Lightolier QVH2GPFOS2FT User manual

Mounting Methods / Features Dimensions
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L85-10
Features
• Efficiency 52.6%.
• Shallow plenum depth.
• Swing down microperforated lamp shields for easy relamping and
maintenance.
• Alter soft white film on inside of mesh conceals lamp image and
provide balance between reflected light and direct light.
• 95% Reflective Alter soft white paint finish.
• Specular interior reflector.
• One piece body for easy installation.
• Easy access to ballast through lamp compartment.
• Fits standard T-Grid ceilings.
• Optional acrylic drop-down visual element
• Slim Semi-Recess and Slim Surface luminaires have the same
photometric performance data.
T-BAR
(43mm)
1-11/16"
2-1/4"
(57mm)
23-13/16"(605mm)
23-13/16"(605mm)
ALTER SOFT LIGHTS QVH2GPFOS2FT
Page 1 of 2 2 '
x2' SLIM SEMI-RECESSED DIRECT/INDIRECT FLUORESCENT
2 LAMP, TT5 BI-TUBE, 2 1/4’’ RECESSED CEILING DEPTH
MICROPERFORATED MESH LAMP SHIELD, STATIC
Microperforated mesh
lamp shields
Ceiling compatibility
Swing down optical system for
easy relamping and maintenance
Suited to standard exposed
T-grid ceilings
Suited to standard exposed
Slot T-grid ceilings
(57mm)
2-1/4"
(100mm)
3-15/16"
(57mm)
2-1/4"
(100mm)
3-15/16"
25-9/16"(650mm) Width
24"(610mm) Length
CEILING
CONTOURED
SURFACE FRAME
SPRING
BRACKET
MOUNTING
Shallow plenum depth
Slim Surface
qvf2spfos2FT
Slim Surface and Slim Semi-Recessed
have the same photometric performance
data.

Photometry*
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] •Fax [phone]
631 Airport Road, Fall River, MA 02720 •[phone] •Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L85-10
Job Information Type:
Specifications
MATERIALS: One piece chassis constructed from die formed 20 gauge cold rolled
steel. Reflectors - 95% reflectance baked white acrylic matte paint finish. Soft
white acrylic film on inside of lamp shield conceals lamp image.
FINISH: Chassis exterior - phosphate undercoating, baked white acrylic matte
high reflectance paint finish.
ELECTRICAL: Rapid start HPF, thermally protected class “P”ballast (Bi-tube type).
If K.Os are within 3”of ballast use wire suitable for at least 90C.
LABELS: Listed by
Ordering Information
Explanation of Catalog Number. Example: QVH2GPFOS2FT120SB
QUALITY
VISUAL
STATIC
QVH- Slim Semi-Recessed
QVF-Slim Surface
direct indirect
soft light
optical system
FIXTURE
WIDTH:
2’
CEILING TYPE:
G=Standard exposed
T-grid ceilings (for QVH)
S=Surface (for QVF)
LAMP SHIELD:
PF = Microperforated
LAMP
QUANTITY
LAMP/FIXTURE
LENGTH:
(NOMINAL 24”)
FT = TT5
Bi-tube
VOLTAGE:
120V
277V
347V
BALLAST:
BE = 50W Electronic TT5 RS
BR = 40W Electronic TT5 RS
BX = 40W Magnetic TT5 RS
PB = 40W TT5 PowerSpec Dimming*
PC = 50/55W TT5 PowerSpec Dimming*
SB = 40W Generic Electronic TT5
*Not available in 347V.
OPTIONS:
R = Radio Interference Filter
O = Emergency Lighting System
(for Canada)
N =Emergency Lighting System
(for U.S.)
2PF 2FT
CLEAR POLISHED
ACRYLIC DROP
DOWN VISUAL
ELEMENT:
OS = Open slot (no acrylic)
GC = Clear acrylic
GG = Clear acrylic / Green projected color face
GB = Clear acrylic / Blue projected color face
GR = Clear acrylic / Red projected color face
*Slim Semi-Recessed and Slim Surface luminaires have the same photometric performance data.
ALTER SOFT LIGHTS QVH2GPFOS2FT
Page 2 of 2 2 ' x2' SLIM SEMI-RECESSED DIRECT/INDIRECT FLUORESCENT
2 LAMP, TT5 BI-TUBE, 2 1/4’’ RECESSED CEILING DEPTH
MICROPERFORATED MESH LAMP SHIELD, STATIC
