Lytecaster®Recessed Downlighting 2000LVE
Page 1 of 1 3 3/4" Aperture Electronic Low Voltage MR16 Standard Frame-In Kit
9 3/4"
Features
1. Mounting Frame: .036" (#20 ga.) galvanized steel. Accommodates all
ceilings up to 1" thick. Push-in/twist-out rotoclips hold reflector flush to
ceiling.
2. Junction Box: 4" x 3 1/2”x 2", .063" (#14 ga.) galvanized steel. U.L. listed
for maximum of 8 No. 12 ga. 90° C through branch circuit conductors.
Integral cable clamps permit attachment of nonmetallic Romex®or armored
cable without need of additional connectors.
3. Mounting Bars: .059" (#16 ga.) galvanized steel. 13" long bars extend
to 27" with integral nailing tabs. Attaches to wood joist without need of
accessories.
4. Socket Housing: Aluminum with lamp adjustment assembly allows 35°
max. vertical 358° horizontal adjustment. (See reflector trim specification
sheet for specific adjustment.)
5. Socket: Field replaceable. Two pin socket, pre-wired with #18 SF1 leads to
junction box.
6. Transformer: Outboard mounted, electronic, 120V (2000LVE1) or 277V
(2000LVE2) primary, nominal 12V secondary. Removable from below.
7. Thermal Protector: Meets NEC and UL requirements. Insulation must be
kept 3" away from fixture sides and wiring compartments and must not be
placed above fixture in a manner which will entrap heat.
Dimming
Dimming Controls: Use only dimmers specifically designed for use with electron-
ic transformers. Consult Lightolier Controls for more information. Low voltage
luminaires may produce audible sound when used with dimmers, which may be
objectionable in acoustically critical areas.
Options & Accessories
Mounting Bars: 1964 - 20" set of (2)
T-Bar Ceiling Clips: 1956 - set of (4)
Plaster Ceiling Ring: 1959 - 7/8" depth for wet plaster ceilings.
MR16 Socket Replacement: 1975B
Socket for General Electric Turn and Lock (TAL) MR16 Lamp: 1975TAL.
Color Filters: AF2 Series
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Frame-In Kit Reflector Trims — See Individual Reflector Trim Specification Sheets
Open Downlight Adjustable Enclosed
Aperture Cone Satin Cone Baffles Slot Pinhole Mini Swivel Eyeball Wet Location
2000LVE1 2012 2008 2005 2006 2011 2025WH 2022LV 2090LV
120V- 0.67A Max 2012NM 2008NM 2005WH 2026WH
2013BKNM 2010 2005BNM
2000LVE2 2013CD 2010NM 2005NM
277V- 0.27A Max 2013CDNM
2013NM
2013BK
2013WH
2013
2013WD
2013WDP
