Life Fitness Lifecycle C3 User manual

TM
Lifecycle Exercise Bike
ASSEMBLY INSTRUCTIONS

Congratulations...
and welcome to the world of Life Fitness
and the Lifecycle C3 exercise bike.
The following Parts Identification Listing and the step-by-step installation
procedures have been assembled to make the set-up of your exercise bike as
quick and easy as possible.
Please take special note of the following important points prior to choosing a
location and beginning assembly of the Lifecycle exercise bike…

IMPORTANT SAFETY INSTRUCTIONS !
⇒DO NOTlocate the Lifecycle exercise bike outdoors, near swimming pools, or in areas of
high humidity.
⇒DO NOT operate your Lifecycle exercise bike if it has been dropped, damaged, or even
partially immersed in water. Contact Life Fitness Customer Support Services at the number
on the back page of this Installation Instruction Guide.
⇒DO NOTlocate the Lifecycle exercise bike any closer than 30 inches ( 76 cm ) to a television
set.
⇒DO NOTlocate additional Lifecycle exercise bikes any closer than a minimum of 42 inches
( 107 cm ) from center to center to avoid interference (cross talk) between Heart Rate
monitors.
⇒DO keep the area around your Lifecycle exercise bike clear of any obstructions, including
walls and furniture.
⇒DOverify the contents of the delivery carton against the accompanying Parts Listing prior to
setting the cartons and shipping material aside. If any parts are missing, contact Life Fitness
Customer Support Services at the number listed on the back page of this Installation
Instruction Guide. Save the shipping cartons in case of return.
⇒DOread the entire Operation Manual prior to attempting to operate this machine as this is
essential for proper use.

TOOLS REQUIRED FOR ASSEMBLY... Phillips screwdriver, 1/2” wrench
PARTS DESCRIPTION
1STABILIZER/HANDLEBAR BOLT Qty:5
0017-00101-0933
2SEAT WITH SEATPOST ASSEMBLY Qty: 1
AK52-00009-0000
3COLLAR Qty: 1
0K18-01156-0001
4HANDLEBAR ASSEMBLY Qty: 1
AK52-00013-0000
5STABILIZER BAR Qty: 1
AK18-00070-0000
69V ALKALINE BATTERY Qty: 1
0017-00003-0757
1
1” 2”
3”
4”
5”

5
3
1
6
4
1
2
CAUTION: Improper insertion of the seat
pin may result in serious injury. Always
make sure the pin is properly engaged in
the seat post hole prior to using the
Lifecycle exercise bike

1. Before proceeding, familiarize yourself with the parts of the Lifecycle
exercise bike and make sure that you have received all the items
described in the Parts List.
2. Remove the STABILIZER BAR (#5) from the carton base. Remove the
two BOLTS (#1) from the bottom of the SHIPPING STABILIZER (A),
save the BOLTS and store the SHIPPING STABILIZER with the other
shipping containers.
3. Use the same two BOLTS (#1) that held the SHIPPING STABILIZER
(A) in place to attach the STABILIZER BAR (#5) as shown. Make
certain that the BOLTS are tight and the STABILIZER BAR is flush
against the frame.
4. Unfold the CONSOLE WIRE HARNESS (B) from the POST extending
from the FRAME.
NOTE: THE COLLAR (#3) SHOULD ALREADY BE IN PLACE
INSTALLED ON THE HANDLEBAR ASSEMBLY (#4). IF NOT,
INSTALL BEFORE PROCEEDING.
5. Place the HANDLEBAR ASSEMBLY (#4) on the floor in front of the
FRAME with the two CONNECTORS (8P) next to each other. Align
the two CONNECTORS and push them together until they firmly snap
into place.
6. Position the HANDLEBAR ASSEMBLY (#4), with the COLLAR (#3) in
place, so that the HANDLEBAR is facing away from the user. Slide
the HANDLEBAR ASSEMBLY into the HANDLEBAR POST. Be
careful not to pinch the wires.
Align the three holes in the HANDLEBAR ASSEMBLY (#4), with those
in the HANDLEBAR POST and install the three HANDLEBAR BOLTS
(#1).
NOTE: BE CAREFUL NOT TO DAMAGE THE WIRES WHEN
PASSING THE BOLTS THROUGH THE HOLES. TIGHTEN THE
BOLTS SECURELY.
7. Slide the COLLAR (#3) down until it completely covers the
HANDLEBAR ASSEMBLY HARDWARE and the HANDLEBAR
POST. Secure the COLLAR by squeezing the sides and pushing
downward firmly.
5
A
B
1
8P
1
4
4
3

8. Press down on the two tabs on the top of the battery door located on
the back of the DISPLAY CONSOLE.(C) While the two tabs are
depressed, pull the BATTERY DOOR (D) away from the DISPLAY
CONSOLE.
Gently pull the BATTERY WIRES (E) from the back of the DISPLAY
CONSOLE and connect them to the 9-VOLT ALKALINE BATTERY
(#6). Carefully, tuck the BATTERY WIRES back into the DISPLAY
CONSOLE and set the BATTERY in place.
NOTE: ONLY USE AN ALKALINE TYPE BATTERY.
USE OF ANY OTHER TYPE BATTERY MAY RESULT
IN A MALFUNCTION OR DAMAGE.
Re-install the BATTERY DOOR by inserting the two bottom tabs of the
BATTERY DOOR into the corresponding slots in the DISPLAY
CONSOLE. Swing the BATTERY DOOR up and into place and press
each tab separately until they are locked into place.
9. After placing the Lifecycle exercise bike in the intended location for
use, check the stability of the bike.
If the bike is not level, rotate the FOOT in the STABILIZER BAR that
appears to be higher until the Lifecycle is level.
Secure the position of the FOOT by tightening the LOCKNUT with the
enclosed wrench.
6
E
D
C
FOOT

PRE-OPERATION CHECKLIST
4Insure that the STABILIZER BAR and HANDLEBAR BOLTS are tight.
4Make sure theexercise bike is properly leveled and stable.
4Confirm the display console is set to English or metric units.
(See Optional Settings ENG/MET in Operation Manual.)
4Read the entire Operation Manual before using the exercise bike.
Before attempting to operate your Lifecycle recumbent exercise bike, it is imperative that you familiarize yourself with
the contents of the Operation Manual. If your recumbent exercise bike does not respond as described in the
OPERATION MANUAL contact:
Life Fitness Consumer Division
14150 Sunfish Lake Blvd.
Ramsey Minnesota, 55303
U.S.A
612.323.4500• FAX: [phone]
800.328.9714 (Toll-free within the U.S. and Canada)
Prior to your call, please be sure you have located and noted the
MODEL NUMBER & SERIAL NUMBER.
The Model & Serial number information of your Life Fitness recumbent exercise bike is contained in a label located
under the center of the front stabilizer bar (See previous page).
Copyright 2000 Brunswick Corporation. All rights reserved. Life Fitness, Lifecycle and Lifepulse are registered trademarks of Brunswick
Corporation. Any use of these trademarks, without the express written consent of Brunswick Corporation is forbidden.

M051-00K20-A207
04/00
