Lifestyle Solutions BARBADOS BED User manual

Box # 1 2 pcs. Side rails
2 pcs. Head Board
Parts And Fittings Packing Detail
Hardware Pack In Box #1
M4 x 32mm Screw
- 26 pcs.
JCBC Bolts
M8 x 25mm - 8 pcs
Washer - 8 pcs.
A complete assembled view of
the Barbados Bed
Box # 2
13 pcs.Slats
Box # 3
Optional :
Open shelf
M5 Allen Key 1 pc.
Optional :
Drawer Box
Optional Hardware
For Full Size Bed Only
1 pc. Slat Support
(Optional: Only for Full Size
Bed)
2 pcs. Support Leg
(Optional: Only for Full Size
Bed)
Bed Assembly Instructions Page 1 of 3
BARBADOS BED
The Fusion Of Function And Comfort With Style
LIFESTYLE SOLUTIONS
M4x 16 mm Screw
2 pcs
Slat Support Bracket
2 pcs
M4x 20 mm Screw
4 pcs

Bed Assembly Instructions
Page 2 of 3
BARBADOS BED
Head/ Foot board
Slat
Side rail
Slat Support
(Optional, Only for Full Size Bed)
Slat Support Bracket
(Optional, Only for
Full Size Bed)
Fix the Support leg into the Slat support as shown
Fix Slat Support Bracket and screw it to Head Board using M4 x 20mm screw as shown.
Step 2/Diagram 2 (For Full Size Bed Only)
Fix Slat Support and screw it into the slat support Bracket as shown. Using M4 x 16mm
screws, fasten the slat support beam as illustrated.
Step 4/Diagram 4 (For Full Size Bed Only)
Place the slats onto ledger strip that is already fixed to the side rails and
attach with screws provided as shown. You will need a Philips screw driver.
(not included)
Step 5/Diagram 5
Step 3/Diagram 3 (For Full Size Bed Only)
Step 1/Diagram 1
Fix both side rails to the Head Board & Foot Board as shown in
diagram 1 with the 25mm bolts and washers.
Head/ Foot board
Head Board Leg
Washer
M8 x 25mm
JCBC Bolt
Metal Bracket
Threaded Hole
Allen Key
Side Rail
M4 x 20mm
Screw
Slat Support
Bracket
Philips Screw
Driver
Head Board
For Full Size Bed Only
Fixing of Slats
Philips Screw Driver
M4 x 32mm
screw
Ledger strip
Slat
Side Rail
For Full Size Bed Only
Support Leg
Slat Support
Slat Support
M4 x 16mm
Screw
Metal Support
Philips Screw
Driver
Head Board
For Full Size Bed Only
Diagram 1
Diagram 2
Diagram 4
Diagram 3
Diagram 5
The Fusion Of Function And Comfort With Style
LIFESTYLE SOLUTIONS

Bed Assembly Instructions.
BARBADOS BED
Slide drawer box in place as shown.
Step 3 (Optional)
Optional
You can change drawer box with open shelves as shown
Page 3 of 3
