Lifestyle Solutions SECTIONAL ROLL ARM User manual

WARNING
WW - 7 / 12 / 2019
SECTIONAL ROLL ARM
ASSEMBLY INSTRUCTIONS
This product has been designed for seating three (3) average adults. To prevent injury and damage to this unit, PROHIBIT jumping on it.
This product is designed for home use and not intended for commercial use.
Children under the age of 5, small infants and babies should not sleep alone on this product for safety reasons.
Recommended # of people needed for handling: 2 (however it is always better to have an extra hand.)
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.

Loveseat Body
QTY:1
PARTS
2/12
1
Legs
Loveseat QTY:4
Chaise QTY:4
Right Facing Arm QTY:2
2
34
6
5
Chaise Body
QTY:1
Left Facing Arm
QTY:1
Right Facing Arm
QTY:1
Loveseat backrest
QTY:1
Chaise backrest
QTY:1
Back Cushion
Loveseat QTY:2
Chaise QTY:1
M10 Washer
(Outer Dim. 45mm)
Loveseat QTY:4
Chaise QTY:4
Right Facing Arm QTY:2
777
89

LOVESEAT PACKAGE
3/12
Step 1 :
8 X 6
9 X 6
3
4
5
1
7 X 1

4/12
Step 2 :
CHAISE PACKAGE
6 X 1
2
8 X 4
9 X 4
7 X 1

5/12
Step 3 :
Bracket on
loveseat body
Bracket on
backrest
LOVESEAT BACKREST ASSEMBLY
1
5
5
1

CHAISE BACKREST ASSEMBLY
6/12
Step 4 :
Bracket on
chaise
Bracket on
backrest
2
6
2
6

7/12
Step 5 :
LOVESEAT ARM ASSEMBLY
3
Metal plate
on armrest
Metal plate
on loveseat
3
Metal plate
on armrest
Metal plate
on loveseat
4
4

8/12
Step 6 :
CHAISE ARM ASSEMBLY
4
Metal plate
on armrest
Metal plate
on chaise
3
3
Metal plate
on armrest
Metal plate
on chaise
4

9/12
LOVESEAT AND CHAISE ASSEMBLY
Step 7 :
Metal plate
on chaise
Metal plate
on loveseat
Metal plate
on chaise
Metal plate
on loveseat

10/12
LEGS ASSEMBLY
Step 8 :
8
9
8
9

11/12
BACK CUSHIONS ASSEMBLY
Step 9 :
1
2
1
2
7
7777
77
7
7
77
77

12/12
INSTALLATION COMPLETE
For prompt, reliable service; please have your assembly
manual ready.
Need assistance?
Please call :
866-626-7826
