BCP L-Shaped Corner User manual

SKY2680Ver. 5
L-Shaped Corner
Computer Desk
INSTRUCTION
MANUAL

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

| 3
TOOLS
HARDWARE
•Please do not exceed the weight limitations of this item.
•Do not stand on or use any part of this item as a step ladder.
•Firmly secure all bolts, screws and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
•Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
•Be aware that some parts are heavy and have sharp edges.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
NOTICE Please retain these instructions for future reference.
PARTS
A
1 PC
SHORT TABLETOP
1 PC 1 PC
LONG TABLETOP
12SHORT TABLE
LEFT LEG
3
FLAT HEAD
SCREWDRIVER
A
31 PCS
M6 x 38mm
CAM BOLT
M4 x 14mm
SCREW
B
4 PCS
FOOT
C
10 PCS
CAM LOCK
D
31 PCS
UP TO 1 HR.
ASSEMBLY
2 PERSON
ASSEMBLY
50 LBS
CAPACITY
LBS

4|
PARTS
A
1 PC
LONG TABLE
LEFT LEG
1 PC 1 PC
SHORT TABLE
RIGHT LEG
4
A
2 PCS
SHELF SUPPORT
7
5LONG TABLE
RIGHT LEG
6
1 PC
LONG BOARD
9
1 PC
SHORT BOARD
8
A
2 PCS
SHELF
10
1 PC
BRACKET
11
TIGHTENING CAMLOCKS
1. Screw cam bolt
in completely.
2. Insert cam bolt and cam lock into
designated holes.
3. Screw cam lock
clockwise to secure
cam bolt.

| 5
PRODUCT ASSEMBLY
1
2
9
6
Insert the cam bolts on the long table left/right legs into the part 9 long board. Insert four part
D cam locks into the table back, and attach the legs by locking the cam locks.
Screw four part A cam bolts into the part 4 long table left leg and part 6 long table right leg.
x4 4
A6
4
BACK VIEW
x4
D

6|
PRODUCT ASSEMBLY
3
4Insert the cam bolts on the short table left/right legs into the part 8 short board. Insert four
part D cam locks into the table back, and attach the legs by locking the cam locks.
3
5
8
5
3
Screw eleven part A cam bolts into the part 3 short table left leg and part 5 short table right leg.
NOTE: Some of the embedded holes are covered with PVC, which can be directly screwed with
part A cam bolts.
x11
A
x4
D
BACK VIEW

| 7
PRODUCT ASSEMBLY
5Insert the cam bolts on the short board table into the long board table. Insert three part D cam
locks into the long board table, and attach the tables together by locking the cam locks.
Insert eight part C feet onto the table.
9
6
4
8
5
3
x3
D
x8
C
BACK VIEW

8|
PRODUCT ASSEMBLY
6Insert two part 10 shelves onto the cam bolts on the side of the short board table.
Insert four part D cam locks into the shelves, and attach the shelves by locking the cam locks.
x2
10
J
4x4
Dx4

| 9
PRODUCT ASSEMBLY
7
x4
x2
7A
Screw four part A cam bolts into two part 7 shelf supports, two bolts per shelf.
Cx2
7
x2
8Insert the shelf supports into the sides of the short board table. Insert four part D cam locks
into the shelves and shelf supports, and attach the shelf supports by locking the cam locks.
Insert two part C feet onto the shelf supports.
D
x4

10 |
PRODUCT ASSEMBLY
9
x12
A
1
2
Screw twelve part A cam bolts into the part 1 long tabletop and part 2 short tabletop.
10 Insert the cam bolts on the long/short tabletops into the table frame. Insert twelve part D cam
locks into the table frame, and attach the tabletops to the frame by locking the cam locks.
2
1
x12
D
