Life Fitness Seated Row User manual

Seated Row
Assembly Instructions

Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Qty
1
2
1
9
41
1
1
1
4
13
1
6
2
1
1
1
1
1
2
2
3
Tools Required:
O17mm Wrench
OMetric Allen Wrench Set
ORatchet with 17mm Socket
ORubber Mallet
ORatchet Extension
Description
Pulley
Pulley Guard
Tower Support
M10 x 45mm Bolt
3/8” Flat Washer
Bottom Brace
Center Frame
Tower
M10 x 130mm Bolt
M10 Nylock Nut
Seat Frame
M10 x 90mm Bolt
M10 x 70mm Bolt
Right Handle
Workarm
Left Handle
Long Spacer
Pivot Shaft
Bearing
Short Spacer
M10 x 25mm Bolt
Part Number
3237801
79794XX
80385XX
3251706
3102514
80004XX
80187XX
79854XX
3251720
3242002
80188XX
3251715
3251711
80191XX
80189XX
80190XX
7330008
7316506
3235601
7330001
3251702
Seated Row
Assembly Instructions
Item
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
Qty
1
1
1
1
1
4
1
1
2
1
1
1
1
1
1
2
1
4
3
6
1
Description
Output Cam
Output Plate
Output Ring
Rear Shroud
Front Shroud
M10 x 20mm Bolt
Plate
Seat Pad
M10 x 35mm Bolt
M10 Hex Jam Nut
Cable
Rod End Bearing
M10 x 40mm Bolt
Spacer
Cable Retaining Plate
M8 Hex Jam Nut
Output Cam Cover Plate
Leveling Shim
7/16” Hole Plug
1” Hole Plug
Multi-language Label
Part Number
7998501
7998495
7998895
8024807
8024707
3251701
7322301
74689XX
3251704
3236901
7999601
3237901
3251705
7489402
8001801
3247502
7998995
7893101
3237401
3237403
8047101

Seated Row
Assembly Instructions
1. Assemble the PULLEY (1) and two PULLEY GUARDS (2) to the TOWER
SUPPORT (3) using one M10 X 45mm BOLTS (4) and one 3/8" SAE
WASHER (5) as shown. Tighten the BOLT securely.
2. LOOSELY assemble the BOTTOM BRACE (6) and CENTER FRAME (7) to
the TOWER (8) using four M10 X 130mm BOLTS (9), eight 3/8" SAE
WASHERS (5) and four M10 NYLOCK NUTS (10) as shown.
3. LOOSELY assemble the SEAT FRAME (11) to the BOTTOM BRACE (6)
and CENTER FRAME (7) using four M10 X 90mm BOLTS (12), eight 3/8"
SAE WASHERS (5) and four M10 NYLOCK NUTS (10) as shown.
4. LOOSELY assemble the TOWER SUPPORT (3) to the CENTER FRAME (7)
and TOWER (8) using two M10 X 90mm BOLTS (12), four 3/8" SAE
WASHERS (5) and two M10 NYLOCK NUTS (10) at the CENTER FRAME
and two M10 X 70mm BOLTS (13), four 3/8" SAE WASHERS (5) and two
M10 NYLOCK NUTS (10) at the TOWER as shown.
5. Tighten all BOLTS and NUTS securely.
6. Install the RIGHT HANDLE (14) over the right end of the HANDLE SHAFT
of the WORKARM (15) as shown and secure it using one M10 x 45mm
BOLT (4). Repeat for the LEFT HANDLE (16).
7. Slide the LONG SPACER (17), PIVOT SHAFT (18), two BEARINGS (19)
and SHORT SPACERS (20) into the BEARING HOUSING (A) of the
WORKARM (15).
Insert the WORKARM between the mounting plates of the CENTER
FRAME (7) and secure it with two M10 X 25mm BOLTS (21) and two 3/8"
SAE WASHERS (5).

8. Assemble the OUTPUT CAM (22), OUTPUT PLATE (23), and OUTPUT
RING (24) using three M10 X 45mm BOLTS (4) and three 3/8" SAE
WASHERS (5) as shown. Tighten the BOLTS securely.
9. Assemble the REAR SHROUD (25) and FRONT SHROUD (26) to the
TOWER (8) using four M10 X 20mm BOLTS (27), four 3/8" SAE WASH-
ERS (5) as shown. Be sure all tabs along the sides and top of the
SHROUDS are fully engaged in the slots located inside the TOWER.
Tighten the BOLTS securely. Do not overtighten the BOLTS.
10. Secure the OUTPUT CAM ASSEMBLY (B) to the TOWER HUB (C) using
one M10 X 25mm BOLTS (21), one 3/8" SAE WASHERS (5) and one
PLATE (28) as shown. Tighten the BOLT securely.
IMPORTANT: Be sure the OUTPUT CAM ASSEMBLY is oriented as
shown before securing it to the TOWER HUB.

11. Attach the SEAT PAD (29) to the SEAT FRAME (11) using two M10 X
35mm BOLTS (30) and two 3/8" SAE WASHERS (5) as shown. Tighten
the BOLT securely.
Seated Row
Assembly Instructions

NOTE: Some components have been removed from the illustration for
clarity.
12. Assemble one M10 HEX JAM NUT (31) onto one end of the CABLE (32)
approximately 1/2”. Assemble the ROD END BEARING (33) to the same
end of the CABLE until it meets the M10 HEX JAM NUT. Tighten the M10
HEX JAM NUT securely.
13. Loosely assemble the ROD END BEARING (33) of the CABLE (32) to the
WORKARM (15) using one M10 X 40mm BOLT (34), SPACER (35), 3/8"
SAE WASHER (5) and M10 NYLOCK NUT (10).
14. Route the CABLE (32) around the pulley of the TOWER SUPPORT (3) and
around the OUTPUT CAM ASSEMBLY (B). Insert the remaining end of
the CABLE through the inner hole of the OUTPUT CAM ASSEMBLY.
Insert the CABLE RETAINING PLATE (36) over the end of the CABLE.
Install two M8 HEX JAM NUTS (37) to the end of the CABLE.
Tighten the M8 HEX JAM NUTS until the WORKARM (15) begins to
move and all push pins still move in and out freely. Be sure the M8 HEX
JAM NUTS are tight against each other.
15. Attach the OUTPUT CAM COVER PLATE (38) to the OUTPUT CAM
ASSEMBLY (B) using three M10 X 45mm BOLTS (4) and three 3/8" SAE
WASHERS (5).
16. Place the unit in the intended place for use and check stability. If the unit
is not stable, the FEET (D) can be adjusted by inserting or removing sup-
plied SHIMS (39).
To add or remove SHIMS, loosen the LEVELING FOOT BOLT (E) and
NUT (10) until the desired SHIM(S) can be inserted or removed. Lightly
tighten the BOLT and NUT. Do not over-tighten the BOLT and NUT.
17. Install HOLE PLUGS in all open bolt holes.

©2006 Life Fitness, a division of Brunswick Corporation. All rights reserved.
Life Fitness is a registered trademark of Brunswick Corporation.
TCRW 6.09.06 8060801 RevA-2
