Calculite Matrix HID Lensed Adj. Accent C4X4MRW
Page 1 of 2 4½" X 4½" Square Aperture (1) 20W CMH MR16
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • D0711
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Ordering Information
Frame-In Kits Reflector Trims Finish/Flange Lamp
C4X420MREU Electronic 120/277V C4X4MRWCLW
C4X4MRWCLP
C4X4MRWCCLW
C4X4MRWCCLP
C4X4MRWCCDW
C4X4MRWCCDP
C4X4MRWWHW
Specular Clear/White
Specular Clear/Polished
Comfort Clear/White
Comfort Clear/Polished
Comfort Clear Diffuse/White
Comfort Clear Diffuse/Polished
White/White
(1) 20W MR16 CMH GX10 Base
Ceiling Cutout: 5 1/4" x 5 1/4" (130 mm x 130mm) Dia.
8.16"
9.66"
8"
9.66"
2"
Max. Ceiling
Thickness
5.75"
4.5"
Features
1. Reflector Trim: 55° physical and reflected cutoff. Available with integral
flange painted white or polished to match inside of cone.
2. Lamp Holder/Trim Adjustment Assembly: Unitized optics ensure
alignment of lamp and aperture cone regardless of ceiling thickness. EZ
Aim™ gear-driven adjustment features an optimized lamp path to maximize
light output at tilt angles up to 45°. Aiming indicator ensures accurate
lamp positioning. Solite lens ships standard. Adjust trim kit vertically to
accommodate up to 2" thick ceiling.
3. Socket: Twist and lock base. 5kV (600V) pulse rated PPS, black T240 body
socket with nickel-plated contacts. 18 AWG silicone leads with fiberglass
outer sleeve.
4. Frame Housing: Steel, 0.029" (22-Ga.), matte black finish. Removable cover
for top relamping.
5. Frame Vertical Adjustment Mechanism: Accommodates mounting to
virtually any ceiling system using pre-installed mounting bars, or ½" EMT
tubing (by others). Single locking feature secures all adjustments. Alignment
holes and markings allow fixture to be pre-set prior to installation. Final
adjustment can be made from below from inside the fixture.
6. Mounting Bars: Galvanized steel, 0.048" (18-ga.), pre-installed telescoping
bars extend to 30" long and lock securely into position. Built-in locking tabs
provide positive attachment to common T-bar systems. Self-centering feature
simplifies installation in 24" O.C. grid systems. Attaches to steel or wood
joists without accessories.
7. Retention Springs: Rust resistant springs secure trim for quick, tool-less
installation.
8. Ballast/Cover Assembly: Accessible from below and removable without
tools for inspection and ballast replacement.
9. Junction Box: 0.059" (16-ga.) galvanized steel. UL listed for 8 No. 12 AWG,
90°C through branch circuit conductors. Allows inspection from below.
Features (continued)
10.Thermal Protector: Meets NEC and UL requirements. Do not install
insulation above nor within 3" (76mm) of any part of the luminaire.
11. Electronic Ballast: 120 or 277V, 50/60 Hz., encased, high power factor
>0.99, THD <10%, thermally and transient protected, RMI/RFI complies with
FCC Part 18 non-consumer limits, shut-down at end of lamp life, sound rating
“A", Minimum starting temperature -30°, Type 1 Outdoor rating.
Ballast ANSI Code Voltage Max. Amps Input Watts
20W MH M156 120/277V 0.20/0.09 22
Options and Accessories
Accepts one optical accessory
2" diameter color filter/specialty filter: ADF2/AF2
2" diameter louver: AL2HC
Labels
UL, cUL (Suitable For Wet Locations)

Job Information Type:
Calculite Matrix HID Lensed Adj. Accent C4X4MRW
Page 2 of 2 4½" X 4½" Square Aperture (1) 20W CMH MR16
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • D0711
(FC) is initial footcandles
at center of beam. Beam
length (L) and beam width
(W) are to where the
candlepower is reduced
to 50% of the center beam
candlepower. (C) is the
distance to the center of
the beam.
2400
1800
1200
600
30°
60°
4 ½" x 4 ½" Aperture 20W CMH MR16 - 12°
500
1000
1500
2000 30°
60°
4 ½" x 4 ½" Aperture 20W CMH MR16-25°
1200
900
600
300
30°
60°
4 ½" x 4 ½" Aperture 20W CMH MR16-40°
20W G.E.HID MR16 12° SP,
GX10 BASE
Lamp @ 30° Vertical Tilt
Lumen Rating = 1000 LMS.
CBCP = 2595 CD
Beam Angle = 16°
Test Report No. 3421FR
Angle CP
0 117
5 166
10 297
15 644
20 1352
25 2138
30 2595
35 2154
40 1201
45 476
50 159
55 26
60 0
65 0
70 0
75 0
80 0
85 0
90 0
30° Aiming Angle - Horizontal Surface
D C FC L W
6' 3.5' 47 1.7' 1.5'
8' 4.6' 26 2.3' 1.9'
10' 5.8' 17 2.8' 2.4'
12' 6.9' 12 3.4' 2.9'
14' 8.1' 9 3.9' 3.4'
30° Aiming Angle - Vertical Surface
D C FC L W
2' 3.5' 81 1.7' 0.8'
3' 5.2' 36 2.6' 1.3'
4' 6.9' 20 3.5' 1.7'
5' 8.7' 13 4.3' 2.1'
6' 10.4' 9 5.2' 2.5'
Angle CP
0 165
5 210
10 335
15 628
20 1107
25 1630
30 1914
35 1730
40 1075
45 453
50 104
55 7
60 2
65 1
70 1
75 1
80 1
85 1
90 1
20W G.E.HID MR16 40° FL,
GX10 BASE
Lamp @ 30° Vertical Tilt
Lumen Rating = 1000 LMS.
CBCP = 1914 CD
Beam Angle = 22°
Test Report No. 3418FR
30° Aiming Angle - Horizontal Surface
D C FC L W
6' 3.5' 35 3.1' 2.7'
8' 4.6' 19 4.2' 3.6'
10' 5.8' 12 5.2' 4.5'
12' 6.9' 9 6.3' 5.4'
14' 8.1' 6 7.3' 6.3'
30° Aiming Angle - Vertical Surface
D C FC L W
2' 3.5' 60 3.5' 1.6'
3' 5.2' 27 5.3' 2.3'
4' 6.9' 15 7.0' 3.1'
5' 8.7' 10 8.8' 3.9'
6' 10.4' 7 10.5' 4.7'
Angle CP
0 134
5 241
10 417
15 676
20 940
25 1128
30 1214
35 1164
40 928
45 541
50 225
55 43
60 3
65 0
70 1
75 1
80 0
85 1
90 0
20W G.E.HID MR16 40° FL,
GX10 BASE
Lamp @ 30° Vertical Tilt
Lumen Rating = 1000 LMS.
CBCP = 1214 CD
Beam Angle = 30°
Test Report No. 3416FR
30° Aiming Angle - Horizontal Surface
D C FC L W
6' 3.5' 22 4.4' 3.7'
8' 4.6' 12 5.9' 5.0'
10' 5.8' 8 7.3' 6.2'
12' 6.9' 5 8.8' 7.4'
14' 8.1' 4 10.2' 8.7'
30° Aiming Angle - Vertical Surface
D C FC L W
2' 3.5' 38 5.5' 2.1'
3' 5.2' 17 8.2' 3.2'
4' 6.9' 9 10.9' 4.3'
5' 8.7' 6 13.7' 5.4'
6' 10.4' 4 16.4' 6.4'
