Lifestyle Solutions ZURICH User manual

Box # 1
2 pcs Side Rails
1 pc Slat Support
1 pc Head Board
Slats Box
4 pcs Support Leg
Parts And Fittings Packing Detail
13 pcs Slats
Box # 2
1 pc Foot Board
ZURICH BED
Page 1 of 2
Bed Assembly Instructions
A complete assembled view of
a Conventional Bed
4mm Allen Key - 1pc
M6 x 70mm JCBC - 4 pcs
Spring Washer - 12 pcs
Hardware Pack in Box #1
M8 x 25mm Bolt - 8 pcs
M4 x 32mm Screw - 26 pcs
(Wrapped in separate Plastic Bag)
Hardware Pack In Slats Box
5mm Allen key - 1 pc
Flat Washer - 12 pcs M6 x 40mm JCBC - 4 pcs
The Fusion Of Function And Comfort With Style

Bed Assembly
Instructions
Page 2 of 2
ZURICH BED
Foot board
Slat
Slat Support
Side Rail
M6 x 70mm JCBC
Head board
Step 1/Diagram 1a & 1b
Fix both side rails to the Head Board and Foot Board as shown in
diagram 1a with the 25mm bolts,washers and spring washers.
Do not tighten all the bolts at this point. Carefully thread in
the M6 x 40mm JCBC Bolts through the side rail end as shown in
diagram 1b to the Head/Foot Board insert nut. Tighten all 12 bolts
when the Head/Foot Board and side rails only when they are fully
assembled together.
Step 3/Diagram 3
Place both ends of the
assembled slats in the bed
frame resting on both sides
of the side rails and screw
them in place with the 32mm
screws provided as shown
in diagram 3.
Step 2/Diagram 2
Spread out all the slats on
to the slat support.Further
secure the pre-drilled slats
to the slats support and
support legs with 4nos
M6 x 70mm bolt as shown
in diagram 2.
Diagram 1a
Slat Support
Diagram 2
Support Leg
Leveler
M6 x 70mm JCBC
Allen Key
Washer
Allen Key
Side Rail
M8 x 25mm
Bolt
Threaded Hole
Metal Bracket
Spring Washer
The Fusion Of Function And Comfort With Style
Fasten screws to all slats
on side rail
Screw
Model shown for assembly instructions only
Diagram 3
Diagram 1b
M6 x 40mm
Bolt
Allen Key
Side Rail
Head & Foot Board
Metal
Bracket
Slat
Flat & Spring
Washer
