Lightolier Lighting Systems SORA-1 User manual

Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems SORA-1
1BHFPG -JHIU51FS'PPU/PNJOBM4FDUJPO
#
Ordering Information
S 1 4
Body
S
Arm
Family Lamps Wattage Style Length Finish
Family Arm Height Panel Power Finish
1Order 18” (45.72cm) station on integrated (H) versions only.
2Order only “H” option for Wall Mount and Answer.
3Order only “C” option for Kick and Post & Beam.
1= In cross section 28 = 28 Watt
54 = 54 Watt
S= Single
P= Post & Beam
4= 4 Foot
Nominal
SC = Platinum
WH = White
5= 5.5” (13.97cm)
18 = 18” (45.72cm)1
Blank for
Wall and
Post & Beam
A= Answer
K= Kick
M= Montage
P= Post & Beam
T= PTW
W= Wall
H= Hard2
C= Cord33
SC = Platinum
WH = White
Complete Ordering Instructions below.
Individual Only
Ordering Instructions
Sora single wing can be mounted in two basic configurations; wall and Post &
Beamand Steelcase furniture panel mounted (stanchion). The single wing
luminaires come in only 4-foot nominal length and in one light T5.
The wall mounted versions are designed for drywall mounting and should be
specified as a Single body style. The stanchion mounted luminaires are available
for Pathways Technology Walls (PTW), Montage, Answer and Kick. Pathways and
Montage are available with integrated (Hard) and flexible (Cord) solutions.
Integrated solutions are hard wired to the panels electrical systemand permanently
affixed. Flexible solutions with a 10-foot black electrical cord and plug and are
mounted via semi-permanent tool-less brackets to the panels top cap.
The Steelcase Answer panel systemis only available in the integrated (Hard)
solution. The Kick panel systemis only available in the flexible (Cord) design.
Ordering is completed in two steps. First, the luminaire Body options are selected.
Second, the Armoptions are selected. Two catalog items are required to complete
the ordering of a single fixture.
Features
1. Housing: Aluminumextruded in 4-foot nominal lengths.
2. Lamp: T5 linear fluorescent, 28 or 54 watt. (by others).
3. Reflector: 24 gauge CRS painted high reflectance.
4. Lens: Translucent matte white acrylic, 0.20” (0.51cm) thick.
Electrical
Ballast is electronic, low harmonic distortion, high power and ballast factor, uni-
versal voltage with two conductors and a ground. Mark X dimming (no extra control
wire required) is available. EM battery pack not available. Integral On/Off switch
provided. Pulling wires (by others) fromthe fixture base to a junction box (via 3/8”
(0.95cm) conduit) in the panel completes the electrical power on integrated
versions. Fixtures have 20’ (6.10m) of wire coming out of the base (Black, white
and green only). Wall mounted versions have the electrical conductors extended
out the end of the support armto be connected at j-box (by others). Post & Beam
products have solid arms thus electrical connections are made via cord. Factory
installed ballast disconnect allows the ballast to be disconnected fromand
reconnected to incoming power under load without turning the entire circuit off.
Mounting
Fixture mounting distance is 50.125” (127.32cm) between stantion arms.
Continuous row mounting is not available. Stanchion height determines the
distance to the bottomof the fixture. 5.5” (13.97cm) stanchions will have an
overall height of 5.5” (13.97cm) + 13.73” (34.87cm) = 19.23” (48.84cm).
Finish
Powder coated Steelcase Platinumor White baked enamel.
Customcolors available, consult factory.
Labels
UL (1286), cUL and I.B.E.W.
Stanchion Mount
W
all and Post & Beam 13.73”
(34.87cm)
2.38”
(6.05cm)
11” (27.94cm)
10.59” (26.90cm)
7.96”
(20.22cm)
4
1 2 3
13.73”
(34.87cm)
2.38”
(6.05cm)
11” (27.94cm)
10.59” (26.90cm)
7.96”
(20.22cm)
4
1 2 3

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt #
Lighting Systems SORA-1
1BHFPG -JHIU51FS'PPU/PNJOBM4FDUJPO
80% 70% 50%
70 50 30 70 50 30 70 50 10
0 898989 7879 79 606060
1 797470 7066 62 494744
2 716457 6256 51 423835
3 645548 4549 43 363228
4 584841 5143 36 322724
5 534335 4738 31 282320
6 493830 4333 27 252017
7 453427 3930 24 221816
8 423024 3627 21 201613
9 382821 3424 19 181411
10 36 25 19 31 22 17 17 13 10
20% FLOOR CAVITY REFLECTANCE
CANDLEPOWER
ZONE 0 22 45 67 90
DEG. CANDELAS
180 308 308 308 308 308
175 279 289 309 327 331
165 214 239 301 374 409
155 288 203 314 407 442
145 1162 390 327 418 459
135 1157 1003 337 420 462
125 1139 938 332 403 454
115 1090 856 317 375 490
105 914 821 271 565 1361
95 597 481 67 692 806
90 445 335 3 212 303
85 436 333 13 170 258
75 444 317 33 126 204
65 391 288 44 91 158
55 349 261 53 66 111
45 306 229 60 38 81
35 256 194 66 14 42
25 201 159 71 5 10
15 150 127 76 31 8
5 101 96 77 58 52
0 7676767676
DISTRIBUTION
Zone Lumens % Lamp%Luminaire
0-90 995 19.9 22.3
90-180 3455 69.1 77.7
0-180 4450 88.9 100.0
Performance
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
REPORT NO.: ITL54089
LAMPS: 1-F54T5
LUMENS: 5000
EFFICIENCY: 88.9%
CAT NO.: S154S4WH
CANDLEPOWER CURVE
WALL REFLECTANCE
Fixture Lengths & Mounting Locations
51.30” (130.30cm)
50.36” (127.91cm)
50.125” (127.32cm)
Stanchion Mounted Shown.
Wall and Post & Beamhave
same mounting centers.
Mounting Accessories
Answer Integrated
(Hard Wired)
Montage Integrated
(Hard Wired)
PTW Integrated
(Hard Wired)
Post & Beam
Kick Flexible
(Cord & Plug)
Montage Flexible
(Cord & Plug)
PTW Flexible
(Cord & Plug)
Wall Mount
