Lifestyle Arpeggio User manual

Arpeggio Rollator
LIFESTYLE MOBILITY AIDS
3200 Tyrone Blvd N
St. Petersburg, FL 33710
Email: [e-mail]
Website: www.lifestylemobilityaids.com
300 LBS
Available Colors
955CH
(Champagne)

The rollator comes fully assembled.
Place the rollator on its wheels on a flat
surface and open by pressing down on
the tubes at each side of the seat until
they lock into place.
To remobe the tote bag, grab and twist up on the round cap at the end of the tube on
each side of the seat. Hold the cap to the side and slide the clip on the tote bag out
of the tube. Then replace the cap into the tube.
UNFOLDING THE ROLLATOR
ADJUSTING THE HANDLE HEIGHT
Press and hold the adjustment button. Simultaneously move the handgrip up or
down to the desired height and release the adjustment button. The handgrip will
automatically lock into the next possible height position. Make sure to adjust both
sides at the same height.
The Ideal handle height is set when the top of the handle aligns with the user's
wrist when standing upright.
Adjustment
button
Hand grip
1. Handgrip
2. Brake lever
3. Height Adjustment button
4. Adjustable Backrest
5. Seat
6. Tote Bag
7. Front wheel
8. Rear wheel
PARTS DIAGRAM
Prior to use please read all instructions and keep manual for future use.
USER MANUAL - 955 ARPEGGIO ROLLATOR
ATTACHING/REMOVING THE TOTE BAG
1
2
3
4
5
6
7
8

To slow or stop the rollator while walking, squeeze both brake levers upward to apply
the brakes. Always apply brake pressure evenly.
To lock the brakes while the rollator is stopped, push down on each brake lever until
they lock into place. Release the brakes by pulling up on the brake levers.
45
Before using as a seat, the rollator should be on a level surface with the
brakes in the locked position.
Lock the brakes by pushing down on the brake levers until they lock into
place. Do not lean back or to the sides when seated.
FOLDING FOR TRANSPORT/STORAGE
To fold the rollator, pull up firmly on the strap located on top of the seat.
Then secure by pushing the two sides of the frame together until an audible click is
heard signifying the lock is in place. Pull the handles apart to unlock.
USING THE BRAKES USING THE ROLLATOR AS A SEAT
ADJUSTING THE BACKREST
The backrest height and depth are adjustable.
To adjust the height, loosen the screw knob below the handgrip and slide the
backrest up or down to the desired height and tighten the screw knob.
To adjust the depth, press and hold the silver adjustment button on the backrest
and slide the backrest in or out to the desired depth. Then release the adjustment
button making sure it clicks securely into place.

67
• Before use. the user should read all instructions and familiarize themselves
with the rollator.
• Ensure all components are properly and securely installed.
• Ensure the user has sufficient strength to safely operate and control the
rollator and hand brakes.
• Before using the rollator as a temporary seat, ensure the brake are locked.
• Do not release brakes until user is standing.
• Do not exceed the maximum recommended weight capacity of 300 lbs
evenly distributed.
• Avoid storing the rollator in direct sunlight; seat or parts exposed to
sunlight will heat up and may cause injury to the skin.
• Do not place more than 10 lbs of shopping or other items into tote bag.
• DO NOT MOVE ROLLATOR WHILE SEATED. This is a walking aid only and is
not to be used as a transportation device.
Do not use high pressure cleaners, steam cleaners or harsh, caustic chemicals.
Frame
• Wipe the rollator frame with a damp cloth.
• For more stubborn dirt, use a mild detergent solution with warm water.
• Dry thoroughly before use to avoid corrosion.
• Clean the wheels using a damp brush with plastic bristles (do not use a wire
brush or you may damage the rubber or painted finish).
Bag and Seat
• Regularly clean with a mild detergent and warm water, or wash with alcohol-
based disinfectants if necessary.
• Dry thoroughly before use.
• Avoid contact with saltwater or pools with high levels of chlorination.
Limited Lifetime Warranty is provided against any factory defects in material or
workmanship of the frame.
One (1) year warranty against defective materials or workmanship on all other
components, assemblies and parts.
This warranty does not cover device failure due to misuse, negligence, improper
storage or handling, improper operation and unauthorized modifications.
Normal wear and tear on non-durable components, such as hand grips, brake
cables, wheels, and totes are not covered under this warranty. These items are
subject to normal wear and need periodic replacement and/or adjustment.
For warranty service, it is recommended but not required that the product be
returned to the Lifestyle Mobility Aids dealer through whom it was originally
purchased. However, all Lifestyle Mobility Aids dealers are qualified to assist you
in obtaining warranty service. If the product is to be returned to Lifestyle Mobility
Aids, prior authorization will be required.
This product is identified by a serial number at the time of manufacture.
Removing or defacing the serial number label may void this warranty. If you have
a question about your Lifestyle Mobility Aids walker or this warranty please email
us at [e-mail].
MAINTENANCE
SAFETY PRECAUTIONS WARRANTY
