Life Fitness Elevation 97C-ALLXX-01 User manual

Elevation Upright XXL Bikes
(97C-ALLXX-01)
Customer Support Services
PARTS MANUALrev 30 Jul 2008

2
Miscellaneous ........................................................................................................ 3
Consoles .............................................................................................................. 4
Monocolumn and Console Mounting Bracket.................................................................... 5
Shrouds................................................................................................................ 6
Front Stabilizer and Components................................................................................. 7
Handlebar and Components ....................................................................................... 8
Pedals and Cranks................................................................................................... 9
Seat and Seat Post Components .................................................................................10
Battery, Leg Leveler, and Rear Stabilizer......................................................................11
Generator and Related Components ............................................................................12
Cables..................................................................................................................................... 13
Elevation Upright XXL Bikes 97C-ALLXX-01
Contents S/N ___100000 and up

3
Elevation Upright XXL Bikes 97C-ALLXX-01
Miscellaneous S/N ___100000 and up
Description Part No.
OPERATION MANUAL, CD – (ENG)
0KCD-02001-0000
(For units equipped with 15” LCD
consoles only)+36V POWER SUPPLY
LINE CORD DOM 10A, 125V
LINE CORD CONT 10A, 250V
LINE CORD U.K. 10A
LINE CORD AUSTRALIA
LINE CORD CHINA 10A, 250V
0017-00003-1037
0017-00003-0704
0017-00003-0691
0017-00003-0889
0017-00003-0918
0017-00003-1012
TOUCH-UP PAINT:
SPRAY CAN
.5 OZ BOTTLE W/APPLICATOR
.33 OZ PEN
0017-00008-0204
0017-00008-0205
0017-00008-0206
BRKT ASSY: POWER/COAX INPUT
ASSEMBLY CONSISTS OF:
1) POWER COAX BRACKET
2) F-TYPE PANEL CONNECTOR
3) PHONE JACK RECEPTACLE
AK66-00036-0000
0K66-01063-0000
0017-00021-2846
0017-00021-2847
HARDWARE BAG AK67-00038-0000

4
7-inch Inspire LCD console
15-inch Engage LCD console
Achieve LED console
Elevation Upright XXL Bikes 97C-ALLXX-01
Console Assemblies S/N ___100000 and up
Console Assemblies
Description Part No.
7-INCH LCD BIKE/CT CONSOLE 07DN-ALLXX-01
15-INCH LCD BIKE/CT CONSOLE DOM - NTSC 15DN-ALLXN-01
15-INCH LCD BIKE/CT CONSOLE INT - PAL 15DN-ALLXP-01
LED BIKE/CT CONSOLE - DOMESTIC LEDN-DOMXX-01
LED BIKE/CT CONSOLE - INTERNATIONAL LEDN-INTXX-01

5
Monocolumn
Mounting Screws (3)
2028
Washers (3)
0017-00104-0469
AK67-00055-0000
0017-00101-
Console Mounting Bracket Assembly
Mounting Screws (3)
AK67-00024-0000
0017-00101-1944
Hex Nuts (3)
0017-00103-0341
Upright Gasket
0K67-01039-0000
Elevation Upright XXL Bikes 97C-ALLXX-01
Monocolumn and Console Mounting Bracket S/N ___100000 and up

6
Console Shroud, Top
Mounting Screws (4)
AK67-00019-0000
0017-00101-1796
Console Shroud, Bottom
Mounting Screws (5)
0K67-01041-0000
0017-00101-1796
Right Seat Post
Shroud w/Decal
Left Seat Post
Shroud w/Decal
Mounting Screws
(4 per shroud)
AK67-00050-0000
AK67-00051-0000
0017-00101-1796
Bottom Front Handlebar Cover
Bottom Rear Handlebar Cover
Mounting Screws (3; 2 front, 1 rear)
0K67-01051-0000
0K67-01052-0000
0017-00101-1796
Right Main Shroud
Left Main Shroud
Mounting Screws (5 per shroud)
AK67-00052-0000
AK67-00053-0000
0017-00101-1796
Step Shroud
0K67-01038-0000
Right Front Shroud
Left Front Shroud
Mounting Screws (6)
AK67-00049-0000
0K67-01033-0000
0017-00101-1796
Rear Console Cover
Mounting Screws (4)
Middle Cover
0K67-01040-0000
0017-00101-1940
0K67-01061-0000
0K65-01209-0000
LF Bug
Elevation Upright XXL Bikes 97C-ALLXX-01
Shrouds S/N ___100000 and up

7
Wheels (2)
Wheel Shafts (2)
0K66-01039-0000
0K66-01040-0000
Stabilizer Mounting Screws (3)
0017-00101-1920
Washers (3)
0017-00104-0469
Front Stabilizer End Caps (2)
0K66-01042-0000
Front Stabilizer Shrouds (2)
0K66-01041-0000
Painted Stabilizer
A
K66-00016-0000
Elevation Upright XXL Bikes 97C-ALLXX-01
Front Stabilizer and Components S/N ___100000 and up

8
Heart Rate Cable
AK63-00028-0001
Handlebar Mounting Screws (3)
0017-00101-1920
Handlebar End Cap
0K63-01114-0002
Heart Rate Electrod
e
Insulator Plug
Mounting Screw
AK63-00014-0004
0K66-01141-0000
0017-00101-1720
Handlebar Assembly
AK67-00006-0000
Elevation Upright XXL Bikes 97C-ALLXX-01
Handlebar and Components S/N ___100000 and up

9
Right Crank Arm
Left Crank Arm
Crank Connector Plate
Crank Screw
Crank Cap
0K66-01006-0003
0K66-01006-0004
0K66-01096-0000
0K66-01120-0000
0K66-01121-0000
Right Pedal w/Strap
Left Pedal w/Strap
AK66-00047-0000
AK66-00048-0000
When replacing either
crank arm, the crank
connector plate and
the crank screw must
also be replaced.
Elevation Upright XXL Bikes 97C-ALLXX-01
Pedals and Cranks S/N ___100000 and up

10
Seat
Washers (3)
Mounting Screws (3)
AK67-00028-0000
0017-00104-0469
0017-00101-2007
Seat Post Base Guide
Mounting Screws (2)
0K67-01060-0000
0017-00101-2009
Bumper
0017-00042-1131
Seat Post Guide Cap
0K67-01059-0000
Seat Post Weldment, XXL
AK67-00003-0002
XXL Seat Post Decal
0K67-01089-0000
Up/Down Latch
Up/Down Spring
Latch Pivot Pin
0K67-01009-0000
0K67-01010-0000
0K67-01017-0000
Up/Down Handle
Handle Pivot Pin
E-rings (3)
Up/Down Rod, XXL (not shown)
0K67-01014-0000
0K67-01011-0000
0K67-01062-0000
0017-00100-0250
0K67-01008-0001
Rod Pins (2, not shown)
Seat Post Shroud
Mounting Screws (2)
located under seat:
0K67-01067-0000
0017-00101-2010
Elevation Upright XXL Bikes 97C-ALLXX-01
Seat and Seat Post Components S/N ___100000 and up

11
6V Battery
Battery Mounting Screws (2)
0017-00003-0685
0017-00101-2011
Rear Stabilizer
Leg Levelers (2)
0K66-01131-0000
Rear Stabilizer Mounting Screws (4)
0017-00101-1920
Washers (4)
0017-00104-0469
AK62-00124-0000
Elevation Upright XXL Bikes 97C-ALLXX-01
Battery, Leg Leveler, and Rear Stabilizer S/N ___100000 and up

12
Generator Control
Board Assembly
Mounting Screw
AK66-00100-0001
0017-00101-2011
Generator/Brake Assembly
Mounting Screws (4)
AK66-00002-0000
0017-00101-1920
Washers (4)
0017-00104-0469
Crank Hub/Bearing
Shaft Assembly
Mounting Screws (3)
AK66-00004-0000
0017-00101-1881
Washers (3)
0017-00104-0469
Idler Assembly
AK66-00067-0000
Poly-V Belt
Pulley
Mounting Screws (3)
Washers (3)
0017-00009-0837
0K66-01005-0000
0017-00101-1891
0017-00104-0468
Elevation Upright XXL Bikes 97C-ALLXX-01
Generator and Related Components S/N ___100000 and up

13
'
$
Gen/Brake Cable
A
K67-00107-0000
Battery Cable
AK67-00109-0000
Battery
0017-00003
-
Console/Handlebar Cable Assembly
AK67-00105-0000
PCB to Console Cable
AK67-00106-0001
Ext. Power Cable
AK67-00108-0000
Elevation Upright XXL Bikes 97C-ALLXX-01
Cables S/N ___100000 and up
