Lightolier Lytespan 8735 User manual

Features
1. Housing: Spun, 16GA. aluminum housing
2. Neck Flange: Cold rolled steel, zinc-plated. Used to attach shade to
fixture, without tools.
3. Groove: To connect optional Accessory Holder to shade.
4. Barndoors: 18GA. aluminum, riveted to Brackets. Qty. of 4
5. Brackets: 18GA. cold rolled steel, riveted to Housing.
6. Washer: For added tensioning.
7. Alignment Mark: Aligns with mating fixture to ensure proper shade orientation
Options and Accessories
MetallicsTM PAR30 Accessory Holder (8783) & Accessories. Order separately
(See Lightolier Specification Sheet 8783).
5
1
2
3
6
4
7
3 9/16”
5 17/16”
1 1/8”
3 1/16”
4 1/4”
10 3/16”
7 5/8”
3 19/16”
12 3/16”
10 13/16”
3 9/16”
12 3/16”
7 5/8”
BARNDOOR PAR30 WITH
METALLICSTM INCANDESCENT/HALOGEN
FIXTURE 8701 & 28701 (PROSPEC)
BARNDOOR PAR30 WITH
METALLICSTM ELECTRONIC METAL HALIDE
FIXTURES 8704E, 8705E
& 28705E (PROSPEC)
ACCESSORY HOLDER,
OPTIONAL (SEE ACCESSORIES
& OPTIONS BELOW)
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 •[phone] •Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) •A0902
Lytespan®Track Lighting 8735
Page 1 of 1 MetallicsTM PAR30 Barndoor Shade
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Finish
All painted finishes: White or Titanium baked enamel.
Labels
UL, I.B.E.W.
ø3 1/8”
Ordering Information
Catalog No. Finishes Lamps
8735 WH Matte White INCANDESCENT: PAR30 75W Max. (When used or fixtures 8701 & 28701)
8735 TM Dark Titanium METAL HALIDE: PAR30L 39W (When used on fixture 8704E)
METAL HALIDE: PAR30L 70W (When used on fixture 8705E & 28705E)
