Lytespan®Track Lighting System 8629WH
Page 1 o 1 Lytejacks Lytedrops Cable
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details o design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
General Description
Lytedrops hold Style Jacks and plug into Power Jacks. They enclose 20W or
35W T4 12V halogen lamps in an etched glass di user. The 5’ or 10’ one-piece
cable can be field-shortened and hung on a sloped ceiling. Lytedrops plug into a
Power Jack with a locking device. For best results, use 20W - 50W Power
Jacks.
Electrical
Bi-Pin base ceramic socket, accepts 6.35 mm pin spacing capsule lamps (see
above) pre-wired with 10’ 5” on 8629 or 5’ 5” on 8631 electrical cord o 18 ga.
so t stranded cable SF-1 leads with fiberglass braided sleeve and a silicone
outersleeve.
Finish
All painted finishes baked enamel.
Labels
UL; I.B.E.W.
Catalog No Size Finishes Mounting Lamps Use with Power Jack
8629WH 10’ Matte White
8629BK 10’ Matte Black
8631WH 5’ Matte White
8631BK 5’ Matte Black
To all Lytejacks
20W TO 50W
Power Jacks.
T-4 BI-PIN GY 6.35 BASE
TUNGSTEN HALOGEN 12V
20W (LOL NO. 56360)
12V 35W (LOL NO. 56361)
TRACK 8610 WH, 8610BK SURFACE 8611WH, 8611BK
RECESSED 8613WH REMODELERS 8612WH
POINTS 8605WH, 8606WH REMOTE TRANSFORMERS
8608,8609
