Lightolier Calculite ProSpec PA4A1175 User manual

<<<
>>>
O.C.
7"
O.C.O.C.
7"
7"
51 1/2" L X 7" W
28" L X 7" W
8 3/4"
Depth
5
6
7
10
11, 12
12
34
54 1/4"
16"
8"
13"
Top View
8
9
13
Flanged Trimless
5"
Ceiling Cut: 29 1/16" L x 8 3/16" W
Ordering Information: AR 111 Series A
Cat. No. Lamp Ceiling Trim Aperture Finish
PA4A117EBL (4) 75W AR 111 Overlap Black with White Flange
PA4A117EWL (4) 75W AR 111 Overlap White with White Flange
PA4A117EBTL (4) 75W AR 111 Trimless Black
PA4A117EWTL (4) 75W AR 111 Trimless White
Add a “1” for 120v or “2” for 277v at the end of the catalog number for voltage
PA4A117EBL = (Flanged) Black/White
PA4A117EWL = (Flanged) White
PA4A117EBTL = (Trimless) Black
PA4A117EWTL = (Trimless) White
Calculite®ProSpec®Linear Downlight PA4A1175
Page 1 of 2 4 Light AR 111 Series A
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • C0306
Features
1. Aperture Frame: Provides clean support for lamp holders and overlapping
flange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Media Cartridge: Allows convenient loading and removal of up to two
accessories (including lamp cover glass; lamp cover glass may be replaced
with solid glass accessory). Easily installed and removed for lamping with a
simple twisting motion. Constructed of diecast aluminum.
3. Cross Blade Louver: Extruded aluminum. 1" deep, provides additional
shielding and can be easily removed.
4. Adjustable Ring: Allows 360° horizontal and 30° (on width) and 40° (on
length) vertical adjustment.
5. Tortiontite Spring: For easy installation of aperture frame.
6. Housing: Die formed 22 ga. steel. Finish: Black.
7. Mounting Brackets: Adjustable vertically from outside of housing.
8. Thermal Protector: Meets NEC, UL , and CSA requirements.
9. Junction Box: 14 ga. steel, 4" x 3 1/2" x 2" box. Allows inspection from
below.
10. Lamp and Accessory Support: .032" steel, flared for easy entry of Media
Cartridge.
11. Lens Retaining Ring: .093" spring steel rod. Holds accessories in place.
12. Lamp Guard: Heat resistant clear glass. Lamp manufacturers requirement.
13. Transformer Housing: Die formed 18 ga. steel.
Electrical
Electronic Transformers: Offer reliable operation and are accessible from
below for servicing. 12V Secondary.
Dimming Controls: Use only dimmers specifically designed for use
withelectronic transformers. Low Voltage fixtures may produce audible
sound when used with dimmers, which may be objectionable in acoustically
critical areas.
Electrical (continued)
UL/cUL listed for through branch circuit wiring with maximum of (8) no. 2 AWG
90°C.
Finish
All painted finishes are powder coated baked enamel.
Options & Accessories
Accessories: 4 3/4" dia. series, filters, lenses, screens and louvers. (2)
accessories maximum, including lamp cover glass. Lamp guard glass may be
replaced with solid glass accessory.
Labels
UL/cUL (Suitable for Damp Location), I B E W
Add a “1” for 120v or “2” for 277v at the end of the catalog number for voltage

(FC) is initial footcandles at center of beam.
Beam length (L) and beam width (W) are to
where the candlepower is reduced to 50%
of the center beam candlepower.
CBCP is center beam candlepower.
(C) is distance to the center of the beam.
Lamp data shown is typical, and is based
on bare lamp photometrics. Contact
lamp manufacturers for availability and
performance.
10’ 250 1.7’ 1.7’
15’ 111 2.6’ 2.6’
20’ 63 3.5’ 3.5’
25’ 40 4.4’ 4.4’
8’ 4.6’ 254 1.9’ 1.6’
12’ 6.9’ 113 2.8’ 2.4’
16’ 9.2’ 63 3.7’ 3.2’
20’ 11.5’ 41 4.7’ 4.0’
4’ 6.9’ 195 2.9’ 1.4’
6’ 10.4’ 87 4.3’ 2.1’
8’ 13.9’ 49 5.7’ 2.8’
10’ 17.3’ 31 7.2’ 3.5’
25000 2000
75W AR111
SP 10°
3’ 144 3.5’ 3.5’
5’ 52 5.8’ 5.8’
7’ 27 8.1’ 8.1’
9’ 16 10.4’ 10.4’
3’ 1.7’ 94 5.2’ 4.0’
5’ 2.9’ 34 8.7’ 6.7’
7’ 4.0’ 17 12.1’ 9.3’
9’ 5.2’ 10 15.6’ 12.0’
1’ 1.7’ 163 * 2.3’
2’ 3.5’ 41 * 4.6’
3’ 5.2’ 18 * 6.9’
4’ 6.9’ 10 * 9.2’
1300 2000
75W AR111
WFL 60°
6’ 125 3.2’ 3.2’
8’ 70 4.3’ 4.3’
10’ 45 5.4’ 5.4’
12’ 31 6.4’ 6.4’
5’ 2.9’ 117 3.7’ 3.1’
7’ 4.0’ 60 5.1’ 4.3’
9’ 5.2’ 36 6.6’ 5.6’
11’ 6.4’ 24 8.1’ 6.8’
2’ 3.5’ 141 5.5’ 2.1’
3’ 5.2’ 63 8.2’ 3.2’
4’ 6.9’ 35 10.9’ 4.3’
5’ 8.7’ 23 13.7’ 5.4’
4500 2000
75W AR111
FL 30°
MR16 Low Voltage Halogen Bi-Pin Lamps
D FC L W D C FC L W D C FC L W
Lamps Beam Spread CBCP Rated
(To 50% CBCP) Life (Hrs.)
0° Aiming Angle 30° Aiming Angle 30° Aiming Angle
30°
Calculite®ProSpec®Linear Downlight PA4A1175
Page 2 of 2 4 Light AR 111 Series A
