Lightolier MD4GPSVA2SB4SB User manual

Features
• Four lighting functions with intregral ambient, reading, examination
and nurses night light.
• Precise light control for glare free patient environment.
• Installs as a one-piece unit.
• Recessed or surface mounted to ceiling which eliminates damage to
fixture from hospital equipment attached to bed.
• 6-7/8" deep.
• All lamps are enclosed.
•
All twin tube T5 lamps are accessible for relamping without tools.
• All ballasts accessible thru louver compartment.
• Optional low voltage electronic sequential switch mounted in fixture
for ambient and reading light controlled with pillow speaker
(optional by others).
• Optional 50 watt or LED night light.
• Meets NYC Code requirements. Chicago Plenum requirements
available.
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
6/07
MD*42' x 4' Recessed or Surface MD4GPSVA2SB4SB
Page 1 of 4 Multi-Function Patient Lighting
Lightolier aGenlyte company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 AirportRoad, Fall River,MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
©2007 a Genlyte company Section 8/Folio R40-11 Rev. B
Ssurface
G
exposed T-grid ceiling
Wall
48"
Securefixture
(4 places)
Mounting Methods Dimensions
1. Reading light with low iridescence anodized semi-specular aluminum reflector.
2. Extruded aluminum lamp baffle.
3. Ambient light with low iridescence anodized secular aluminum reflector.
4. Examination light with specular 36 cell aluminum louver with virgin acrylic overlay (illustrated).
5. Twin tube T5 lamps (6).
6. Clear acrylic lens.
7. Prismatic virgin acrylic overlay.
8. Ballast compartment accessible by opening louver and reflector.
2" x 3" access plate with (2) 7/8"
dia. K.O.s (Ambient/Reading)
2" x 3" access plate with (2) 7/8"
dia. K.O.s (Examination) Tabs for wire
supports
(4 places)
Mounting holes (8)
11-7/8"
11-7/8"
14"
4-7/8"
2-1/32"
19-11/16" 19-11/16"
4-5/16"
47-3/4"
2-1/32"
23-3/4"
12-3/4"
4"
1
2
3
4
5
67
48" (1219mm)
6-7/8"
(175mm)
6
8
Ceiling
Wall
Now available in 3 styles
(Reflectors always semi-specular)
Traditional with specular louver (PS option)
(For multiple patient room)
White louver and horizontal surfaces to blend with ceiling (FF option)
(Reflectors always semi-specular)
All components white (AW option)
(For single patient room)
Wall Angle
or T-bar
(by others)
Acoustical Tile
(by others)
Style 1 shown

→
AMBIENT LIGHT
Ambient Light
Indirect illumination from wall directly behind patient provides glare-free lighting..
No direct glare to patient. (Light is directed towards wall.)
No direct glare to patient's visitor.
No direct glare to adjacent patients. (3 footcandles maximum on wall behind adjacent patients bed.)
Reading Light
Eliminates reflected glare from reading material (over shoulder illumination).
No direct glare to patient or visitors. (7 footcandles maximum at head of bed. 15 footcandles maximum at foot of bed.)
Controls light directly onto patient's bed.
No reading light spill-over to adjacent bed (2 foot/candles maximum at head of adjacent patient's bed.)
F OOTCANDLES ON BED (with Specular Louver)
Totals of ambient, reading and examination lights .
Examination Light
Excellent color rendition. (Biax Type lamp.)
Wired for independent switching (1 or 2 circuit).
Optional louver or lens frame.
Concealed hinging and latching.
Numbers in parenthesis ( ) are total footcandle
level of ambient and reading lights only.
70 82 82 102 100 70 48
(11) (12) (15) (45) (43) (20 (10)
75 82 86 107 102 72 48
(11) (12) (15) (45) (43) (20) (10)
70 82 82 102 100 70 48
(11) (12) (15) (45) (43) (20) (10)
ADJACENT
MD*4
ON
MD*42' x 4' Recessed or Surface MD4GPSVA2SB4SB
Page 2 of 4 Multi-Function Patient Lighting
LIGHTED
ZONE
SHIELDED
ZONE
LIGHTED
ZONE
3"→←
6" →
←12"
BED
↑
↓
12"
SHIELDED
ZONE
45 110 140 110 45 14 4 2 1 1 1 1
44 83 95 83 44 19 7 3 2 2 1 1
30 45 50 45 30 16 8 4 3 3 2 1
16 20 22 20 16 11 7 4 3 3 2 1
79 974322 11
3 3221 1
1211
OFF
Illumination at the reading task range 50-60 footcandles
READING LIGHT
ON
ADJACENT
MD*4
OFF
FOOTCANDLES ON BEDS
WALL
3"↓
6"
BED BED 12"
↑
↓
↓3"
6"
12"
↑
↓
↑
↓
222222111111
333332221111
6 7 7764332211
33 38 39 38 33 23 16 12 9 5 3 2
30 38 38 38 30 23 15 12 8 6 3 2
14 15 15 15 14 11 9 7 5 4 2 2
555555442211
Illumination at the
reading task ranges
50-60 footcandles.
LIGHTED
ZONE

MD*42' x 4' Recessed or Surface MD4GPSVA2SB4SB
Page 3 of 4 Multi-Function Patient Lighting
Nurse's Night Light (Optional NL or LD)
Lights night stand between beds.
Field adjustable for either right or left side of patient's bed.
No glare to any patient.
Wired for independent switching.
Options Pillow speaker (by others)
MD*4’s optional low voltage (1-3 volts) sequential switch mounted in the fixture is listed in com-
pliance with UL 544 for medical and dental equipment. Two red wires coming from the fixture can
be wired to a wall receptacle (by others) for use with that manufacturer's pillow speaker. The pil-
low speaker is used to control the television, call the nurse and control the lighting. To control the
lighting it should be specified to have a normally open contact switch.
Pressing this switch on the pillow speaker the first time, turns the ambient light on; pressed a
second time, turns the reading light on and the ambient light off; pressed a third time, turns both
the ambient and reading lights on; pressed a fourth time turns both lights off. Pressing the button
again repeats the cycle.
Should the patient's bed be rolled away from the wall, the pillow speaker will simply pull free
from the wall receptacle avoiding any damage.
TAMPER RESISTANT/GERM SHIELD
GermShield:Ideal for psychiatric wards and
germfree environments. Fits lay-in grid
ceiling systems with 15/16" maximum ceiling tee
face. The heavy duty welded extruded aluminum
frame with clear 1/8" thick polycarbonate lens is
fixture to ceiling system sealed with a heavy duty
gasket. Request Folio R40-15 REV.A.
Nurse's night light.. Suffix: NL (Lamp included)
Specular anodized aluminum mirror,
adjusts to left or right side of bed
120V medium base narrow spot,
50W reflector lamp
Night Light:120V, 3 watt, cool white LED (50,000
hours life) (supplied with fixture). Suffix: LD
CAN BE SET TO
LEFT OR RIGHT
SIDE OF BED
Ballast Compartment accessible by opening
Louver and Reflector
Tamper Resistant/Germ Shield
Sequential Switch. Suffix: SW
Night Light

MD*42' x 4' Recessed or Surface MD4GPSVA2SB4SB
Page 4 of 4 Multi-Function Patient Lighting
Job Information Type:
Lightolier aGenlyte company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
©2007 a Genlyte company Section 8/Folio R40-11 Rev. B
ORDERING INFORMATION
Explanation of Catalog Number. Example: MD4GPSVA2SB4SB120SW
MD
MD*4
Recessed or
Surface,
Multi-function
Patient Light
G
Ceiling
Type:
Same Unit
May Be Used
For: Grid (lay-in)
T-bar or
Surface
Mounted
Louver/
Lens Frame:
AW = All Components
White (For single
patient room)
FF = White Louver
and Horizontal
surfaces to blend
with ceiling
PS = Traditional with
Specular Louver
(For multiple
patient room)
2
Lamp
Quantity:
(Ambient/
Reading)
2Lamps
(Total)
Options:
Add appropriate
Suffix to Catalog
No. i.e. (GLR)
Specifications:
Materials: Chassis parts aredie-formed 20 gauge steel.
Louver (examination light) – Pre-anodized aluminum Coilzak®or equal.
Reading light –Extruded aluminum lamp baffle with clear extruded acrylic
shields and is removable without tools.
Ambient light –Clear acrylic lens that rotates open for easy relamping.
Reflectors (Ambient and Reading Lights): Low iridescence specular pre-
anodized aluminum standard.
Finish: Cavity (Examination Light) – Powder coated flat white or black
polyester enamel, 89% reflectivity. Five stage rust prevention undercoating
process. Chassis exterior –post painted white baked polyester powder.
Louver (examination light) PS =low iridescence specular
pre-anodized aluminum. Comes with a virgin acrylic overlay FF =flat white
baked polyester powder louver. AW =flat white baked polyester powder
louver. VA =.095" nominal thickness prismatic virgin acrylic overlay.
Specifications (continued):
Electrical:Rapid start HPF, SB (Biax type) thermally protected class "P" ballast
C.B.M. certified by E.T.L. If K.O. is within 3" of ballast, use wire suitable for at
least 90°.
Labels:I.B.E.W. UL and ULc Listed.
This product may have a mercurycontaining lamp. Manage in accordwith
Disposal Laws. See: www.lamprecycle.org
Options/Accessories
Access Plates:Top wiring access plate is shipped with fixture as standard.
When access plates are required in advance for wiring convenience, specify
separately. Catalog Number: ACP.
Drywall Kit or Plaster Ceiling:Order Catalog Number: FK92X4.
Request Folio OA30-10 Rev. A.
Electronic Sequential Switch (Low Voltage): Switch factory mounted in
fixture for ambient and reading light convenience (controlled by pillow switch,
by others). Suffix: SW.
Nurses Night Light:120 volt medium base, narrow spot, 50W reflector lamp
with specular anodized mirror,field adjustable to right or left side of patient's
bed (Lamp included). Suffix: NL.
Night Light:120 volt, 3 watt, cool white LED (50,000 hours life). Suffix: LD.
Fusing: Internal fast-blow fusing. Suffix: GLR.
Internal slow-blow fusing. Suffix: GMF.
Radio Interference Filter: To order one RIF per fixture; Suffix: R.To order one RIF per
ballast; Suffix: B.
Electrical/Wiring Options:Consult factory.
Louver
Overlay/Lens:
VA =Virgin Acrylic
.095" Nominal
Thickness
Overlay
(standard) Ballast Type:
(Ambient Reading)
<20THD <10THD
1-2 Lamp Elec. TT5 SB* IB**
(40 Watt)
1-2 Lamp Elec. TT5 –PR**
(40 Watt)
LOL Dimming TT5 PB –
**Instant Start Standard
**Program Start
NOTE:
For TT5 UNV,you must use IB Ballast
Ballast Type:
(Examination)
<20THD <10THD
1-3 Lamp Elec. TT5 X3* I3**
2-2 Lamp Elec. TT5 SB* IB**
2-2 Lamp Elec. TT5 – PR**
(40 Watt)*
LOL Dimming TT5 PB*–
**Instant Start Standard
**Program Start
NOTE:
For TT5 UNV,you must use IBBallast
Voltage:
120 or 277
4
Fixture
Size:
2' x 4'
Lamp
Quantity
3= 3 Lamp
4= 4 Lamp
