Lytecaster Conversion Kit 1910CKU
Page 1 of 2 1002P1 - 1102P1 Retrofit Kit, 1 Lamp, CFL, 120V Elec.
Features
1. Junction Box: 2” x 4” x 3-½” (22cu.in) .032” (#22ga.) galvanized steel.
2. UniFrame™ Mounting System: Tool free mounting attaches securely to
1002P1-1102P1. (.036” (#20ga.)) Galvanized Steel adjustable speed clamp
for positive mounting to frames.
3. Ballast: 120V UL Listed Electronic Ballast, end of lamp life protection,
Class “P” thermally protected, class “A” sound rating.
4. Socket: Four-pin base, molded thermoplastic socket,
prewired with No. 18 AWM leads to ballast.
5. Socket Housing: .036” (#20ga.) Galvanized Steel housing attaches to
reflector trim by spring clip for precise optic alignment.
6. Adaptor Assembly: Male Adapting Screw is tool free and makes converting
to Compact Fluorescent as easy as changing an incandescent lamp. Clip
Socket Bracket to existing deep drawn socket cup.
Labels
UL Listed. Suitable for Damp Location.
1
3
2
4
5
6
10" Flexible
Conduit/Greenfield
22" Flexible
Conduit/Greenfield
4.00
2.00
3.44
Please refer to second page for trim compatibility.
Lightolier is a Philips group brand
Job Information Type:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • A1008
Lytecaster Conversion Kit 1910CKU
Page 2 of 2 1002P1 - 1102P1 Retrofit Kit, 1 Lamp, CFL, 120V Elec.
Conversion Kit 1910CK18U Trim Compatibility
Frame-
In-Kit
Reflector Trims- See Individual Reflector Trim Specification Sheets
1910CK18U
18w Quad/Triple,
GX24q-2 Base
120v - 0.20 amp max
Performance
Cone
Open Downlight Enclosed
Diffusers Wall Washer
1102P1
Anodized Reflector Satin Cone Baffles Cross Blade Cone
1113CFL
1113CDCFL
1144
1144CD
1145
1146
1146CD
1143
1149
1150
1151
1151CD
1108
1108NM
1110
1110NM
1105
1105NM
1105BNM
1176
1171
1179WH
1176WH
1179M1
1170M1
1132 1112
1112NM
1113
1113BK
1113WH
1113CD
1113NM
1113BKNM
1113CDNM
1121
1124
1134
1190
1135
1135WH
1195
1196
1196CD
1185
1185WH
1186
Uniframe Trim Horizontal Reflectors
Clear Lens Open Downlight Fresnel Lens Single Wall Wash Opal Lens Shielded Downlight Crossblade
1101HCLC
1101HCDC
1101HWHC
1101HCL
1101HCD
1101HWH
1101HCLF
1101HCDF
1101HWHF
1101HCLSW
1101HCDSW
1101HWHSW
1101HCLO
1101HCDO
1101HWHO
1101HACB
1101HWHCB
Conversion Kit 1910CK2624U Trim Compatibility
Frame-
In-Kit
Reflector Trims- See Individual Reflector Trim Specification Sheets
1910CK2642U
26w Quad/Triple,
GX24q-3 Base
120v - 0.28 amp max
32w Triple,
GX24q-3 Base
120v - 0.36 amp max
42w Triple,
GX24q-4 Base
120v - 0.47 amp max
Performance
Cone
Open Downlight Enclosed
Diffusers
Wall
Washer
1102P1
Anodized Reflector Satin Cone Baffles Cone
1113CFL
1113CDCFL
1143*
1144*
1144CD*
1145
1149
1146
1146CD
1150
1151
1151CD
1108**
1108NM**
1110**
1110NM**
1105**
1105NM**
1105BNM**
1176**
1171*
1176WH**
1112**
1112NM**
1113**
1113BK**
1113WH**
1113CD**
1113NM**
1113BKNM**
1113CDNM**
1121
1124
1134
1135
1135WH
1195
1196
1196CD
1185*
1186*
1186WH*
Uniframe Trim Horizontal Reflectors
Clear Lens Open Downlight Fresnel Lens Single Wall Wash Opal Lens Shielded Downlight Crossblade
1101HCLC
1101HCDC
1101HWHC
1101HCL
1101HCD
1101HWH
1101HCLF
1101HCDF
1101HWHF
1101HCLSW
1101HCDSW
1101HWHSW
1101HCLO
1101HCDO
1101HWHO
1101HACB
1101HWHCB
Complete fixture consists of Frame-In-Kit, Reflector Trim and Conversion Kit. Select each seperately.
Conversion Kit 1910CK18U Trim Compatibility
Frame-
In-Kit
Reflector Trims- See Individual Reflector Trim Specification Sheets
1910CK18U
18w Quad/Triple,
GX24q-2 Base
120v - 0.20 amp max
Performance
Cone
Open Downlight Enclosed
Diffusers
Wall
Washer
1002P1
Reflector Cone Satin Cone Baffles Basic White
1013CFL
1013CDCFL
1045
1046
1046CD
1012
1012NM
1013
1013NM
1013BK
1013BKNM
1013CD
1013CDNM
1013WH
1008
1008NM
1010
1010NM
1005
1005WH
1005NM
1005BNM
1076
1076WH
1071 1024
1078
1021
1035
1035WH
1085
1095
1096
1096CD
Uniframe Trim Horizontal Reflectors
Clear Lens Open
Downlight Fresnel Lens Single
Wall Wash Opal Lens Shielded Downlight Crossblade
1001HCLC
1001HCDC
1001HWHC
1001HCL
1001HCD
1001HWH
1001HCLF
1001HCDF
1001HWHF
1001HCLSW
1001HCDSW
1001HWHSW
1001HCLO
1001HCDO
1001HWHO
1001HACB
1001HWHCB
Conversion Kit 1910CK2642U Trim Compatibility
Frame-
In-Kit Reflector Trims- See Individual Reflector Trim Specification Sheets
1910CK2642U
26w Quad/Triple,
GX24q-3 Base
120v - 0.28 amp max
32w Triple,
GX24q-3 Base
120v - 0.36 amp max
42w Triple,
GX24q-4 Base
120v - 0.47 amp max
Performance Cone Open Reflector Enclosed Diffusers
1002P1
1013CFL*
1013CDCFL*
1045*
1046*
1046CD*
1024*
1078*
Uniframe Trim Horizontal Reflectors
Clear Lens Open Downlight Fresnel Lens Single Wall Wash Opal Lens Shielded Downlight Crossblade
1001HCLC*
1001HCDC*
1001HWHC*
10 0 1HCL*
1001HCD*
1001HWH*
1001HCLF*
1001HCDF*
1001HWHF*
1001HCLSW*
1001HCDSW*
1001HWHSW*
1001HCLO*
1001HCDO*
1001HWHO*
1001HACB*
1001HWHCB*
*ONLY COMPATIBLE WITH 18W AND 26W LAMPS
