Life Ionizers 9000 User manual

Safety Guide
Parts Guide
Name & Function of Ionizer
Careful Notice of Installation
Conversion from 9100 to 9200
Installation Instructions
Installation Guide
Installation of the Pre-lter
Internal Filter Replacement
LCD Display/Touch Sensor
LCD Functions
Special Features
Operation Method
Amperage/Volume Adjustments/Filter Reset
Operation Warnings/Error Messages
Filters
Explanation of Ionized Water
Alkaline and Acidic Water Usage Guide
Uses of Ionized Alkaline/Acidic Water
Performance Features
Common Problems and Solutions
Acidic Cleaning Instructions
& Routine Maintenance
Frequently Asked Questions
4-8
9
10-11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27-29
30
31-32
33
34-45
Table of Contents

www.LifeIonizers.com/Support
4
Safety Guide - Read Completely
Before installation or operation of the LIFE Ionizer®, read this
instruction manual completely.
Note- Some parts may have been altered to improve product quality,
function or ease of use.
Symbols
Indications
Refer to the following key symbols and indicators throughout the manual.
Improper use may cause bodily injury
Improper use may cause structural damage to the unit
or physical injury
Caution, warning, danger symbol
Information on prohibited functions and uses
Make note of important information
Do not open as it may cause electric shock or other injury
Disconnect power plug in case of malfunction
75
9000/9100/9200
As with most electrical appliances, electrical parts in
this ionizer are electrically live even when switch is o.

www.LifeIonizers.com/Support 5
Improper use may cause bodily injury
When drinking Ionized Alkaline Water - Do not take
prescription or other medications for approximately one
hour before and after drinking water.
This machine should not be repaired or otherwise
disassembled by any unauthorized person as it
may cause electrical re or shock, and will void the
manufacturer’s warranty.
Do not place the machine in humid areas such as
bathrooms. Do not clean this machine by spraying
the ionizer with water as it may cause electrical
shock.
75
9000/9100/9200
As with most electrical appliances, electrical parts in
this ionizer are electrically live even when switch is o.

www.LifeIonizers.com/Support
6
Power cord should not be touched with wet hands.
Power cord should be plugged directly into an electrical
outlet.
Do not connect multiple appliances into a single power
receptacle.
Dusty or dirty electrical outlets may cause safety issues.
Bending, twisting, pulling or putting heavy objects onto
the power cord may cause electrical problems including
re.
If power cord, plug, or electrical outlet are damaged,
discontinue use immediately.
If the ionizer machine falls into water-
1. Unplug power cord from electrical outlet
2. Wipe the machine down and place in shaded area
3. Contact your LIFE IonizerTM dealer
Use only (110v) in the U.S.A. and Mexico. Use (100v) in
Japan. Most other countries require (220v). The power
cord cannot be altered from manufacturer’s specs.
Do not crimp or staple the power cord as it could cause
electrical shock.
75
9000/9100/9200
As with most electrical appliances, electrical parts in
this ionizer are electrically live even when switch is o.

www.LifeIonizers.com/Support 7
Improper use may cause bodily injury
Improper use may cause structural damage to
the unit or physical injury
Place machine in an upright position only.
If not used for several days, run water through the
unit for 1 to 3 minutes before starting.
Do not install this unit in direct sunlight or near a
heater, replace or other heat source.
Do not use water with a temperature of over 95
degrees Fahrenheit or 35 degrees Celcius.
Store Ionized Alkaline Water in an air-tight glass
container and refrigerate for up to 2 days.
If inexperienced with drinking Ionized Alkaline
Water, users are encouraged to start with lever 1.
DO NOT DRINK ACIDIC WATER.
If wall mounted, secure rmly and correctly.
Do not store Alkaline or Acidic water in metal
containers.
75
9000/9100/9200

Aluminum and brass containers will be tarnished by
Alkaline and acidic water.
Improper use may cause structural damage to the unit
or physical injury.
Do not block the unit vent as it can cause overheating
and/or electrical problems.
Do not use benzene, thinner, or chemicals to clean the
unit as it can damage the housing.
Do not block the water passage or tubing.
If the machine will not be used for several days...
1. Unplug the power cord from the electrical outlet
2. Turn o the water valve to avoid leaking
3. Remove lters, drain and place in refrigerator in
plastic bags.
When handling the pH test (reagent drops)
1. Keep away from eye area. If eyes become irritated,
ush thoroughly and consult a doctor.
2. If accidentally swallowed, drink water and consult a
doctor.
3. Store in an airtight container away from the reach of
children.
4. Drops are ammable. Keep away from children.
www.LifeIonizers.com/Support
8
75
9000/9100/9200

1. Refer to the diagrams on the following pages before
beginning installation.
2. Be aware that a 110v outlet (USA) or 220v outlet is required. If
the outlet is located under the sink, make sure it is not near
the water source.
3. If after installation the water has an odor, you may need to
install a pre-lter. Please consult your LIFE Ionizer® dealer.
4. How to use reagent drops: (BTB Chemical). Put 2-3 drops in
approximately 1 ounce of water to be tested. Compare color
to color chart provided in kit to determine pH level.
Parts Guide
www.LifeIonizers.com/Support 975
9000/9100/9200
Reagent Drops
(pH Test Drops)
Alkaline water
outlet hose
(exible)
Tubing Hose
User Manual
BTB Chemical
Power Cord
Counter top
Diverter Valve
Faucet (for
9200 model)

Name & Function of Unit
1. Front View
2. 1st/2nd Filter Exchange
(1) MAIN BODY
(3) LCD SCREEN
(2) ALKALINE WATER OUTLET (4) SELECTION/FUNCTION
TOUCH SENSOR
(5) SLIDING DOOR
(6) 1ST FILTER (7) SECOND FILTER
www.LifeIonizers.com/Support
10
75
9000/9100/9200

3. Bottom View
(1) MAIN BODY (case): This is outer case in order to cover all the parts
equipped inside.
(2) ALKALINE WATER OUTLET: This is alkaline/acidic water outlet
while electrolyzing.
(3) LCD SCREEN: All the functions of the main unit are to be displayed on
the LCD screen.
(4) SELECTION/FUNCTION TOUCH SENSOR: This is the selection sensor to
select the level of alkaline/acidic or puried water.
(5) SLIDING DOOR: Quick and easy 1st & 2nd lter exchange by sliding
the door open.
(6) 1ST FILTER: This is for ltering contaminents from the tap water inlet valve.
(7) 2ND FILTER: This is for ltering additional sediments from the water
after passing through the1st lter.
(8) NATURAL WATER INLET: Water inlet from the tap water faucet or water
manifold to the unit.
(9) ACID WATER OUTLET: This is to drain the acidic/alkaline water while
the water is ionizing.
(10) POWER CORD: To provide electric power.
(11) POWER SWITCH: ON/OFF switch for main power supply.
(10) POWER CORD
(11) POWER SWITCH
(8) NATURAL WATER INLET (9) ACID WATER OUTLET
www.LifeIonizers.com/Support 11 75
9000/9100/9200

Special Installation Notes
The unit should be placed
horizontally in an environ-
ment in which there is no
danger of sliding.
Do not lay the ionizer
over the outer hose so
that the hose will not
be bent or pressed.
Be sure to install the
ionizer higher than the
faucet (to protect it
from freezing).
The unit should be
installed within 40
inches distance from
water drainage.
Acidic water hose
should be installed
lower than the ionizer.
The machine should
be installed away from
direct sunlight or heat-
ers such as a re place
or oil source.
• Before installation, make sure of your electric power voltage. This unit
is only for use with 110V/220V.
• The unit should be installed away from direct sunlight or cold areas, as
it may cause breakage.
• Be sure to close the natural water from the tap. The ionizer should be
connected to cool water. (Never connect to hot water.)
• Acidic water hose should be installed lower than the main body. If the
length of the hose is too long or located higher than the body, it may
have a negative eect on the taste of your water.
• Do not install this unit near a heater or other heat source.
• Do not make any modications to the internal or external parts of the
machine.
www.LifeIonizers.com/Support
12
75
9000/9100/9200

1. Snap in plastic adaptor into top of unit where exible metal hose was in place.
2. Cut a piece of 1/4 inch tubing and connect it to plastic adaptor on top of unit,
then insert other end of tubing into the alkaline tubing connection on faucet.
3. Connect a piece of 1/4 inch tubing from“outlet”on bottom of ionizer, to the
acid connection on faucet.
4. Plug in electrical extension wire into faucet connection and plug in the other
end into the back of the ionizer.
5. Press power button on top of faucet to turn on ionizer.
www.LifeIonizers.com/Support 13 75
9000/9100/9200
Conversion from 9100 to 9200
Power button
1. Inlet Valve
2. Outlet Valve
3. Power Plug
4. Fuse Box
5. On/O Power Switch

www.LifeIonizers.com/Support
14
Installation Instructions for LIFE IonizerTM 9000
Use Cold Water Only With Your Ionizer
STEP 1: Unscrew the existing aerator from your faucet.
STEP 2: Use teon plumbers tape on the threads. Screw the LIFE
IonizerTM diverter valve onto your faucet. Three dierent
sized adaptors are included for non-standard sized faucets.
STEP 3: Unscrew the round nut from the side of the diverter valve.
Slide the nut over the end of the 1/4” tubing and then screw
the nut back onto the diverter valve. Tubing should now t
snugly onto the diverter valve.
STEP 4: Lay the ionizer down on its back and you will see two white
elbows extruding from the bottom of the machine. There
will be an o-white collar around the base of the elbow.
Depress the collar towards the machine while simultaneously
extracting the elbow from the machine. Now, holding the
elbow in your hands, you’ll see a similar collar near the end
of the elbow. In the same way as you extracted the elbow,
you can depress the collar towards the elbow and extract
the plug from the end of the elbow. It is sometimes helpful
to use the back of a butter knife or screw driver to remove
the plug. If you ever need to remove the tubing from the
quick release, you will use the same process.
STEP 5: Run tubing from the diverter valve to the inlet valve on the
bottom of the ionizer. Be sure to push the tubing into the
quick connect valve 3/4”until it is rmly seated.
STEP 6: Insert one end of tubing into outlet valve on bottom of unit
and run the other end into the sink securing it with the
suction cup provided. Some units may contain water.
Don’t be alarmed; we test units for quality before shipment!
75
9000/9100/9200

www.LifeIonizers.com/Support 15
Installation Instructions for LIFE IonizerTM 9000
C
o
ld
w
a
t
e
r
in
le
t
C
o
ld
w
a
t
e
r
i
n
l
e
t
Assembly method of valve for
wall-mounted water taps
Fix adapter
Quarter turn
for Tap Water
Running
Water
Rubber Gasket
Remove the aerator from the water tap.
Assembly method of valve for Deck-sink water taps
Screw in the adaptor
Remove the aerator from
the water tap.
Connect by rotation
after insertion of rubber
packing
Installation Guide
Cold Water inlet
Assembly method of valve for Deck sink water taps
Assembly method of valve for
wall-mounted water taps
Quarter turn
for Tap Water
Running
Water
Cold Water inlet
Rubber Gasket
Fix adapter
Inlet Valve
Outlet Valve
(Drainage)
75
9000/9100/9200

www.LifeIonizers.com/Support
16
1. Cut the tubing leading to the ionizer at the desired location and length.
2. The cap on top of the lter housing is marked“OUT” and “IN”.
3. The tubing coming from the cold water connector needs to be inserted into the
side of the housing marked “IN”. Firmly press the tubing into the lter-housing cap.
You will feel the tubing stop when it is fully inserted. Pull on the tubing gently to
ensure that it does not come out and a good connection was made. If possible,
ush the lter by turning on the ow of water slowly and point the “OUT”towards
the sink; let it run for 2-3 minutes and turn the water ow o.
4. Insert the tube going to the ionizer into the side of the housing marked“OUT” by
rmly pressing the tube into the lter housing cap.
5. To remove the tubing from the lter cap, press in on the O-ring and tubing simul-
taneously, then gently pull out on the tubing.
TOP VIEW OF FILTER HOUSING
SIDE VIEW OF FILTER HOUSING
Installation of the Pre-Filter
75
9000
75
9000/9100/9200

www.LifeIonizers.com/Support 17 75
9000/9100/9200
Internal Filter Replacement
►LCD Screen Filter Display
1st lter: The 1st lter life is indicated on the left
side of the LCD screen. The lights will decrease as
the lter life diminishes. When the lter life has 100
liters remaining, there will be a voice message to
exchange the lter. The unit will not work when the
lter life is fully used.
►How to Exchange Filters
→Push the front from left to right side to open up.
→Select the lter and turn left to release it out of the socket.
→Be sure to take the sticker o of the new lter.
→Turn the lter into the lter socket to lock (right side) direction.
→Close the front from right to left side and then touch operating sensor.
→After draining out about 5 liters (about 5 quarts) water, in the waiting mode,
please touch alkaline water sensor so as to drink the water.
1st lter 2nd lter The sticker on the lter
must be removed.
2nd lter: The 2nd lter life is indicated on the right side of the LCD screen. The
lights will decrease as the lter life diminishes. When the lter life has 100 liters
remaining, there will be a voice message to exchange the lter. The unit will not
work when the lter life is fully used.
→Life of 1st lter: about 4,000 liters (about 4,226 quarts)
→Life of 2nd lter: about 8,000 liters (about 8,453 quarts)

www.LifeIonizers.com/Support
18
LCD Display
75
9000/9100/9200
1. 1st lter life indicator
2. Wash lamp indicator
3. Mode display indicator
4. Outlet water pH value
5. Voice set display lamp
6. Amount of water & speed
7. Operation display lamp
8. 2nd lter life indicator
9. Alkaline/Acid water level
10. Alkaline water selection lamp
11. Acid water selection lamp
12. Purity water selection lamp
13. Error display lamp
1. It works at Operation/Stand by MODE.
2. It works when Alkaline water selection is done.
3. It works when Acidic water selection is done.
4. It works when Clean water selection is done.
5. It is to alter with Selection Mode.
6. It is to set the MODE after selection.
7. It works for compulsory washing.
1
2
3
4
5
6
7 8 9
10
11
12
13
Optional Function Touch Sensor
ALKALI
ACIDIC
WAKING/
STAND BY
PURIFY
WASHING
SET
UP MODE
2
3
6
14
7
5

www.LifeIonizers.com/Support 19 75
9000/9100/9200
LCD Functions
1. Alkaline water selection lamp: The Alkali lamp is ON when
alkaline water is selected.
2. Acid water selection lamp: The Acidic lamp is ON when acidic
water is selected.
Purify water selection lamp: The Purify lamp is ON when purify
water is selected.
Outlet water pH/ORP value: It shows the pH/ORP value of the
outlet water.
3. Amount of water & speed: It shows the amount and speed of
inlet water.
4. Wash lamp indicator: It will be used when compulsory washing
function is required. (If the unit works continuously up to 30
liters or a little over 30 quarts, even if it is in automatic operating
mode, there will be an activation of 20 sec. automatic washing
function.) * This washing time and period shall be decided upon
the capacity setting.
5. Mode display indicator: Displays the MODE function.
6. 1st lter life indicator: It shows the 1st lter’s remaining life.
7. 2nd lter life indicator: It shows the 2nd lter’s remaining life.
8. Alkaline/Acid water level: It marks the level of alkaline/acidic
water.
9. Error display lamp: This is the function to use when the unit has
a malfunction or error.
10. Voice set display lamp: It is to control the voice volume.
11. On electrolysis display lamp: It shows the status of
electrolysis function.

www.LifeIonizers.com/Support
20
75
9000/9100/9200
1. It has one-touch sensing ON/OFF system for selecting each function.
2. It has 9 sheets of Platinum coated Titanum electrode plates (patented).
3. It can produce 9 levels of water - four (4) alkaline water, four (4) acidic water,
one (1) puried water. You can select the levels by using our convenient
touch sensor selection system.
4. Big LCD screen (Dierent Color LCD display).
5. There is a PH value (acid and alkaline concentration) display on the
LCD screen.
6. There is an ORP value (Oxidation-Reduction Potential) reading on the
LCD screen.
7. The pH of the water will be displayed on screen shown by 7 dierent
colors (reds is most acidic and purple is most alkaline).
8. It has self-diagnosis and error display function in the system.
9. There are 2 big capacity lters in the system.
10. There is wireless lter sensing function in the system to check the
certied parts and to sense the lter life.
11. It has a function to see the actual amount of serviced water by the
lter life display.
12. It has voice message function for each mode & ON/OFF function as
well in the system.
13. Outlet water amount per minute (min) shall display by liter (ℓ).
14. It has SMPS power control system.
15. It has PH and ORP automatic control system to manage supplying
water amount and speed.
16. It has an auto-clean feature that drains and cleans the unit after each use.
17. The automatic cleaning cycle ensures better sanitation and a well-
maintained unit.
18. While dispensing water in puried mode, the machine is designed to
cut o acidic water output, which saves unnecessary water waste.
19. Convenient front sliding door for easy lter access (patented).
Specic Features
