LIFE Ionizer 5100 User manual

Safety Guide
Parts Guide
Name & Function of Ionizer
Special Installation Notes
Installation Instructions
Installation Guide
Installation of the Pre-lter
Internal Filter Replacement
LED Display/Touch Sensor
LED Functions
LIFE 5100 Features
Operating Instructions
Amperage/Volume Adjustments/Filter Reset
Operation Warnings/Error Messages
Filters
Explanation of Ionized Water
Alkaline and Acidic Water Usage Guide
Uses of Ionized Alkaline/Acidic Water
Performance Features
Common Problems and Solutions
Acidic Cleaning Instructions
& Routine Maintenance
Frequently Asked Questions
4-8
9
10-11
12
14
15
16
17
18
19
20
21
22
23
24
25
26
27-29
30
31-32
33
34-45
Table of Contents

www.LifeIonizers.com/Support
4
75
5100
Safety Guide - Read Completely
Before installation or operation of the LIFE Ionizer® 5100, read this
instruction manual completely.
Note- Some parts may have been altered to improve product quality,
function or ease of use.
Symbols
Indications
Refer to the following key symbols and indicators throughout the manual.
Improper use may cause bodily injury
Improper use may cause structural damage to the unit
or physical injury
Caution, warning, danger symbol
Information on prohibited functions and uses
Make note of important information
Do not open as it may cause electric shock or other injury
Disconnect power plug in case of malfunction
As with most electrical appliances, electrical parts in
this ionizer are electrically live even when switch is o.

www.LifeIonizers.com/Support 575
5100
Improper use may cause bodily injury
When drinking Ionized Alkaline Water - Do not take
prescription or other medications for approximately one
hour before and after drinking water.
This machine should not be repaired or otherwise
disassembled by any unauthorized person as it
may cause electrical re or shock, and will void the
manufacturer’s warranty.
Do not place the machine in humid areas such as
bathrooms. Do not clean this machine by spraying
the ionizer with water as it may cause electrical
shock.
As with most electrical appliances, electrical parts in this
ionizer are electrically live even when the switch is o.

www.LifeIonizers.com/Support
6
75
5100
Power cord should not be touched with wet hands.
Power cord should be plugged directly into an electrical
outlet.
Do not connect multiple appliances into a single power
receptacle.
Dusty or dirty electrical outlets may cause safety issues.
Bending, twisting, pulling or putting heavy objects onto
the power cord may cause electrical problems including
re.
If power cord, plug, or electrical outlet are damaged,
discontinue use immediately.
If the ionizer machine falls into water-
1. Unplug power cord from electrical outlet
2. Wipe the machine down and place in shaded area
3. Contact your LIFE Ionizer®dealer
Use only (110v) in the U.S.A. and Mexico. Use (100v) in
Japan. Most other countries require (220v). The power
cord cannot be altered from manufacturer’s specs.
Do not crimp or staple the power cord as it could cause
electrical shock.
As with most electrical appliances, electrical parts in this
ionizer are electrically live even when the switch is o.

www.LifeIonizers.com/Support 775
5100
Improper use may cause bodily injury
Improper use may cause structural damage to
the unit or physical injury
Place machine in an upright position only.
If not used for several days, run water through the
unit for 1 to 3 minutes before starting.
Do not install this unit in direct sunlight or near a
heater, replace or other heat source.
Do not use water with a temperature of over 95
degrees Fahrenheit or 35 degrees Celcius.
Store Ionized Alkaline Water in an air-tight glass
container and refrigerate for up to 2 days.
If inexperienced with drinking Ionized Alkaline
Water, users are encouraged to start with level 1.
DO NOT DRINK ACIDIC WATER.
If wall mounted, secure rmly and correctly.
Do not store Alkaline or Acidic water in metal
containers, although you can put alkaline water in
the Water for LIFE stainless steel bottles as they are
designed to maintain pH and ORP.

www.LifeIonizers.com/Support
8
75
5100
Aluminum and brass containers will be tarnished by
Alkaline and acidic water.
Improper use may cause structural damage to the unit
or physical injury.
Do not block the unit vent as it can cause overheating
and/or electrical problems.
Do not use benzene, thinner, or chemicals to clean the
unit as it can damage the housing.
Do not block the water passage or tubing.
If the machine will not be used for several days...
1. Unplug the power cord from the electrical outlet
2. Turn o the water valve to avoid leaking
3. Remove lters, drain and place in refrigerator in
plastic bags.
When handling the pH test (reagent drops)
1. Keep away from eye area. If eyes become irritated,
ush thoroughly and consult a doctor.
2. If accidentally swallowed, drink water and consult a
doctor.
3. Store in an airtight container away from the reach of
children.
4. Drops are ammable. Keep away from children.

www.LifeIonizers.com/Support 975
5100
1. Refer to the diagrams on the following pages before
beginning installation.
2. Be aware that a 110v outlet (USA) or 220v outlet is required.
3. If after installation the water has an odor, you may need to
install a pre-lter. Please consult your LIFE Ionizer® dealer.
4. How to use reagent drops: (BTB Chemical). Put 2-3 drops in
approximately 1 ounce of water to be tested. Compare color
to color chart provided in kit to determine pH level.
Reagent Drops
(pH Test Drops)
Alkaline water
outlet hose
(exible)
Tubing Hose User Manual
BTB Chemical
Parts Guide
Screws for mounting to wall
Counter top
Diverter Valve

www.LifeIonizers.com/Support
10
75
5100
Name & Function of Unit
1. Front View
(1) MAIN BODY
(3) LED SCREEN
(2) ALKALINE
WATER
OUTLET
(4) SELECTION/
FUNCTION
TOUCH SENSOR

www.LifeIonizers.com/Support 11 75
5100
3. Bottom View
* Natural Water Inlet : Water inlet from the tap water
faucet or water manifold to the unit.
* Acidic Water Outlet : This is to drain the acidic/alkaline
water while the water is ionizing.
* Power Cord : To provide electric power.
Acidic Water Outlet
Natural Water Inlet
Power Cord

www.LifeIonizers.com/Support
12
75
5100
Special Installation Notes
The unit should be placed
horizontally in an environ-
ment in which there is no
danger of sliding.
Do not lay the ionizer
over the outer hose so
that the hose will not
be bent or pressed.
The unit should be
installed within 40
inches distance from
water drainage.
Acidic water hose
should be installed
lower than the ionizer.
The machine should
be installed away from
direct sunlight or
heaters such as a re
place or oil source.
• The unit can be operated on either a 110 or 220 volt setting.
Before plugging it in, set the voltage selector switch to the right setting.
• To avoid damage, the unit should be installed away from direct
sunlight and not exposed to freezing temperatures.
• Be sure to shut o the water supply from the tap when not in use.
• The unit should be connected to the cold water side.
(Never connect to hot water).
• Do not install the unit near a heater or other heat source.
• Do not attempt to modify the unit in any way; tampering will void
your warranty.

www.LifeIonizers.com/Support 13 75
5100

www.LifeIonizers.com/Support
14
75
5100
Installation Instructions for LIFE Ionizer™5100
Use Cold Water Only With Your Ionizer
STEP 1: Unscrew the existing aerator from your faucet.
STEP 2: Use teon plumbers tape on the threads. Screw the LIFE
Ionizer™ 5100 diverter valve onto your faucet. Three dierent
sized adaptors are included for non-standard sized faucets.
STEP 3: Unscrew the round nut from the side of the diverter valve.
Slide the nut over the end of the 1/4” tubing and then screw
the nut back onto the diverter valve. Tubing should now t
snugly onto the diverter valve.
STEP 4: Lay the ionizer down on its back and you will see two white
elbows extruding from the bottom of the machine. There
will be an o-white collar around the base of the elbow.
Depress the collar towards the machine while simultaneously
extracting the elbow from the machine. Now, holding the
elbow in your hands, you’ll see a similar collar near the end
of the elbow. In the same way as you extracted the elbow,
you can depress the collar towards the elbow and extract
the plug from the end of the elbow. It is sometimes helpful
to use the back of a butter knife or screw driver to remove
the plug. If you ever need to remove the tubing from the
quick release, you will use the same process.
STEP 5: Run tubing from the diverter valve to the inlet valve on the
bottom of the ionizer. Be sure to push the tubing into the
quick connect valve 3/4” until it is rmly seated.
STEP 6: Insert one end of tubing into outlet valve on bottom of unit
and run the other end into the sink securing it with the
suction cup provided. Some units may contain water.
Don’t be alarmed; we test units for quality before shipment!

www.LifeIonizers.com/Support 15 75
5100
Installation Instructions for LIFE Ionizer™5100
C
o
ld
w
a
t
e
r
in
le
t
C
o
ld
w
a
t
e
r
i
n
l
e
t
Assembly method of valve for
wall-mounted water taps
Fix adapter
Quarter turn
for Tap Water
Running
Water
Rubber Gasket
Remove the aerator from the water tap.
Assembly method of valve for Deck-sink water taps
Screw in the adaptor
Remove the aerator from
the water tap.
Connect by rotation
after inspection of
rubber packing
Installation Guide
Cold Water inlet
Assembly method of valve for Deck sink water taps
Assembly method of valve for
wall-mounted water taps
Quarter turn
for Tap Water
Running
Water
Cold Water inlet
Rubber Gasket
Fix adapter
Inlet
(Supply)
Outlet
(Drainage)

www.LifeIonizers.com/Support
16
75
5100
1. Cut the tubing leading to the ionizer at the desired location and length.
2. The cap on top of the lter housing is marked “OUT” and “IN”.
3. The tubing coming from the cold water connector needs to be inserted into the
side of the housing marked “IN”. Firmly press the tubing into the lter-housing cap.
You will feel the tubing stop when it is fully inserted. Pull on the tubing gently to
ensure that it does not come out and a good connection was made. If possible,
ush the lter by turning on the ow of water slowly and point the “OUT” towards
the sink; let it run for 2-3 minutes and turn the water ow o.
4. Insert the tube going to the ionizer into the side of the housing marked “OUT” by
rmly pressing the tube into the lter housing cap.
5. To remove the tubing from the lter cap, press in on the O-ring and tubing
simultaneously, then gently pull out on the tubing.
TOP VIEW OF FILTER HOUSING
SIDE VIEW OF FILTER HOUSING
Installation of the Pre-Filter

www.LifeIonizers.com/Support 17 75
5100
Internal Filter Replacement
►LED Screen Filter Display
1st lter: Condition of the 1st lter is shown on the
left side of the LCD screen. The height of the light
bar will gradually decrease as the lter is used up.
When the lter has 500 liters of life remaining, there
will be a voice prompt to change the lter. The unit
will not work when the lter’s life has expired.
►How to Change the Filters
→Press the two buttons on top right hand side, and tilt the side panel away
from the unit to remove.
→Select the lter to be changed, twist a quarter turn to the left and pull it from
the socket.
→Remove the sticker from the new lter.
→Insert, and twist the new lter a quarter turn to the right until it locks in position.
→Close the side panel then touch the WAKING/STAND BY touch control.
→The unit will automatically ush itself, and then it is ready for use.
The sticker on the lter
must be removed.
2nd lter: Condition of the 2nd lter is shown on the right side of the LCD screen.
The height of the light bar will gradually decrease as the lter is used up. When the
lter has 500 liters of life remaining, there will be a voice prompt to change the
lter. The unit will not work when the lter’s life has expired.
→Life of 1st lter: about 4,000 liters (about 4,226 quarts)
→Life of 2nd lter: about 8,000 liters (about 8,453 quarts)

www.LifeIonizers.com/Support
18
75
5100
LED Display
1. 1st lter life indicator.
2. Alkaline water selection lamp.
3. Acid water selection lamp.
4. Purify water selection lamp.
1. Touch to get alkaline water.
2. Touch to get acidic water.
3. Touch to get puried water.
4. Touch to enter the conguration mode (see pg 22).
5. Touch to turn the unit on.
6. Touch to manually ush the unit.
1
2
3 4
5
7
6
5. Wash lamp indicator.
6. 2nd Filter life indicator.
7. Alkaline/Acid water level.
Touch Control Panel Functions
1 2 3
4 5 6

www.LifeIonizers.com/Support 19 75
5100
LED Functions
1. Alkaline water selection lamp: The Alkali lamp is ON when
alkaline water is selected.
2. Acid water selection lamp: The Acidic lamp is ON when acidic
water is selected.
3. Puried water selection lamp: The Purify lamp is ON when
purify water is selected.
4. Wash lamp indicator: Lights up when washing function is
selected and during automatic ushing. (The unit will ush
itself for 20 seconds every 20 liters of use.)
5. 1st lter life indicator: Shows how much life is remaining for
the 1st lter.
6. 2nd lter life indicator: Shows how much life is remaining for
the 2nd lter.
7. Alkaline/Acid water level: Displays what level of alkaline/acid
water is being dispensed.
5. Wash lamp indicator.
6. 2nd Filter life indicator.
7. Alkaline/Acid water level.

www.LifeIonizers.com/Support
20
75
5100
1. One-touch ON/OFF control and function selection.
2. 5 Platinum coated titanium electrode plates.
3. LED displays which level of acid and alkaline water is being dispensed.
4. In case of malfunction, error messages are shown on the LED display.
5. Dual internal high capacity lters.
6. LED display shows remaining lter life for internal lters.
7. Voice message prompts for each function.
8. SMPS power control system.
9. System automatically regulates pH levels and water ow.
10. Automatic self cleaning cycle ensures safety and eciency of the unit.
LIFE 5100 Features

www.LifeIonizers.com/Support 21 75
5100
1. Touch the "Waking/Stand By" button on the front of the unit.
→When powered ON for rst time, the unit will ush itself auto-
matically. The red“Washing” LED will blink.
→Once the system is ushed, it will be in standby mode. Select the
type of water desired on the touch control panel.
2. When“Alkali” is selected, the blue "Alkali" LED will light up. Alkaline
water comes out and the voice prompt announces which level of
alkaline water is being dispensed.
→Repeatedly touch the "Alkali" touch control to cycle through the
available levels of alkaline water.
→The system remembers which level of alkaline water was selected
and will dispense that level of alkaline water until a new level is
chosen.
→However, if level 4 is chosen, for your safety the system will revert
to level 2 at next use.
3. When “Acidic” is selected, the yellow "Acidic" LED will light. Acidic water
comes out and there is a voice message announcing the level of acidic
water.
→Repeatedly touch the "Acidic" touch control to cycle through the
available levels of acidic water.
→After dispensing acidic water, the unit switches back to alkaline
water automatically for your safety.
4. When“Purify” is selected, puried water will be dispensed. The green
"Purify" LED will light up.
5. When“Washing” is selected, the red "Washing" LED will display for 30
seconds. After the wash cycle is complete, the unit will return to stand-
by mode.
→While washing the system, there will be a voice prompt: "Don't
drink water!"
→Use the "Washing" function when you need to clean the
electrolytic cell.
→The system will revert to the alkaline water setting after cleaning.
Operating Instructions
