LG MultiVision SPM42C4-WP User manual

Owner's Manual
MultiVision Mounting Bracket
Please read the safety information carefully before using the product.
SPM42C4-WL
SPM42C4-WP
P/NO : MFL63640518 (1207-REV00)

2
Accessories
MultiVision Mounting Bracket-Landscape
SPM42C4-WL
MultiVision Mounting Bracket-Portrait
SPM42C4-WP
MultiVision Mounting Bracket
4 Guide Spacer 4 Guide Spacer Fixing
Screws
(M6X35mm)
4 Bracket Fixing Screws
(M6X80mm)
4 Nuts
Owner's Manual Wrench 4 Supporter Connection
Fixing Screws
(M4X8mm)
Supporter Connection
(SPM42C4-WL Only)

3
ENGLISH
After reading the manual, please keep it handy for future reference.
- If you are a professional installer, please read this manual carefully before installing the product.
- After installing the product according to the manual, ensure that the user also reads the manual carefully.
Safety Precautions
Warning
The product should be installed by a qualified professional
specified by the retail store.
Installing the product without a qualified professional is dangerous and may
cause injury.
The product should be installed where its weight can be
supported.
If the product is installed on a weak surface, the product may fall and cause
injury.
When moving or replacing the product after installation,
contact a qualified installer specified by the retail store.
Installation or movement of the product must be carried out by a skilled
professional. If an unqualified person moves and installs the product, this
may cause safety issues.
Prior to installing the product, arrange the power cable and
signal cable to prevent damage during installation.
Damaged cables may result in a fire, electric shock or damage to the product.
Do not hang on the product or apply shock to the product.
The product may fall and cause injury.
Do not clean the product with wet towels, and do not use a heater or
humidifier underneath the product.
Moisture permeating into the product, including through steam and heat, may
result in a fire, electric shock or damage to the product.
Make sure that the power cord is removed from the outlet before installing
the product.
Otherwise, it may cause an electric shock or a fire.
Keep the product away from sprinklers, sprinkler sensors, high-tension
wires and power sources. Do not install the product in a location where
vibrations or shock impacts are likely to occur.
Wear working gloves when installing the product. Do not use bare hands.
Otherwise, it may cause injury.
Caution
Follow the instructions in the manual to install the product.
If you do not follow the instructions, the product may not be installed properly,
causing serious injury or damage to the product.
To install or adjust the height of the product, two or more people are
needed.
If you try to install or move the product alone, it may fall and cause injury or damage to
the product.
Before installing the product, check whether the wall is strong enough to
hold the product.
Installing the product on a wall that cannot hold its weight may cause safety issues.
When sets are built into a wall, the internal temperature may rise to such an extent that it
causes overheating. To prevent the set from overheating, please follow the instructions
below. Overheating may damage the product and in extreme cause smoke of fire.
Avoid completely sealed installation.
To ensure adequate ventilation, keep the top, the bottom and the sides of the set a
minimum of 20 cm from the wall. (The back of the set should be a minimum of 15 cm
from the wall.)
If there is not enough space, a separate ventilation device is required.
If you install four or more sets on top of one another, you will need to ensure a ventilator is
used. (for example, a forced draft fan.)
20cm
20cm 15cm

4
When moving or lifting the monitor, read the
following to prevent the monitor from being
scratched or damaged and for safe transportation
regardless of its type and size.
 It is recommended to move the monitor in
the box or packing Cover that the monitor
originally came in.
 Before moving or lifting the monitor,
disconnect the power cord and all cables.
 Hold the top and bottom of the monitor frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
 Avoid touching the screen at all times, as this
may result in damage on the screen.
CAUTION
 When transporting the monitor, do not expose
the monitor to jolts or excessive vibration.
 When transporting the monitor, keep the
monitor upright, never turn the monitor on its
side or tilt towards the left or right.
 When transporting the monitor by hand,
hold the monitor as shown in the following
illustration.
 When the product is carried upright, 2 persons
carry by holding the bottom and top of the
front, and when it is being put down, put down
carefully for the panel not to be touched.
 When the product is carried laid down, 2
persons carry by holding the bottom of the
back, and when it is being put down, put down
carefully for the panel not to be touched.
Transportation method for panel protection

5
ENGLISH
<Correct method>
Panel Cushion
If the product needs to be
set upright, hold both sides
of the product, and tilt back-
ward carefully for the panel
not to touch the floor. (The
setting upright of the set is
possible with the outer frame)
When laying down the prod-
uct, lay a cushion on a flat
floor, and put the product on
it with the panel of the prod-
uct facing down.
<Incorrect method>
Panel
Panel
If the product is tilted to the
side of the panel, the bottom
of the panel may be dam-
aged.
If the product is tilted to the
edge of the panel, the edge
of the panel may be dam-
aged.
 Handle the product with care. The product may be damaged by shocks.
NOTE
Storage method for panel protection

6
How to Install
- Attach the brackets using two bracket fixing screws (M6
Assembling the MultiVision Bracket
1
Nut
Before Installation
* Do not use this product for purposes other than to attach the monitor to the wall.
* Be careful when installing and using the bracket to prevent product damage and safety hazards.
* If the instructions in the manual are unclear, stop the installation and contact the service center.
If you are still having problems understanding the instructions after contacting the center, seek a professional to install the product.
* An individual with experience in mechanical and architectural fields may not have any difficulty understanding this manual or installing the product,
even if they are not a professional.
* When installing the bracket on a concrete wall or on any other walls capable of holding the strength specified in the manual, you may detach the
standard gap bracket for stud wall mounting then follow the instructions for attaching the bracket to make the installation easier.
* Only install the bracket on vertical walls. Do not install the bracket on a wall inclined at an angle, exceeding the standard range or on the ceiling.
Salitek is not liable for problems that occur due to the installation of the product on a slanted wall or on the ceiling.
* Check the accessories provided with the product before installing. Salitek is not liable for any damage to or loss of the accessories after the
package has been opened.
* Make sure that the accessories are kept out of reach of children to prevent safety accidents, such as choking due to swallowing small parts.
* Make sure that the screws are fixed tightly. Applying excessive force to screws may impair the performance or reduce the strength of the product, or
cause it to become damaged.
* Make sure that the monitor to be installed does not exceed the specified tension load and that no external force is applied.
* In order to prevent accidents, take care when handling tools during installation of the product.
<Tools for Installation>
Bracket Fixing Screw
The illustration depicts a landscape installation, but the procedure is identical to that of a portrait installation.
Check the direction of the arrows shown in the figure above to avoid placing the bracket upside down.
CAUTION

7
ENGLISH
r
- Join the brackets each other as shown below using the connect supporters and screws.
- When the brackets are attached, unscrew the locking bolts A and B to adjust the sets vertically and horizontally before
mounting them.
A
Locking
bolt for
vertical
adjustment
Locking bolt for
horizontal
adjustment
B

8
MultiVision Wall
Bracket-Landscape
SPM42C4-WL MultiVision Wall Bracket-Portrait
SPM42C4-WP
Refer to the following illustration to fix the brackets according to the type.
2Verifying Where the Brackets Are Fixed
A bolt
The bracket may be distorted, depending on the
flatness of the wall. Adjust the flatness of the bracket
using the A bolts attached to it.
Use abolt that is capable ofholding the weight ofthe product.
We recommend using an bolt & Nut.)
3Attaching the Guide Spacers
If the screws are not fully tightened when you attach the guide spacers, check the length of the screws and refer to the technical
service manual.
<How to attach Guide Spacers>
Attach the guide spacers and the guide spacer fixing screws in the order shown in the picture.
Lay the set down and attach the guide spacers to the set using the screws.
-Place the product on a table with its screen facing downward. Make sure that you place it on soft clothing or a cushion on the flat surface
to protect the screen.
- Tighten the screw until the set, the guide spacer and the screw are joined together securely.
Guide Spacer
4 Guide Spacer Fixing Screws (M6X35mm)

9
ENGLISH
l
5
6
How to Attach the Product and Bracket
Connecting Cables
- Two or more people are needed to install the product.
- It is recommended to arrange cables using the bracket firat to install the set.
- For information on how to connect cables, please refer to the set's owner's manual.
Place the product assembled with the guide spacers, as illustrated with the arrow.
- Make sure that the product is fixed securely by checking attachement.
4Dip switch setting
OFF
ON
1234 1234
1234 1234
1234 1234
monitor #3
1234 1234
monitor #4
1234 1234
monitor #5
1234 1234
monitor #1
monitor #2
Factory reset
RX TX
* There is a switch on the inside cover.
DVI-D
OUT
DVI-D
IN
RGB IN
(SERVICE ONLY)
USB

10
7Set Arrangement
The procedure is based on 3X3 installation.
Set Arrangement step : 8 → 5 → 2, 7 → 4 → 1, 9 → 6 → 3
1. Mount set 8 to the wall mounting bracket as shown below and adjust it vertically and horizontally before fastening A
locking bolts.
* Adjust set 8 vertically within 10 mm.
* This is a bracket with gas spring, so sets can be adjusted vertically with a small force.
8
1
4
7
2
5
8
3
6
9
A
*
Under
10mm

11
ENGLISH
A
2. Mount set 5, then remove the module-protecting Cover on sets 8 and 5.
Insert 4 Guide pins as shown in the figure below.
3. Slowly push down set 5 and insert the guide pins into set 5 as shown below.
* This is a bracket with gas spring, so sets can be adjusted vertically with a small force.
Remove the module-protecting Cover.
(The protective Cover is attached on all four sides; only re-
move first the Cover on the sides where the sets meet.)
CAUTION
 when set 5 is mounted the sets may collide and cause damage.
 Avoid severe impact to the set when adjusting the gap (seam). Otherwise, this can cause damage to the
module glass.
5
8
5
8
<Fine-tuning the gap between the sets>
Rotate the guide pins to fine-tune the
gap between the sets.
Support set 5 with the guide pins
to avoid it going down.

12
- Mount set 2 in the same way as set 5 is mounted.
4. Fix the top set (i.e., set 2 shown below) with the locking bolts so that it does not move vertically.
Remove the module-protecting Cover.
(The protective Cover is attached on all four sides; only
remove first the Cover on the sides where the sets meet.)
2
5
8
9
*
2
5
8
5. Adjust the gap (seam) between sets 8 and 9 by moving set 9 vertically and horizontally. After this, fix set 9 with
the locking bolts so that it does not move vertically.
5
89
A
A

13
ENGLISH
6. After adjusting the gap (seam) as explained above, finish the assembly by sliding the left and right three sets as
shown below.
* To minimize the gap between the joined sets, tighten the left and right sliding locking screws at the bottom of the
wall mounting brackets.
1
4
7
2
5
8
3
6
9

14
How to Service
1
4
7
3
6
9
8
2
5
1. Slide sets 3, 6, 9 to the right and sets 1, 4, 7 to the left. Make sure that the left and right sliding fixing locks are released.
2. Move sets 2 and 5 to the position B as shown below. Move set 8 to the position A and pull it out.
CAUTION
 Make sure that sets 2 and 5 are not pulled out at the position A when moving them to the service position.
3. Mount back set 8 replaced for service and adjust the sets in reverse order.
A
B

15
ENGLISH
Product Specifications
Model Name
SPM42C4-WP
Width (mm)
1426 1426
Height (mm)
210 210
Depth (mm)
1006 1006
Weight
(kg)
Gross
18 17
Net
1111
106
185
79
100
1325.5
749
650
600
400
185
79
100
106
1325.5
749
400
600
650
.
SPM42C4-WL

The model name and serial number are located on
the back and side of the product.
Please make a note of these below.
Model Name
Serial Number
