Light progress Uv-box-e3/40h-nx-r User manual

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 1/2

UV-BOX-E3/40H-NX-R

AISI 304 Stainless Steel Germicidal UV-BOX with Direct Radiation for

STERILITY MAINTAINING

MODEL:

UV-BOX-E3/40H-NX-R

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 2/3

SECURITY WARNING

The Company has ensured that every care is taken in the design and production of its machinery. In order to guar-

antee, as far as possible, that it is safe when used correctly. However, the laws on accident prevention require all users

of the machinery to ensure that whoever is responsible for installation, maintenance, use and sale of these products is

shown the instruction provided by our company and is made aware of the precautions to be taken.

According to the circumstances, the appropriate recommendations made in these instructions must be made available,

together with any other relative information, to any company or person involved in the installation of LIGHT PRO-

GRESS products.

Only use this appliance for its intended purpose as described in this booklet.

If the appliance is wrongly operated for a purpose other then that for which it is intended, no liability can be accept-

ed for any possible damage. The manufacturer cannot be responsible for any damage to people, animals and objects

caused by use or operation of the appliance contrary to these instructions.

As with all electrical appliances the safety information and precautions contained in this booklet must be carefully

observed, including following:

Before maintenance or cleaning ensure that the appliance is switched off and unplugged from the mains supply.

Should the appliance become faulty please contact our authorized Service Centre direct and in case of repairs ask

for genuine parts.

Improper repairs may damage the appliance and place the user at serious risk.

WARNING

•Avoid exposition to UV-C rays emitted by germicidal lamps,

even for few seconds, it may cause severe conjunctivitis and

erythema

•Plastic or painted surfaces exposed to direct UV-C rays may

progressively yellow, as after a long exposure to sunlight.

•The intended use is as a germicidal lamp for sterilization, any

other use is improper and dangerous

•The lamp, as supplied, cannot be modified or designed for use

with accessories or tools

•We disclaim all responsibilities and void the warranty in case of

tampering or lack of maintenance

•Read carefully the following instruction before use

•In case of opening of the UV section, must be provided a shut-off of the UVC devices

in order to avoid exposure to UVC light emitted by the germicidal lamp; It may cause

severe conjunctivitis and erythema.

•Remove the protection film from the device before light-on the UV-C lamp.

•This device can be used by children with no less than 8 years and by persons with

reduced physical, sensory or metal capacities or with no experience or knowledge, as

long as under supervision or often they have receiv3ed the related instructions about

the safe use of the device and the related risks. Kids do not have to play with this de-

vice.

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 3/4

CONVENTIONAL SYMBOLS NOTICED ON DEVICES

DOESN’T DISPOSE THIS PRODUCT ON THE UNDIFFERENTIATED WASTE DISPOSING OF THE

SUBSTITUTED ITEMS MUST BE PERFORMED RESPECTING THE LOCAL LAWS.

RECYCLE THE STUFFS THAT COMPOSES THIS PRODUCT.

OBLIGATION TO CONSULT THESE INSTRUCTIONS BEFORE USE THIS PRODUCT

DANGER OF ELECTRICAL SHOCK; REMOVE TENSION TO THE SYSTEM BEFORE PERFORMING

ANY OPERATION.

GENERIC DANGER.

DANGER OF EXPOSITION TO ULTRAVIOLET UV-C RAYS.

THIS DEVICE RESPECTS THE ROHS NORMS.

USE PROTECTIVE GLOVES

WEAR PROTECTIVE GLASSES

STORAGE OF THIS MANUAL

ATTENTION !

This instruction manual must be preserved and be ever at disposal to consultation; it must follow the device in

case of passage of property, and accompany the device until its demolition. It’s possible to contact Light Pro-

gress’ technical office to ask for updated instruction manuals and information.

DEMOLITION AND DISPOSAL

Do not dispose of these products as unsorted municipal waste but collect separately as special waste and

entrusting them to waste disposal firms specialised. Disposal must be in accordance with the Legislative

Decree 151/2005 (WEEE - Italy) or in accordance with the legislation in force in the country where it will be

the disposal (WEEE - EEC). In the event of non-compliance or improper disposal are provided for heavy

penalties. The apparatus is composed of plastic parts, electronic components, metal, UV lamps containing

mercury (dangerous substances to the environment and human health). The dealer is available to the withdrawal of the

apparatus used.

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 4/5

DEVICE DESCRIPTION

UV-BOX-E3/40H-NX-R has a stainless steel AISI 304 structure with 2 stainless steel AISI 304 flat grills to support the

objects to be disinfected. The grids support the stored items minimizing dead spots and getting disinfection of 99.99%

in very short exposure times.

The box is equipped with three lamps UV-C 40 W, protected by the grid to prevent hits and damages. The steel door is

equipped with a transparent anti UV polycarbonate window and a position switch for turning off the UV lamps when the

door is opened.

The box is also equipped with a control panel which has an on/off switch and a timer

The irradiation time can be adjusted from 1 second to 500 hours.

APPLICATIONS AND RESULTS

This cabinet can be used for germicidal disinfection and maintenance of sterility of objects and tools for healthcare,

pharmaceutical labs, microbiological labs, food industries, etc.

After washing, the objects can be stored inside the germicidal box, in order to maintain the condition of cleanliness in

time; objects can thus be used with confidence, even after several hours far from washing.

UV-BOX-E3/40H-NX-R is among the few items on the market to offer an action extremely effective, because it pos-

sesses two opposite lamps of high power (40W), which can radiate uniformly to all directions, directly on instruments

surface. Furthermore, the internal reflection increases the amount of UV radiation which invests the instrumentation

from all directions, reducing to zero the micro-shadows and lowering significantly the exposure times

Very short exposure times are thus obtained to get a 99.9% sterilization

OPERATION

The switching on / off of the box is controlled by a programmable cycle of pause / working time intervals.

You can decide for the duration of the irradiation and of the pause interval between two subsequent working periods.

Whenever the door is closed, UV lamps turn on and begin the disinfection of the inside space and surfaces. This will

last for the whole programmed working time; the possible opening of the door, during the disinfection action, immedi-

ately shuts off the lamps, in order to ensure the personnel safety; if you will close the door again, a new disinfection

action will begin from the start. At the end of the working period, automatically lamps will switch off. At the end of the

pause period, automatically lamps will switch on. This sequence allows to maintain aseptic conditions even at distance

in time.

The duration of the working time and of the pause time is manually adjustable before the beginning of the treatment.

BENEFITS AND ADVANTAGES

a) PHYSICAL ACTION AND ENVIRONMENTAL PROTECTION. Treatment by UV-C rays is purely physical, and

achieves always the same effect; also, there are no problems of overdose and rooms are always safe and practicable

(when devices are off). Rather, many methods of chemical treatment involve the use of dangerous products for the en-

vironment, and difficult to biodegrade, as well as the risk of contamination of foodstuffs. Also, by the use of chemicals it

is likely to develop resistant microbial forms with consequent danger to human health.

b) IMMEDIATE EFFECT. It takes just a very short time to obtain effective results (99% killing of the bacteria).

c) PRACTICABILITY AND SAVINGS. The treatment is immediate and ready for use. The maintenance is minimal with

low costs of both energy consumption and repairs.

d) NO CONTRAINDICATION FOR EQUIPMENT TO BE TREATED. This device provides the ability to maintain a ster-

ile equipment, without the slightest contraindication. Equipment to be disinfected, or previously sterilized, can be pre-

served for a long time and are ready at any time, since the treatment is dry and without heat generation.

e) TOTAL SAFETY. Ultraviolet rays are confined inside the enclosure and cannot exit for the presence of UV rays re-

sistant polycarbonate (LEXAN ®) and for the presence of micro-switches that prevent UV irradiation when the door is

open. Therefore, it may treat the instruments in the presence of the operators.

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 5/6

DEVICE CODES

RECEPTION

Handle with care as fragile material. Verify the integrity of the packaging, and please be careful not to damage the con-

tents when using sharp blades or cutters to open the box.

Remove the unit from the box, then inspect it immediately to ensure that no damage has occurred during transport.

Before installation and using the device please READ AND FOLLOW CAREFULLY THE SECURITY WARNINGS and

all others instructions that follows.

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 6/7

INSTALLATION

The UV-BOX-E3/40H-NX-R is a wall cabinet and it is fundamental to install it in a secure location accessible to the op-

erator. Take care not to place the cabinet in hazardous locations for the personnel.

To fix the cabinet to the wall, use two screw anchors (8 10mm) (not supplied), placed at a mutual distance equal

to the distance of the two welded eyelets, behind and at the top on the cabinet.

ELECTRICAL PLUGS IN

We suggest you to let a qualified electrician to install this device, following these instructions and the electrical

scheme, and following the CEI norms.

Make sure that the device will be installed where it will fit with the existing environmental conditions. Before

connecting the device to the electrical line, make sure that the labelled data on the device are the same as the

ones of the electrical line; we remind you that the electrical supply power of this device is 220-240V, 50/60Hz.

Make sure that the electrical system is suitable to provide the supply current required by the device (please

read the label).

The connection to the electrical line needs a multipolar switch.

The connection to the electrical line must be made by the supplied cable 3 x 1 mm2.

The use of screws, nuts, or other means, is necessary to connect the device to the electrical line.

We suggest the use of counters to know exactly the life of UV lamps and to remember when replace them.

Protect the power supply cable from high temperature, sharp corners, water, oils.

CONSOLE with timer switch for treatment time setting

Connection to the main

by Schucko IEC Socket.

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 7/8

SCHEDULING

ON/OFF SWITCH

Cabinet main power switch (green led power-on indicator)

TIMER

You should set up two types of time on the timer:

a) DURATION OF STERILIZATION

b) DURATION OF PAUSE, between two successive sterilizations

Proceed with the following steps:

1) Set the full scale as desired, by turning the two Phillips screws placed in the lower left side of the clock. For the dura-

tion of sterilization, act on the full scale "RANGE OFF". We recommend the full scale "10 minutes". For the duration of

the pause, act on the full scale "RANGE ON". We recommend the full scale "hrs" (hours).

2) Set the desired time, by acting on the two superimposed central rings, in the following way:

To set the duration of sterilization, adjust the gray ring with the red marker. It is recommended to set at least 4 (4

minutes). To set the duration of the pause, between one sterilization and the next, you must act on the transparent ring

with the green indicator. We recommend that you set it to 6 (6 hours). It can be set from a minimum of 1 sec. to a max-

imum of 500 hours. For the choice of the duration of irradiation, see the table on the side, about the most common bac-

teria and viruses exposition times; exposition times for molds (fungi) equal the exposition times for bacteria/virus multi-

plied by 2 or 3. START: Power-on the cabinet by the switch ON / OFF UV lamps will light up (if

the door is closed) and on the timer the RED LED will remain lit for all the dura-

tion of the sterilization period. Then, the start of the pause period will be indicat-

ed by the of the switching-on of the GREEN LED (UV lamps off). So cyclically

the two phases alternate. The presence of the power lamps will be visible

through the window of the doors (opaque to UV rays). Every time you open and

close on the door the clock re-start from scratch. The device can be live 24

hours on 24 without any contraindication

ON/OFF TIMER SWITCH

ON/OFF SWITCH

0

50

min

OFF

RANGE

ON

RANGE

DISINFECTION TIMES

for bacteria, virus and yeast:

reduction 90% ➔2 min.

reduction 99% ➔4 min.

reduction 99,9% ➔8 min.

reduction 99,99% ➔16 min.

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 8/9

MAINTENANCE

UV LAMP

Lamp maintenance is very important because UV-C light emit-

ted by the source is not visible to the eye, so, although you

see the lamp ON, its germicidal effect may not be sufficient to

performs disinfection treatment.

Before reaching the lamp, ALWAYS switch off power supply

If UV-C lamp gets dirty (or gets dusty) clean it with a clean cloth

and alcohol, and avoid touching the glass part with hands. To

check UVC lamp life number of hours, correct product code of the

spare UV lamp please refer to table 1. The lamp, once reached the

timing for replacement, must be replaced, this operation is carried

out as follows:

• Loosen the nuts on the lamp housing and let them slide

along the lamp; grab the lamp at the 2 ends and pull it in a

direction parallel to the lamp.

• Repeat the steps in reverse to insert the new lamp.

TROUBLESHOOTING

UV LAMP

See MAINTENANCE.

POWER SUPPLIER

This model is supplied with electronic ballast that provides an emission 15% higher than traditional reactors and also

the pipes are not affected by the ambient environment (operating down to -20 ° C). Finally, the ignition of the lamps is

immediate (without starter) and the duration is more prolonged.

To replace the ballast in the event of failure, ALWAYS remove power to the unit:

1) Unscrew the screws on the lid of the timer panel. Now the cover is removable and can be easily accessed inside.

Please, note that with this operation the door is set free and must be extracted.

2) Disconnect the wires on the right (4 or 7 wires) and the left (3 wires) placed on the power supply by pressing the

blade of a screwdriver on the slot corresponding to each input wire, to set it free. Pay attention to the succession of

links because each wire will have to occupy again the same position at the end.

3) Unstick the circuit board levering by a screwdriver.

4) Replace the ballast with a new one, like the original (for code see Table 1), and reconnect the wires paying much

attention to the succession of the links.

5) Mount the cover again, repeating in reverse.

TIMER

In case of failure, you must substitute the timer. So, remove power to the device:

1) Unscrew the screws on the lid of the timer panel. Now the cover is removable and can be easily accessed inside.

Please, note that with this operation the door is set free and must be extracted.

2) By a screwdriver, disconnect the wires screwed to the timer. Pay attention to the succession of links because each

wire will have to occupy again the same position at the end.

3) Uncouple the timer from the door.

4) Replace the timer with a new one, like the original (for code see Table 1), and reconnect the wires paying much at-

tention to the succession of the links.

5) Mount the cover again, repeating in reverse.

USE

PROTECTIVE

GLOVES

WEAR

PROTECTIVE

GLASSES

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 9/10

TECHNICAL SPECIFICATIONS

TABLE n.1

UV-BOX

E3/40H-NX-R

LAMP LIFETIME (h)*

≤ 18.000

SUGGESTED REPLACEMENT

Deduct 1 hour for every lighting (max. 2 Years).

TOTAL CONSUMPTION (W)

120

EXTERNAL DIM. AxBxC (mm.)

750 x 550 x 350

INTERNAL DIM. DxExF (mm.)

600 x 500 x 310

WEIGHT(Kg.)

22

INOX SHELVES

2

SPARE PARTS

UV LAMP CODE

n.3 CHS-40WH

BALLAST CODE

n.3 EB-55P

TIMER SWITCH CODE

n.1PM4HW-H-AC240V-J

* continuous operation

•Highly efficient selective UV-C lamp (at 253.7 nm.), pure quartz.

•Stainless steel AISI 304 cabinet with UV resistant polycarbonate window (LEXAN ®).

•All used materials are tested to resist intense UV-C rays.

•Rack in plastic for foods material with 11-16 knives housings.

•Timer for treatment duration programming.

•Timer for pause between two subsequent irradiations.

•Safety switch to turn off the UV light when the door is opened

•Electronic ballast specific for ultraviolet UV-C. (220-240 V, 50-60 Hz)CE lamps.

•Mark (LVD - EMC - MD - RoHS).

•UVLON ® PIPE protection (optional)

•Noise: less than 70 dB(A)

•Vibrations: less than 0.5 m/s2

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 10/11

LABEL AND SYMBOLS

Example:

SYMBOL

MEANING

Warning! Check the

attached documentation

GROUND TERMINAL

(The unit must always be connected to the

ground)

Device with CE certifica-

tion.

WARRANTY

All products made by LIGHT PROGRESS are manufactured using only materials of the higher quality, and are subject-

ed to rigorous testing, and are guaranteed to be free of factory faults according to current law and regulations.

•Minimum requirements for warranty validity

Warranty will be considered valid only in case of possession of the purchase document.

•Warranty limits

Warranty excludes

•Damages caused by not following the instructions that accompany the product at purchase.

•Periodical controls, maintenance, repairs or replacements of parts due to normal wear.

•Consumable parts.

•Use of incompatible spare parts or consumables; Compatibility is assured only by use of products pur-

chased from or recommend by Light Progress.

•Damages caused by modification of device / system without Light Progress’ previous consent.

•Improper use of the product, falling or crashes.

•Modifications or repairs made by unauthorized personnel.

For defective materials return, you must request the return merchandise authorization (RMA) sending an email to in-

[email protected]t or calling the number +39.0575.749255.

Once you receive the module, it has to be filled up in every part and sent via email to info@lightprogress.it or via fax

to +39.0575 789929 to obtain the RMA number that will authorize the shipments of the goods to Light Progress

warehouse. Only authorized goods will be accepted, otherwise it will be refused and sent back to the sender on ex-

works conditions. The packages must be sent on DDP (Delivery Duty Paid) with packaging suitable for transport. RMA

number is valid up to 10 working days from release date.

MANUFACTURER RESPONSIBILITY AND COMMITMENTS

Light Progress do not assume any responsibility for any damage to persons or property, due to failure to follow

these instructions. We recommend you to carefully read all the given instructions.

The manufacturer agrees with the buyer to provide, upon request, schemes of circuits, component parts lists, in-

structions for calibration of lamps and other information, which are useful to repair those parts that the manufacturer

considers repairable.

The company reserves the right to make changes without prior notification or public notice.

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 11/12

DECLARATION OF COMPLIANCE

We, LIGHT PROGRESS S.r.l., hereby declare under our own responsibility that the following units of own production:

UV-BOX-E3-40H-NX series

are in accordance with EEC directive 2014/30/EU (Electromagnetic Compatibility)

are in accordance with EEC Machinery Directive dispositions 2006/42/EU

are in accordance with EEC Low Voltage Directive 2014/35/EU

are in accordance with EEC (RoHS) 2011/65/EU

TECHNICAL STANDARDS APPLIED

UNI EN ISO 12100:2010

Safety of Machinery - Basic Concepts, General Principles for Design - Risk

assessment and risk reduction

UNI EN ISO 13857:2008

Safety of Machinery - Safety Distances to prevent danger zones being reached

by the upper and lower limbs (2008)

ISO 14120:2015

Safety of Machinery - Guards - General Requirements for the Design and

construction of fixed and movable guards

UNI EN ISO 13849-1:2016

Safety of Machinery - Parts of the Control System related to the Safety –Part 1:

General Design Principles

UNI EN ISO 14119:2013

Safety of Machinery - Interlocking devices associated with guards - Principles for

design and selection

CEI EN 60204-1/2016

Safety of Machinery - Electrical Equipment of Machines. Part 1: General Rules

(2010)

EN 61439-1:2011

Low-voltage Switchgear and Control Gear Assemblies. Part 1: General rules

FURTHER TECHNICAL STANDARDS APPLIED:

IEC EN 60335-1 "Safety of household electrical appliances and similar”

Electronic Ballasts for the control of the lamps in accordance with the standard EN 60928.

Germicidal UV-C Lamps in accordance with EN 61199.

Electrical Protective Measures in accordance with IEC 70-1, EN 60229.

Anghiari, 3.24.2020

Responsible for Standards: Dr. Aldo Santi

LIGHT PROGRESS S.r.l. Loc. San Lorenzo, 40 - 52031 ANGHIARI (AR) - ITALY - http://www.lightprogress.com

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 12/13

CIRCUIT SCHEME

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 13/14

Notes:

____________________________________________________

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 14/15

____________________________________________________

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 15/16

____________________________________________________

LIGHT PROGRESS UV-BOX-E3/40H-NX-R [eng]

mar-2020 Pag. 16/16

Loc. San Lorenzo, 40 - 52031 ANGHIARI (AR) - ITALIA

TEL. 0575 / 74.92.55 - FAX 0575 / 78.99.29

PRODUZIONE:

•ANGHIARI - Loc. San Lorenzo, 40

•CASTIGLION F.NO - Loc. S. Antonino, 40

Http: www.lightprogress.it

E-mail: info@lightprogress.it

Light Progress UV-BOX-E3/40H-NX-R User manual

Popular Laboratory Equipment manuals by other brands
