Lightolier Calculite Standard Finish & Flange Options User manual

Lightolier is a Philips group brand
Care & Maintenance
If handling of reflectors with Alzak®finish is required, the use of clean white or plastic film gloves is recommended
to avoid fingerprints. Alzak®surfaces can be cleaned by the following methods: Wipe off with soft clean, dry
lint-free cloth; or wipe off with a soft cloth dampened in mild detergent solution, rinse, then wipe dry with lint-free
cloth or paper towel. Avoid gritty cleaning agents.
Note: Not all finishes are available for all trims. Refer to specification sheet for availability.
© 2008 Philips Group
Flange Options
P Polished Flange
5/8" wide integral flange polished and finished to match
the appearance of the interior of the reflector (available
option on most reflector types).
W White Painted Flange
5/8" wide integral flange painted matte white. Standard
trim detail on all reflectors.
Calculite
Standard Finish & Flange Options
CL Clear
Clear is the most specular and
therefore most efficient finish
available. Clear reflectors deliver
maximum photometric performance
but can produce a mirror image of
the interior of the space.
CCZ Champagne Bronze
Champagne Bronze is a semi-
specular finish that softens the
light at the source of the reflector
while providing a warmer reflector
appearance. Light output is slightly
warmer as well.
BK Black
Black is a specular finish that pro-
vides the lowest aperture brightness
possible and significantly reduces
source identification in a ceiling.
WH White
The matte white finish produces
the brightest aperture when illumi-
nated but provides the smoothest
transition to most ceilings when
off. White is available only with a
white flange.
GD Gold
Gold is a specular finish that
provides a pale tint of color for
slightly warming the light output.
Reflector appearance mixes well in
spaces with gold and brass finishes.
CCL Comfort Clear™
Comfort Clear is a slightly diffuse
clear finish, which eliminates irides-
cence and reduces the mirror image
inherent with specular finishes.
CCD Comfort Clear™Diffuse
Comfort Clear Diffuse is a semi-
specular finish that softens the
light at the source of the reflector.
The finish creates a subtle, even
luminance from the reflector cone.
MG
Multigroove trims provide a seam-
less matte black aluminum baffling
that captures stray light for a very
low brightness aperture.
Standard Finish Options
Note: Not all finishes available for all trims.
