicable to 14HQ901G-B and 17HQ901G-B
models. If the condition table is applied to other models, the desired image may not be obtained.
•Regarding paediatric dosage, it should be much less than for an adult.The certified radiologist should pay
special attention to paediatric X-ray dosage levels.

12
ENGLISH
GRID
Item Recommended Specification
SID 100cm / 130cm / 150cm / 180cm
Size 460 x 460 mm
Ratio 10 : 1
Frequency 215 Line / Inch
Inter Spacer AL
Control Box
Item Specification
Model
Size (Width x Height x Depth) 125.0 x 109.8 x 255.0mm
Weight Typ. 1.3 kg
Input AC 100-240V~ 50/60 Hz, 1.4-0.7A
Output
24 V 2.1A,Trigger signals, Ethernet data for Detector A.
24 V 2.1A,Trigger signals, Ethernet data for Detector B.
Control Box supports 2 Detector connection.
Usage is, one is for Bucky stand, the other is for table (bed).
Generally, X-ray room of hospital installs 2 detectors, Bucky stand and table
type, it's far more convenient and efficient working environment.
These 2 detectors are not operated simultaneously, control box selects the
operating detector by AWS command.
Transmission image/command between the detector and PC.
Transmission control signals between the detector and X-ray Generator.
Cables
Category Length Qty
Main Cable 7 m 1
LAN Cable (Optional) 10 m 1
Power Cord (110 V or 220 V) 1.5 m 1
Trigger Cable (Optional) 15 m 1

13
ENGLISH
Dimension
Detector
Unit: mm
Front Side
100kg
460.0
460.0
100kg
15.6

14
ENGLISH
Control Box
Unit: mm
Front Side
Power Ethernet Ready Exposure
125.0
Power Ethernet Ready Exposure
255
109.8

15
ENGLISH
ENVIRONMENTAL REQUIREMENT
PC System requirement
PC Specification
CPU Intel i5
Memory 4 GB
Disk capacity At least 10 GB ~ 500 GB recommended
Network card Dual Ethernet 100/1000 Mbps
OS Windows 7/8.1/10 (32bit, 64bit)
Monitor Min. Resolution 1280x720
CALIBRATION SOFTWARE INSTALL
How to install
Run the installation file. Once the installation file has been executed, follow the
installation instructions on the screen.
How to delete
You can delete the in the following ways:
Deleting from the Control Panel
1 Select Control Panel from the Start menu.
2 Select Programs and Features in Control Panel.
3 Select the [LG DXD Calibration] on the lists.
4 When the program installation and deletion screen appears on the screen, select the [Delete] button.
5 Follow the deletion instructions on the screen and click the [Next] button to proceed.
Deleting with the installation file
1 Run the installation file, then follow the deletion instructions on the screen.
NOTE
•When using the installation file to delete the program, the Installation file must be the same version as the
current software.

16
ENGLISH
CONNECTION TYPES
Connection of X-ray Generator - Detector
Select Trigger Mode in accordance with the acquisition method.
-Auto Mode: Detector detects the image obtained after the X-ray.
-Manual Mode: Detector acquires image by pressing Generator exposure switch.
Connection of Detector - PC
The connection mode used between the detector and PC.
-Wired Mode:The wired connection between the detector and a PC through the Control Box.
Mode X-ray Generator - Detector Detector - PC
Case 1 Auto Mode Wired Mode
Case 2 Manual Mode Wired Mode

17
ENGLISH
Trigger Cable
•Trigger Cable is connected between control box and X-ray Generator, and used only for manual mode, not auto mode.
AC-IN T4L 250V
Ethernet Sync
DXD 1 DXD 2
Labeling of pins X-ray Generator
NC: No Connection
No. Labeling of pins color Description
1 Red Power: X-ray Generator SupplyVoltage (DC 12V ~24V) Use
2Brown Expose signal from Generator to Control Box Use
3 Blue Cancel REQ Ground NC
4 Orange Prepare Acknowledge signal from Control Box to Generator Use
5 Yellow Expose Acknowledge signal from Control Box to Generator Use
6 Green Prepare signal from Generator to Control Box Use
7 Black Cancel request VCC NC
8Gray Prepare Acknowledge Ground NC
9 Violet Ground of Signals Use
NOTE
•Trigger Cable and X-ray Generator connection is to be performed by qualified personnel. Description of each pin is common language of this industry.

18
ENGLISH
Block diagram of Trigger Cable connection
DC 12-24 V
PREPARE
VCC
EXPOSE
PREP_REQ
EXP_REQ
X-ray Generator Control Box
<Connection of X-ray Generator - Control Box>
VCC
EXPOSE
EXP_ACK
EXP_ACK_COM
Control Box X-ray Generator
<Assembly drawing>

19
ENGLISH
EXP_REQ
EXP_ACK
<Timing Chart>

20
ENGLISH
Detector and PC
Auto Mode Manual Mode
100kg
Detector
Main Cable
Control Box
LAN Cable
X-ray Generator
Interface
X-ray
Generator
X-ray Switch
Object
PC
Power Cord
(AC 100-240 V~)
100kg
Detector
Main Cable
Control Box
LAN Cable
X-ray Generator
Interface
X-ray
Generator
X-ray Switch
Object
Trigger
Cable
PC
Power Cord
(AC 100-240 V~)
