Lightolier CALCULITE 8037TB SERIES User manual

INSTRUCTION SHEET NO.
IS:8037TB
0597 Page 1 of 2
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE
This fixture is intended for installation in accordance with the National Electrical Code and local regula-
tions. To assure full compliance with local codes and regulations, check with your local electrical inspector
before installation. To prevent electrical shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
INSTALLATION PROCEDURE FOR CALCULITE®COMPACT FLUORESCENT
REFLECTOR TRIMS LOUVERED: 8037TB, 8038TB AND 8069 (TRIPLE TUBE) SERIES
A. REMOVE LOUVER (Fig. 1)
Pull LOUVER down from REFLECTOR.
B. INSTALL SOCKET CUP OR BRACKET (Fig. 2a)
Align tabs on SOCKET CUP with openings in REFLECTOR and
push in SOCKET CUP until RETAINING SPRING snaps in. Place
SOCKET BRACKET STUDS through holes in REFLECTOR. Secure
BRACKET from inside REFLECTOR with two supplied nuts.(Fig. 2b)
C. PUSH-UP REFLECTOR HOUSING (Fig. 3)
Tilt REFLECTOR and insert SOCKET CUP into ceiling opening on
side opposite JUNCTION BOX. Pivot REFLECTOR and push it up
into ceiling.
NOTE: To remove REFLECTOR disengage the SOCKET
CUP by depressing the RETAINING SPRING. (Fig. 2) Turn
REFLECTOR counterclockwise while pulling downward.
After starting, use both hands to remove, if desired. (Fig. 4)
D. LAMPING (Fig. 5)
Note: See SOCKET CUP for lamping information.
Tilt lamp base to engage, line up LAMP PINS with SOCKET. Bring
lamp to horizontal position and push into SOCKET. (Fig. 5) To
relamp, carefully pull straight out of SOCKET with one finger
place on the tip of the lamp to prevent hitting the REFLECTOR.
E. ATTACH LOUVER (Fig. 6)
Align SPRINGS in LOUVER with SLOT in REFLECTOR. Gently
push LOUVER straight up until SPRINGS snap into SLOTS in
REFLECTOR.
WARNING: (RISK OF FIRE) DO NOT INSTALL INSULATION
WITHIN 3” OF FIXTURE SIDES OR WIRING COMPARTMENT,
NOR ABOVE FIXTURE IN SUCH A MANNER SO AS TO
ENTRAP HEAT.
®
FALL RIVER, MASSACHUSETTS 02720
®
TO REMOVE
WARNING: USE ONLY WITH FRAME-IN KITS PROVIDED BY
LIGHTOLIER. USE OF OTHER MANUFACTURERS’ FRAME-IN
KITS VOIDS THE UNDERWRITERS LABORATORIES LISTING
AND COULD CONSTITUTE A FIRE HAZARD.
Fig. 1 Fig. 2a
Fig. 3
Fig. 4 Fig. 5
Fig. 6 SPRIN
REFLECTOR
LOUVER SLOT IN REFLECTOR
Fig. 2b
SOCKET
BRACKET
STUD
REFLECTOR
REFLECTOR
LOU-
REFLEC-
SOCKET
CUP SLOT RETAINING
SPRING
JUNCTION
BOX
SOCK-
ET
REFLECTOR
SOCKET

FALL RIVER, MASSACHUSETTS 02720
INSTRUCTION SHEET NO.
IS:8037TB
0597 Page 2 of 2
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE
This fixture is intended for installation in accordance with the National Electrical Code and local regula-
tions. To assure full compliance with local codes and regulations, check with your local electrical inspector
before installation. To prevent electrical shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
®
®
INSTALLATION PROCEDURE FOR CALCULITE®COMPACT FLUORESCENT
REFLECTOR TRIMS LOUVERED: 8056TB SERIES (QUAD OR TWIN TUBE)
A. REMOVE LOUVER (Fig. 1)
Pull LOUVER down from REFLECTOR HOUSING.
B. SNAP IN (Fig. 2)
Align tabs on SOCKET CUP with openings in REFLECTOR HOUSING
and push in SOCKET CUP until RETAINING SPRING snaps in.
C. PUSH-UP REFLECTOR HOUSING (Fig. 3)
Tilt REFLECTOR HOUSING and insert SOCKET CUP into ceiling
opening on side opposite JUNCTION BOX. Pivot REFLECTOR
HOUSING and push it up into ceiling.
Note: To remove REFLECTOR HOUSING disengage the
SOCKET CUP by depressing the RETAINING SPRING.
(Fig. 2) Turn REFLECTOR HOUSING counterclockwise
while pulling downward. After starting, use both hands
to remove, if desired. (Fig. 4)
D. LAMPING (Fig. 5)
Note: See SOCKET CUP for lamping information.
Insert lamp, tip first through hole in side of REFLECTOR HOUS-
ING opposite lamp SOCKETS. Bring lamp to horizontal position,
line up pins, and push into SOCKET. To relamp, carefully pull
straight out of SOCKET, tilt base downward, and remove lamp.
E. ATTACH LOUVER (Fig. 6)
Align SPRINGS in LOUVER with SLOT in REFLECTOR. Gently
push LOUVER straight up until SPRINGS snap into SLOTS in
REFLECTOR HOUSING.
F. CARE AND MAINTENANCE OF “ALZAK” REFLECTOR
If handling of reflectors with anodized or Alzak®finish is
required, the use of clean white or plastic film gloves is recom-
mended to avoid fingerprints.
Anodized or Alzak surfaces can be cleaned by the following
methods:
1. Wipe off with a soft, clean, dry, lint-free cloth.
2. Wipe off with a soft, clean cloth dampened in mild detergent
solution. Rinse, wipe dry with lint-free cloth or paper towel.
3. Wipe off with a soft, clean cloth dampened in a solution of
wetting agent and water (such as 2 oz. per gallon “Pluronic
L62-LF” by Wyandotte Products). Then wipe dry.
4. Or use a liquid wax such as Glass Wax®. Avoid gritting
cleaning agents.
WARNING: (RISK OF FIRE) DO NOT INSTALL INSULATION
WITHIN 3” OF FIXTURE SIDES OR WIRING COMPARTMENT,
NOR ABOVE FIXTURE IN SUCH A MANNER SO AS TO
ENTRAP HEAT.
WARNING: USE ONLY WITH FRAME-IN KITS PROVIDED BY
LIGHTOLIER. USE OF OTHER MANUFACTURERS’ FRAME-IN
KITS VOIDS THE UNDERWRITERS LABORATORIES LISTING
AND COULD CONSTITUTE A FIRE HAZARD.
TO REMOVE
Fig. 1 Fig. 2
REFLECTOR
HOUSING RETAIN-
ING
SOCKET
TABS
JUNCTION
BOX
REFLECTOR
HOUSING
SOCKET CUP
SOCKET
REFLECTOR
HOUSING
SLOT IN
REFLECTOR
SPRING
LOUVER
