Lightolier QVF2SPFOS User manual

ALTER SLIM SURFACE
2’ X 2’ SURFACE FLUORESCENT
1 OR 2 LAMP SURFACE, TT5, 2 1/4” DEEP
MICROPERFORATED MESH LAMP SHIELD
STATIC
Efficiency 52.6%.
Only 2 1/4'' deep.
Swing down microperforated lamp shields for
easy relamping and maintenance.
Alter soft white film on inside of mesh
conceals lamp image and provide balance
between reflected light and direct light.
95% Reflective Alter soft white paint finish.
Specular interior reflector.
One piece body for easy installation.
Easy access to ballast through lamp
compartment.
Optional acrylic drop-down visual element.
MOUNTING METHODS/FEATURES DIMENSIONS
FIXTURE TYPE
JOB INFORMATION:
VOLTS
L95-10
QVF2SPFOS
Swing down optical system for
easy relamping and maintenance
Microperforated mesh lamp shields
Genlyte Thomas Company
2' x 2'

ORDERING INFORMATION Explanation of Catalogue Number Example: QVF2SPFOS2FT120SB
SPECIFICATIONS
MATERIALS: Chassis constructed from die formed
20 gauge cold rolled steel. Reflectors - 95% reflectance baked white
acrylic matte paint finish. Soft white acrylic film on inside of lamp shield
conceals lamp image.
FINISH: Chassis exterior - phosphate undercoating, baked white acrylic
matte high reflectance paint finish.
ELECTRICAL: Rapid start HPF, thermally protected class “P” ballast (Bi-tube
type). If K.Os are within 3” of ballast use wire suitable for at least 90C.
LABELS: Listed by CSA, UL
QVF2SPFOS
QVF
ALTER SLIM
SURFACE
Surface soft light
optical system
2
FIXTURE
WIDTH
2'
S
CEILING
TYPE
S=Surface
PF
LAMP
SHIELD
PF =Microperforated
LAMP
QUANTITY
1 or 2
LAMP/FIXTURE
LENGTH
(NOMINAL 24")
FT=TT5
120
VOLTAGE
120,277
347
SB
OPTIONS
R =Radio Interface Filter
O =Emergency Lighting
System (for Canada)
N= Emergency
Lighting System
(for U.S.)
BALLAST
BE = 50W Electronic TT5 RS
BR = 40W Electronic TT5 RS
BX = 40W Magnetic TT5 RS
PB = 40W TT5 PowerSpec Dimming*
PC = 50/55W TT5 PowerSpec Dimming*
SB = 40W Generic Electronic TT5
*Not available in 347V.
SHIELD DETAILING
OS =Open slot (no acrylic)
GC =Clear acrylic
GG =Clear acrylic / Green projected color face
GB =Clear acrylic / Blue projected color face
GR = Clear acrylic / Red projected color face
We reserve the right to change, materials and finish in any way that will not alter installed appearance or reduce function and performance.
ALTER SLIM SURFACE
2’ X 2’ SURFACE FLUORESCENT
OS 2 FT
Photometry Model No. : QVF2SPFOS2FT120SB
Genlyte Thomas Company
631 Airport Road, Fall River, MA 02720 - Tel. [phone]
C.F.I. Division of Canlyte, Inc.
525 Education Road, Cornwall, Ontario
Canada K6H 6C7 - [phone]
