Life Fitness UPRIGHT LIFECYCLE 95C Installation and operating instructions

The following information replaces Section 1.2, Set Up, Check for External Power, in the 97C, 95C, Upright Lifecycle
Exercise Bike Base Operation Manual.
Check for External Power
The Engage™(15” LCD) Console that is serial coded “DLB” can receive both analog and digital signals. Life Fitness
is not responsible for the installation of CATV service or components required for the delivery of CATV service. An
external TV signal input via a 75-ohm coaxial cable must be present before TV setup can occur.
The Engage Console that is serial coded “DLB” for U.S. markets is powered by two external power supplies: a 36-
volt DC power supply and a 12-volt DC power supply. “DLB” coded units have a Digital TV Tuner
(NTSC/ATSC/QAM). Note: The Engage Console that is serial coded “ANN & ANP” for non-U.S. markets will continue
to use a single 36-volt DC power supply. “ANN & ANP” coded units have an Analog TV Tuner (NTSC).
The 36-volt power supply is optional for the Inspire™(7” LCD) and Achieve™consoles. If a 17” Attachable TV is used
with the Inspire or Achieve consoles, then a 12-volt DC power supply is needed for the 17” Attachable TV.
Product Configuration External Power Supply
Engage Console (“DLB”) 36
V and 12 V
Engage Console (“ANN” & “ANP”) 36 V
Inspire or Achieve Console 36 V (optional)*
Inspire or Achieve Consoles with 17” Attachable TV 36 V (optional)* and 12 V
*Self-Powered
Recommended Installation of External Power Supplies:
Piggyback both external power supplies using the included cable ties.
Remove the protective liner from one of the provided fastener strips.
Attach the fastener strips to the bottom of one of the power supplies.
Remove the remaining protective liner from fastener strip.
Secure the piggybacked power supplies to the underside of the center frame
as shown.
Plug connectors to appropriate receptacles.
Plug Y-Cord into an AC outlet.
For external powered units, the console should immediately beep and light up.
The Engage console will show a message indicating it is initializing (for up to 2
minutes). Note: If any of the consoles do not light up, contact Life Fitness
Customer Service at 800-351-3737.
The following connection receptacles
are located at the front of the Upright
Lifecycle Exercise Bike:
A. 12-V Power for Attachable
TV or Engage Console
(“DLB”)
B. Broadcast Supply Input
Coaxial Cable
C. 36-V External Power
D. Fitness Networking
Addendum: 97C, 95C Upright LifecycleExercise Bike Base Operation Manual
M051-00K88-A001 Date: 12/09
Note to the CATV Installer:
This reminder is provided to
call the CATV system
installer’s attention to Article
820-40 of the NEC that
provides guidelines for proper
grounding and, in particular,
specifies that the cable
ground shall be connected to
the grounding system of the
building as close to the point
of cable entry as practical.
CAUTION: Connectors
should easily fit into the
receptacles. Forcing a connection
may lead to damage to the barrel
connector and/or receptacle and
may void product warranty.
B
D
A
C
36 V
12 V
To AC Outlet
To Fitness
Networking
A
C
D
To Broadcast
Supply Input
Coaxial Cable
B
