LG LSP-345 User manual

REVISED HISTORY
DATE ISSUE CONTENTS OF CHANGES REMARK
2004/06
2004/08
ISSUE1.0
ISSUE1.1
Initial Release
Cover Design Change

LSP-345LGE CDMA Fixed Wireless Telephone
5
CONTENTS
1GImportant Information.......................................................................9G
Safety Information ...............................................................................................9G
Optimal Phone Performance ...............................................................................9G
Care and Service...............................................................................................10G
Safety Information .............................................................................................11G
2GIntroduction .....................................................................................14G
2.1 G Front View of the Telephone .................................................................... 14 G
2.2 G LCD Display ............................................................................................. 15 G
2.3 G Installation ................................................................................................ 16 G
2.4
G
Installation Steps...................................................................................... 18
G
3GBasic Operation ..............................................................................19G
3.1 G Making a Call ........................................................................................... 19 G
3.2 G Redialing Last Outgoing Number ............................................................. 19 G
3.3 G Receiving a Call ....................................................................................... 20 G
3.4 G Signal Strength......................................................................................... 20 G
3.5 G Missed Call Message ............................................................................... 21 G
4GList of Menu State ...........................................................................22G
4.1 G Volume / Ring........................................................................................... 23 G
4.1.1GRing Volume.................................................................................................23G
4.1.2GKey Volume..................................................................................................23G
4.1.3GEar Volume ..................................................................................................23G
4.1.4GRing Type.....................................................................................................24G
4.2 G Additional Features .................................................................................. 25 G
4.2.1GWake-up.......................................................................................................25G
4.2.1.1GTime..................................................................................................25G
4.2.1.2GRinger ...............................................................................................25G
4.2.2GMinute Alert ..................................................................................................26G
4.2.3GConnect Alert ...............................................................................................26G
4.2.4GRx Call Mode................................................................................................26G
4.2.5GSIO Baud Rate .............................................................................................26G
4.2.6GOwn Number ................................................................................................26G
4.3 G Dial Features............................................................................................ 27 G
4.3.1GHot Line........................................................................................................27G

LSP-345 LGE CDMA Fixed Wireless Telephone
6
4.3.2GHot Line Time...............................................................................................27G
4.3.3GAuto Time-out...............................................................................................27G
4.3.4GSpeed Dial (enable / disable) .......................................................................28G
4.3.5GKey-tone Length...........................................................................................28G
4.4 G Security Features ..................................................................................... 29 G
4.4.1GSet Lock Mode .............................................................................................29G
4.4.2GClear Calls....................................................................................................29G
4.4.3GClear Memory...............................................................................................30G
4.4.4GEmergency Call............................................................................................30G
4.4.5GRestriction Call Service ................................................................................31G
4.4.5.1GRestrict Set .......................................................................................31G
4.4.5.2GPermit Memory .................................................................................32G
4.4.5.3GDeny Memory ...................................................................................33G
5GFunctions while in a call.................................................................34G
5.1 G Ear Volume .............................................................................................. 34 G
5.2 G Mute ......................................................................................................... 34 G
5.3 G Memo ....................................................................................................... 35 G
5.4 G MIC Volume ............................................................................................. 35 G
5.5 G Transmitting your own number................................................................. 36 G
6GSearching, Editing & Dialing..........................................................37G
6.1 G Retrieving Last Call History...................................................................... 37 G
6.2
G
Retrieving Phone Number by Name......................................................... 39
G
6.3
G
Retrieving Phone Number by Address ..................................................... 40
G
6.4 G Retrieving Phone Number by Number...................................................... 41 G
6.5 G Fast Searching ......................................................................................... 42 G
7GSMS (Short Message Service) .......................................................43G
7.1 G Checking & Deleting Received Message ................................................. 43 G
7.1.1GText Message...............................................................................................43G
7.1.2GVoice Message.............................................................................................44G
7.1.3GErasing all Received Message.....................................................................45G
7.2 G MSG Notification Type Select .................................................................. 45 G
7.3
G
Message Sending .................................................................................... 46
G
7.3.1GSending a New Message .............................................................................46G
7.3.2GSending the sent Message or Message after editing the Sent Message .....47G
7.3.3GSending the Received Message or Message after editing the Received
Message.......................................................................................................49G

LSP-345LGE CDMA Fixed Wireless Telephone
7
7.3.4GErasing a Sent Message ..............................................................................50G
7.4 G MSG Ringer ............................................................................................. 51 G
8GOther Functions ..............................................................................52G
8.1 G Redial ....................................................................................................... 52 G
8.2
G
Finding Last Call History .......................................................................... 52
G
8.3 G Hook Switch ............................................................................................. 52 G
8.4 G Flash Key ................................................................................................. 52 G
8.5 G Safe Mode................................................................................................ 52 G
9 Storing Phone Number...................................................................53
9.1 G Storing/Editing Phone Numbers ............................................................... 53 G
9.1.1GStoring Phone Numbers...............................................................................53G
9.1.2GErasing Stored Phone Numbers ..................................................................55G
9.2 G Finding Stored Phone Numbers ............................................................... 56 G
10GSpeaker Phone ................................................................................57G
11GGeneral Information........................................................................57
FCC RF Exposure Information ............................................................59

LSP-345 LGE CDMA Fixed Wireless Telephone
8
Highlights
Congratulations on your purchase of the LSP-345 Fixed Wireless Telephone. This telephone has
been designed to operate on the latest digital mobile communications technology. This
technology has greatly enhanced voice clarity and can provide various advanced features.
The telephone provides:
zCMX 16 Poly Ringer Type, Power on / off, SMS, Alarm Midi Sound
z3-line LCD Display with status indicator
zA choice of 10 ring sounds
zA menu driven interface with prompts for easy operation
zLast Number Redial
zSpeed Dialing with a 99-number memory
zDial tone
zROH (Receiver Off-Hook) tone
zAdjustable Ring Volume
zInternal Back-up Battery Pack
zAC Power Supply
zDipole Antenna
zRJ-45 Data Port for service and repair
zSpeaker phone

LSP-345LGE CDMA Fixed Wireless Telephone
9
1 Important Information
Safety Information
Warning
To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. Do not
use this product near swimming pools or other water bodies.
IMPORTANT
Before installing or operating this product, please read this information.
Optimal Phone Performance
zDo not operate your product when holding the antenna, or when someone is within four
inches (ten centimeters) of the antenna. Holding the antenna affects call quality and may
cause the telephone to operate at a higher power level than needed.
zFor the best call quality, keep the antenna free from obstructions and position the antenna
straight up.
zDo not use the unit with a damaged antenna. Have your antenna replaced by a qualified
technician immediately. Use only a manufacturer-approved antenna. Non-approved
antennas, modifications, or attachments could impair call quality, damage the phone.
zRF energy may affect improperly installed or inadequately shielded personal medical
devices such as pace markers, hospital monitors. Consult the manufacturer of any
personal medical devices to determine if they are adequately shielded from external RF
energy. Turn your terminal OFF in health care facilities when any regulations posted in the
areas instruct you to do so. Hospitals or health care facilities may be using equipment that
could be sensitive to external RF energy.
zIf this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
¾Reorient or relocate the receiving antenna
¾Increase the distance between the radio or television and the telephone.
¾Connect the equipment into an outlet on a circuit different from that to which the
terminal is connected.
¾Consult you Authorized LGE Dealer of an experienced radio/TV technician for help.

LSP-345 LGE CDMA Fixed Wireless Telephone
10
zUse only the battery, antenna and AC power supply provided by LGE. Using any other
type will invalidate the warranty.
zOnly authorized personnel should service the phone and its accessories. Faulty installation
or service can be dangerous and may invalidate the warranty.
zDo not use the unit in designated “no cellular phone use” area.
zAvoid exposure to high temperature or humidity.
zAvoid wetting the unit with any liquids. If the unit gets wet, turn the power off immediately
and remove the backup battery and AC power supply. If the unit is inoperable, then return
to the service agent for service.
zAvoid shock or impact.
zWe recommend you to charge the backup battery before initial use. Backup battery may be
discharged during delivery.
Care and Service
Unplug the telephone from the wall outlet and remove antenna (or disconnect antenna cable)
before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.
If the unit fails for any reason, do not attempt to disassemble; contact the telephone service
provider for assistance.
If any of the following conditions exist, unplug the unit at the wall plug, remove battery, and call
the service provider.
zThe power supply cord is damaged or frayed.
zLiquid has been spilled into the unit.
zThe unit has been exposed to rain or water.
zThe unit has been dropped or damaged.
zThe unit does not work normally by following the operating instructions.

LSP-345LGE CDMA Fixed Wireless Telephone
11
Safety Information
Do not use with car battery. It may cause electric shock, fire, breakdown
or transformation.
For safety use, use only adapter approved by LG.
To all problems arising from not following this guide, LG does not bear
responsibility.
Ex) LSP-345
(LG Power Adapter Source : DC 9.6V / 1A)
Avoid exposure to high temperature or humidity. Avoid wetting the unit
with any liquids. If the unit gets wet, turn the power off immediately and
remove the backup battery and AC power supply.
Keep it dry. Precipitation, humidity, and liquids contain minerals that may
corrode electronic circuits.
Do not use or store it in dusty, dirty areas as this can damage its moving
parts.
Do not store it in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
Do not store it in cold areas. When the phone warms up to its normal
operating temperature, moisture can form inside the phone, which could
damage the phone’s electronic circuit boards.
Do not attempt to open it. Non-expert handling of the device could
damage it. Consult your authorized LG dealer for help. It may cause fire,
electric shock and breakdown.
Do not drop, knock or shake it. Rough handling can break internal circuit
boards.
WARNING

LSP-345 LGE CDMA Fixed Wireless Telephone
12
Do not use harsh chemicals, cleaning solvents, or strong detergents to
clean it. Wipe it with a soft cloth that has been slightly dampened in a mild
soap-and water solution.
Do not paint it. Paint can clog the device’s moving parts and prevent
proper operation.
During lightning, do not touch power plug or phone line. It may cause an
electric shock or death.
Do not install under direct sunlight or on an uneven surface.
Before using plug, check with available power voltage. Inaccurate power
voltage may cause fire and damage.
Ex) LSP-345 Input Voltage : 100-250V.
Do not plug many power cords in outlet. It may cause fire or electric shock.
Do not remodel the power cord or disassemble. If power cord or plug is
impaired, do not use it. It may cause fire or electric shock.
Do not install in an ill-ventilated place. It may cause fire or breakdown.

LSP-345LGE CDMA Fixed Wireless Telephone
13
Do not touch the plug with wet hands. When disconnecting the power
cord of any accessory, grasp and pull the plug, not the cord. It may cause
fire or electric shock.
Do not put heavy things on the power cord. Do not bend power cord too
much. It may cause fire or electric shock.
Do not short-circuit. It may start a fire or may explode causing injury.
Do not throw and impact battery. Do not dispose of batteries by putting
them in fire. It may explode or catch fire by electrolyte.
Use only LG-approved battery or adapter. If not, it may cause explosion or
short. LG does not bear responsibility for the danger.
When you disconnect the power cord of any accessory, grasp and pull the
plug, not the cord. It may cause an adapter breakdown.
WARNING
WARNING

LSP-345 LGE CDMA Fixed Wireless Telephone
14
2 Introduction
2.1 Front View of the Telephone
1) Menu / Softkey 1: Activate MENU state
2) Message : Activate SMS state
3) End : Deactivate a state – No store a value
4) Recall / Softkey 2 : Activate RECALL state / Choose next state
5) Clear(Cancel) : Delete the last digit/dial number(also exit without storing in the MENU state)
6) Redial /Flash : Flash function in the call state / Dial the last dialed number
7) Volume Left (ൖ): Volume୉(also function as a cursor in the edit state)
8) Volume Right (൘): Volumeେ(also function as a cursor in the edit state)
9) Speaker phone
10) Antenna

LSP-345LGE CDMA Fixed Wireless Telephone
15
2.2 LCD Display
The LCD shows icons on the top of the LCD screen.
Different indicator appears based on the phone's operating mode.
RSSI indicator : Indicates the signal strength in the service area.
No service : The phone is not receiving system signal.
In use : Displayed when call is in progress or the phone is in off-hook and dial tone heard.
:Noservice :Inuse
Text message : Displayed when a text message is received.
Voice message : Displayed when a voice message is received.
Alarm : Displayed when wake up alarm time was setting.
Caller ID : Displayed when caller ID is received.
Battery charge level : Indicates charged battery level.

LSP-345 LGE CDMA Fixed Wireless Telephone
16
2.3 Installation
You should follow each step carefully as shown below in order to guarantee proper operation of
CDMA Fixed Wireless Telephone.
STEP I. Check Components
zFixed Wireless Terminal is supplied with the following standard unit and accessories;
1. LSP-345 Main Unit with Handset -1EA-
2. Dipole Antenna -1EA-
3. Backup Battery -1EA-
4. User Guide -1EA-
5. AC/DC Power Adapter -1EA-
6. Power Cord(Only SMPS Adapter) -1EA-
zPlease make sure that these components are present before you begin the unit installation.
And then compare the following figures and components. If components are missing or
damage is found, contact the store where you purchased the unit immediately.
STEP II. Place the Terminal
zPlace the terminal on the stable flat secure surface area (desk, table, etc.). Serious
damage may result if the unit falls. Do not place the unit on, or within 1 meter of heaters or
radiators. This unit is designed for desktop usage. Avoid direct exposure to sunlight and
damp areas.
zRead the SAFETY INFORMATION located at the first part of this document before you
place the terminal.
STEP III. Connect Components (See the figures in “Installation Steps”.)
zConnect the antenna to the TNC antenna connector located at the topside of the terminal.
If you have placed the terminal on a flat surface, position the antenna up right.
zConnect curl cord of handset assembly to the RJ-11 port located at the left side of the
terminal.
zOpen the battery case, securely connect the battery cord, place the backup battery pack
and close the case.
zConnect the AC/DC Adapter cable to the DC input port located at the topside of the
terminal.

LSP-345LGE CDMA Fixed Wireless Telephone
17
¾If it is good, beep tone is heard.
¾If it is not good(Booting fails or beep tone is not heard), you have to connect the
adapter or backup battery, again.
zPlease observe the following matters to get better voice quality;
1. Keep away from electrical appliances such as TV, computer, radio and so on.
2. Keep terminal in a high and central location with no obstructions.
3. Raise the integral antenna of terminal to get maximum strength as shown figure.
STEP IV. Check the LCD Display
zAfter you follow the installation instruction step I to step III, please check the LCD for
normal operation.
zIf you may not see status of service, please repeat the 5th instruction of step III. And
confirm Fixed Wireless Telephone to get the proper signal strength from service operator
system.
ଖThe adapter type(with power cord) may be different from country to country.

LSP-345 LGE CDMA Fixed Wireless Telephone
18
2.4 Installation Steps
Please follow the below procedure to install the unit properly.
Connect Base-
handset to the
handset connector.
Bend the antenna up
right.
Insert back-up
battery in the bottom
of the unit.
(Give care to
polarity)
Connect the
antenna to the TNC
connector (Turn
right).
Open the battery
cover at the bottom
of the unit.
Replace the Battery
cover
When you use
terminal first, please
Turn “on” the battery
switch.
Connect the AC
power supply.
Notice
Before using the terminal, please check battery switch is on.
After switching on it, use the phone.
When charging the battery, check that battery switch is “on”.
Battery is charged only when battery switch is on.

LSP-345LGE CDMA Fixed Wireless Telephone
19
3 Basic Operation
3.1 Making a Call
If user press '୆' button after dialing the number, the terminal make a call immediately.
1. Pick up the handset or press button.
2. Listen for dial tone.
3. Enter the phone number with area code if needed.
4. Wait for the Auto Time-out.
5. The call is connected and you can start conversation.
6. To disconnect the call, replace the handset or press button.
3.2 Redialing Last Outgoing Number
1. Pick up the handset or press button.
2. Listen for dial tone.
3. Press Redial button. The last number that you called will be re-dialed.
1234567
1234567
Calling...

LSP-345 LGE CDMA Fixed Wireless Telephone
20
3.3 Receiving a Call
1. When bell rings, pick up the handset.
2. Start conversation.
3. To disconnect the call, replace the handset.
3.4 Signal Strength
The quality of calls depends on the signal strength in your area.
The stronger the signal, the better the call quality. The signal
strength icon indicates the current strength as a number of bars.
You can see the antenna and bars according to the strength of
received signal in the upper-left part.
zCorrecting dialing mistakes
1. Press Clear button shortly to erase the most recent digit.
2. Press and hold Clear button for at least one second.
zIf the phone is locked, enter the Lock Code
zIf the call did not go through, press the hook switch and dial again.
zFlashing / Hook Switch
1. While in the middle of a call, pressing the hook switch for less than 1 second will be
treated as a flash. After 1 second, the call will be terminated.
2. Very briefly pressing the hook switch will be ignored.
zBattery icon is displayed only when the terminal is operating by battery without AC power.
Incoming Call!
10:23 AM
08 May, Sat
[MENU][RECALL]
Time: 0:23
1234567
[MENU
[MUTE]

LSP-345LGE CDMA Fixed Wireless Telephone
21
3.5 Missed Call Message
If a call is received and not answered for user’s absence, you
are informed that you have missed a call. The latest missed
call time and number of missed call is displayed. Press [OK] to
erase “Missed call” message.
10:51 AM
Missed 1 call
[OK]

LSP-345 LGE CDMA Fixed Wireless Telephone
22
4 List of Menu State
Main Menu Sub-Menu Setting Value Default
1. Ring Volume 4 steps
2. Key Volume 4 steps +silent
3. Ear Volume 4 steps
1. Volume / Ring
4. Ring Type 10 types
1. Time Off / Once / Always
1. Wake-up
2. Ringer ALARM1...ALARM5
2. Minute Alert On/Off
3. Connect Alert On/Off
4. Rx Call Mode
Voice / Fax for next / Always Fax
Modem for next / Always modem
5. SIO Baud Rate
9,600/19,200/38,400/57,600
/115,200/230,400
2. Additional
6. Own Number Display own number
1. Hot Line Off/On
2. Hot Line Time 2-9 Sec.
3. Auto Time-out 2-9 Sec.
4. Speed Dialing Enable/Disable
3. Dial features
5. Key Tone Length Normal/Long
1. Set Lock Mode On/Off
2. Clear Calls No/Yes
3. Clear Memory No/Yes
4. Emergency Call Local(3.ea)
5. Restriction Call Servic
e
5.1 Restrict Set
No restriction/Restriction
/Emergency Only
5.2 Permit Memory Local(10.ea)
4. Security
5.3 Deny Memory Local(10.ea)
