LIFE Ionizer M9 Next Generation User manual

Safety Guide
Installation of Parts Guide
Parts of the Ionizer
LIFE M9 NG Installation Guide
Cold Water Connect Installation
Diverter Installation Guide (countertop)
LIFE M9 UC NG Installation Guide
Indicator Functions
Operation Method
Function Options
Quick Connect Fittings and Tubing
Operation Method (M9 UC NG)
Indicator Functions (M9 UC NG)
Internal Filter Replacement
Installation of the Pre-Filter
Filters
Explanation of Ionized Water
Alkaline and Acidic Water Usage Guide
Uses of Ionized Alkaline/Acidic Water
Performance Features
Common Problems and Solutions
Operation Warnings/Error Messages
Acidic Cleaning Instructions
& Routine Maintenance
Frequently Asked Questions
4-8
9
10
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27-29
30
31
32
33
34-45
Table of Contents

www.LifeIonizers.com/Support
4
75
M9/M9 UC NG
Safety Guide - Read Completely
Before installation or operation of the LIFE Ionizer®, read this
instruction manual completely.
Note- Some parts may have been altered to improve product quality,
function or ease of use.
Symbols
Indications
Refer to the following key symbols and indicators throughout the manual.
Improper use may cause bodily injury
Improper use may cause structural damage to the unit
or physical injury
Caution, warning, danger symbol
Information on prohibited functions and uses
Make note of important information
Do not open as it may cause electric shock or other injury
Disconnect power plug in case of malfunction
As with most electrical appliances, electrical parts in
this ionizer are electrically live even when switch is o.

www.LifeIonizers.com/Support 575
M9/M9 UC NG
Improper use may cause bodily injury.
When drinking Ionized Alkaline Water - Do not take
prescription or other medications for approximately one
hour before and after drinking water.
This machine should not be repaired or otherwise
disassembled by any unauthorized person as it
may cause electrical re or shock, and will void the
manufacturer’s warranty.
Do not place the machine in humid areas such as
bathrooms. Do not clean this machine by spraying
the ionizer with water as it may cause electrical
shock.
As with most electrical appliances, electrical parts in this
ionizer are electrically live even when the switch is o.

www.LifeIonizers.com/Support
6
75
M9/M9 UC NG
Power cord should not be touched with wet hands.
Power cord should be plugged directly into an electrical
outlet.
Do not connect multiple appliances into a single power
receptacle.
Dusty or dirty electrical outlets may cause safety issues.
Bending, twisting, pulling or putting heavy objects onto
the power cord may cause electrical problems including
re.
If power cord, plug, or electrical outlet are damaged,
discontinue use immediately.
If the ionizer machine falls into water-
1. Unplug power cord from electrical outlet
2. Wipe the machine down and place in shaded area
3. Contact your LIFE IonizerTM dealer
Use only (110v) in the U.S.A. and Mexico. Use (100v) in
Japan. Most other countries require (220v). The power
cord cannot be altered from manufacturer’s specs.
Do not crimp or staple the power cord as it could cause
electrical shock.
As with most electrical appliances, electrical parts in this
ionizer are electrically live even when the switch is o.

www.LifeIonizers.com/Support 775
M9/M9 UC NG
Improper use may cause bodily injury.
Place machine in an upright position only.
Do not install this unit in direct sunlight or near a
heater, replace or other heat source.
Do not use water with a temperature of over 95
degrees Fahrenheit or 35 degrees Celcius.
If wall mounted, secure rmly and correctly.
Improper use may cause structural damage to
the unit or physical injury
If not used for several days, run water through the
unit for 1 to 3 minutes before starting.
Store Ionized Alkaline Water in an air-tight glass
container and refrigerate for up to 2 days.
If inexperienced with drinking Ionized Alkaline
Water, users are encouraged to start with level 1.
DO NOT DRINK ACIDIC WATER.
Do not store Alkaline or Acidic water in metal
containers, although you can put alkaline water in
the Water for LIFE stainless steel bottles as they are
designed to maintain pH and ORP.

www.LifeIonizers.com/Support
8
75
M9/M9 UC NG
Aluminum and brass containers will be tarnished by
Alkaline and acidic water.
Improper use may cause structural damage to the unit
or physical injury.
Do not block the unit vent as it can cause overheating
and/or electrical problems.
Do not use benzene, thinner, or chemicals to clean the
unit as it can damage the housing.
Do not block the water passage or tubing.
If the machine will not be used for several days...
1. Unplug the power cord from the electrical outlet
2. Turn o the water valve to avoid leaking
3. Remove lters, drain and place in refrigerator in
plastic bags.
When handling the pH test (reagent drops)
1. Keep away from eye area. If eyes become irritated,
ush thoroughly and consult a doctor.
2. If accidentally swallowed, drink water and consult a
doctor.
3. Store in an airtight container away from the reach of
children.
4. Drops are ammable. Keep away from children.

www.LifeIonizers.com/Support 9
1. Refer to the diagrams on the following page before beginning
installation.
2. Be aware that a 110v outlet (USA) or 220v outlet is required.
If the outlet is located under the sink, make sure it is not near
the water source.
3. If after installation the water has an odor, you may need to
install a pre-lter. Please consult your LIFE IonizerTM dealer.
4. How to use reagent drops. (BTB Chemical). Put 2-3 drops in
approximately 1 ounce of water to be tested. Compare color
to color chart provided in kit to determine pH level.
Extra
Fuse
1/4”Tubing Hose
Diverter Valve
User Manual
Installation of Parts Guide
75
M9/M9 UC NG
For M9 UC NG
BTB Chemical
pH Color
Chart
Reagent Drops
(pH Test Drops)
Suction Cup
Located in the Power Switch
at the bottom of the machine
Cold Water
Connect
Faucet
Flexible Hose
Faucet Adapter
Faucet
Connector
Alkaline/Acid
Hoses
Tubing/Cable
Protector

www.LifeIonizers.com/Support
10
1. First Filter Cover
2. Wall Mount Screw
Holes
3. Speaker
4. Bar Code and Serial
Number
5. Second Filter
6. Under Counter
Installation
Plug/Connector
1. Source water inlet
2. Acidic outlet
3. On/O Power Switch
4. Fuse Box
5. Power Plug
Parts for the Ionizer (Back)
Parts for the Ionizer (Bottom)
xxx-xxxxx-xx-xx
Parts of the Ionizer
75
M9/M9 UC NG
6
345

www.LifeIonizers.com/Support 11
Parts for the Ionizer (Front)
1. Control Panel
2. Flexible Spout
3. LCD Panel
75
M9/M9 UC NG
2
1
3
A
IonizerParts List and InstallationGuide
1.Referto the diagrams on thefollowing pagebefore beginning
installation
2.Be aw are that a 110v outlet (US) or 220v outlet isrequired.If this
outlet is located under the sink make sure it is not near thewater
source.
3.If after installation thewater has an odor,you may needto install a
pre-filter.Pleaseconsultyour Life Ionizer dealer.
DO NO Trun thefollowingtypes ofwater though the Life Ionizer as it
cancause damageto the unit:
1.Dirty orSaltWater
2.Watercontaining high amounts ofrust or iron
3.Water above 40 degrees C/104 degrees F
Read these instructions thoroughly before attempting
installation
1-AcidWaterSpout
2-Digital Indicator
3-AlkaliWater Spout
4-ControlPanel
1- Water Spout
2- Digital Indicator
3- Water Spout
4- Control Panel
5- Top of Faucet
WARNING:
Do not twist top of faucet.
This will damage to the faucet.
5
Faucet (for M9 UC)

www.LifeIonizers.com/Support
12
LIFE M9 NG Installation Guide (countertop)
Use Cold Water Only With Your Ionizer
STEP 1: Unscrew the existing aerator from your faucet.
STEP 2: Use teon plumbers tape on the threads. Screw the LIFE
IonizerTM diverter valve onto your faucet. Three dierent
sized adaptors are included for non-standard sized faucets.
STEP 3: Unscrew the round nut from the side of the diverter valve.
Slide the nut over the end of the 1/4” tubing and then screw
the nut back onto the diverter valve. Tubing should now t
snugly onto the diverter valve.
STEP 4: Lay the ionizer down on its back and you will see two white
elbows extruding from the bottom of the machine. There
will be an o-white collar around the base of the elbow.
Depress the collar towards the machine while simultaneously
extracting the elbow from the machine. Now, holding the
elbow in your hands, you’ll see a similar collar near the end
of the elbow. In the same way as you extracted the elbow,
you can depress the collar towards the elbow and extract
the plug from the end of the elbow. It is sometimes helpful
to use the back of a butter knife or screw driver to remove
the plug. If you ever need to remove the tubing from the
quick release, you will use the same process.
STEP 5: Run tubing from the diverter valve to the inlet valve on the
bottom of the ionizer. Be sure to push the tubing into the
quick connect valve 3/4” until it is rmly seated.
STEP 6: Insert one end of tubing into outlet valve on bottom of unit
and run the other end into the sink securing it with the
suction cup provided. Some units may contain water.
Don’t be alarmed; we test units for quality before shipment!
75
M9/M9 UC NG

www.LifeIonizers.com/Support 13
LIFE M9 NG Installation Guide (countertop)
75
M9/M9 UC NG
Cold Water Connect Installation Method
1. Find the raw water
valve under sink.
Turn the main valve
(angle stop) off.
2. Take off the cold
water line from the
angle stop valve
as pictured.
3. Totally disconnect
the line as shown
above.
4. Connect the Cold
Water Connect
to the angle
stop valve. Then
connect the cold
water line to
the Cold Water
Connnect valve.
5. Close tight with
pliers.
6. Connect the 1/4”
tubing and open
the Cold Water
Connect valve.
Turn the main
valve back on.
(for under sink)
Bottom of Ionzier
Source Water

www.LifeIonizers.com/Support
14
75
M9/M9 UC NG
C
o
ld
w
a
t
e
r
in
le
t
C
o
ld
w
a
t
e
r
i
n
l
e
t
Assembly method of valve for
wall-mounted water taps
Fix adapter
Quarter turn
for Tap Water
Running
Water
Rubber Gasket
Remove the aerator from the water tap.
Assembly method of valve for Deck-sink water taps
Screw in the adaptor
Remove the aerator from
the water tap.
Connect by rotation
after insertion of rubber
packing
Diverter Installation Guide (Countertop)
Cold Water inlet
Assembly method of valve for Deck sink water taps
Assembly method of valve for
wall-mounted water taps
Quarter turn
for Tap Water
Running
Water
Cold Water inlet
Rubber Gasket
Fix adapter

www.LifeIonizers.com/Support 15 75
M9/M9 UC NG
Diverter Installation Guide (Countertop) LIFE M9 UC NG Installation Guide
xxx-xxxxx-xx-xx
MCU cable
Alkaline hose
Acid hose
Tap water hose
Faucet
Front
Back
Bottom
Rubber packing
Rubber packing
Fixing nut
Alkaline hose
MCU cable connector
Acid hose
Union connectors
MCU cable
Plug connector
Faucet turret
Acidic outlet valve
Source water inlet
Adapter
Tap water
hose
Alkaline outlet
Pre lter
(Optional double
or triple housings)
Pre lter(s)
Cold Water Connect

www.LifeIonizers.com/Support
16
Indicator Functions
75
M9/M9 UC NG
1. ON/OFF Button
2. Alkaline Selector
3. Purify Selector
4. Acidic Selector
5. Menu/Function
6. Filter 1 Indicator/Reset
7. Filter 2 Indication/Reset
8. Filter 1/Life Indicator
9. Filter 2/Life Indicator
10. Operation Display Lamp
11. Level Indicator
12. Indicator Water Type (Alkaline/Acidic/Purify)
13. pH Indicator
1211
9
813
10
4325 6 7 1

www.LifeIonizers.com/Support 17 75
M9/M9 UC NG
Operation Method
Press the “ON/OFF” button and
then select the “ALKALINE” button
and tap until the desired alkaline
level displays on the screen. The
level indicator will display the level
you selected. To STOP collecting
water, press the“ON/OFF” button.
Press the “ON/OFF” button and
then select the “PURIFIED”button
to start dispensing ltered, purifed
water.To STOP collecting water,
press the “ON/OFF” button.
Alkaline water discharge method
Acidic water discharge method
Puried water discharge method
Button & Indicator Functions
Press the “ON/OFF” button and
then select the “ACIDIC”button
and tap until the desired acidic
level displays on the screen. The
level indicator will display the level
you selected. To STOP collecting
water, press the“ON/OFF” button.

www.LifeIonizers.com/Support
18
75
M9/M9 UC NG
Function Options
VOLUME ADJUSTMENT (F-10)
• Hold down the "Menu" button for 5 seconds until the menu option
appears on screen. Then release “Menu/Function” button.
• To increase volume, press "Filter 1"; to decrease volume press "Filter 2"
AMPERAGE ADJUSTMENT (F-20)
• Hold down the “Menu” button for 5 seconds until the menu option
appears on screen. Then release “Menu” button.
• Scoll through menu by pressing “Menu” until the Alkaline symbol
appears and ashes.
• To increase amperage, press “Filter 1”; to decrease amperage press
“Filter 2” .
• Same process is used for adjusting the Acidic level.
PLATE SELECTION (F-30)
• Ensure machine is plugged in.
• Hold down the “Menu” button for 5 seconds until the menu option
appears on screen. Then release “Menu” button.
• Select number of plates (7,9 & 11)
LANGUAGE SELECTION (F-40)
• Hold down the “Menu” button for 5 seconds until the menu option
appears on screen. Then release “Menu” button.
• Select preferred language. (English is the default language)
PH DISPLAY OPTIONS (F-50/F-51)
• Default will show pH setting only
• ph Ho - Fixed level (use this level)
• pH En - Adjustable level
CLEANING (F-60) (reverses the electric power to clean the plates)
• Hold down the “Menu” button for 5 seconds until the menu option
appears on screen. Then release “Menu” button.
(1)
Washes beginning & end of water usage
(2) Washes at the beginning only (defualt setting)
(3) Washes at the end only
(4) Does not wash at all
DO NOT CHANGE. LEAVE AT DEFAULT SETTINGS.
1st FILTER SETTING (F-70) 3,000 liters (30 is default setting)
2nd FILTER SETTINGS (F-71) 5,000 liters (50 is default setting)
WATER FLOW CHECK (F-80) (0 is default setting)
RUN TIMER (F-81) 10 minutes (10 is default setting)
To show the power consumption and water ow information,
press the “Menu” button and“Filter 1” button at the same.

www.LifeIonizers.com/Support 19 75
M9/M9 UC NG
Quick Connect Fittings and Tubing
Push the tubing into the tting to the pipe stop. The coller (gripper has
teeth which hold the tubing rmly in position while the “O” Ring pro-
vides a permanent leak proof seal.
Check the Seal: Pull on the tubing to see if the seal is secure. It is a good
practice to test the system prior to leaving the site and/or before use.
Ensure system is depressurized before removing ttings. Push in the
coller against the face of the tting. With the coller held in this position,
the tube can be removed. The tting can then be re-used.
coller
To ensure an optimal seal, tubing should be cut with the end square.
An angled cut or distortion of the tubing will not provide an ecient seal
and may cause leaks. Determine the length of tubing needed for
the connection and cut the segement of tubing to the appropriate length.
To Connect:
To Disconnect:
push in coller
push in coller
pull tubing out

www.LifeIonizers.com/Support
20
Operation Method (Under the Counter)
When you select alkaline water.
1~4 phases appear in number
and light is marked by blue
color.
When you select acid water,
1~2 phases apear in number
and light is marked by orange
color.
When you select puried water,
the number and light is marked
by green color.
The lifetime of the lter is
shown by four phases of light.
You should change the lter
when only one bar is not lit up.
DISPLAY WINDOW OPERATION MENU DESCRIPTION
Early stages of lter life. In need of lter change.
75
M9/M9 UC NG
Please note that water will come out of both spouts when dispensing water.
A) When the Alkaline button is pressed, Alkaline water will be dispensed
from the top spout and acid water will be dispensed from the bottom
spout.
B) When the Acid button is pressed, Acid water will be dispensed from the
top spout and Alkaline water will be dispensed from the bottom spout.
C) When the purify button is pressed, puried water will be dispensed from
the bottom and top spouts.
Note: Push Power Button to Start Dispensing Water

www.LifeIonizers.com/Support 21
Voice Functions
Indicator Functions
1. Filter Indicator
2. Indicates Ionized Water Type
3. Indicates Selected
Ionization Water Setting
4. Ionization Water Selection
Button
5. The Faucet Can Swivel Up
to 120o
*It is being washed now, Please wait a minute.
*Alkaline 4 - 4th grade of alkaline water is being extracted now.
*Alkaline 3 - 3rd grade of alkaline water is being extracted now.
*Alkaline 2 - 2nd grade of alkaline water is being extracted now.
*Alkaline 1 - 1st grade of alkaline water is being extracted now.
*Acidic Water 3 - 3rd grade of acid water is being extracted now.
*Acidic Water 2 - 2nd grade of acid water is being extracted now.
*Acidic Water 1 - 1st grade of acid water is being extracted now.
*Puried Water is being extracted now.
Alkaline Water Button
Acid Water Button
Puried Water Button
75
M9/M9 UC NG
