E2 Series Emergency Lighting E2
Page 1 of 2 6 and 12 Volt 36 to 72 Watts Thermoplastic Housing
Lightolier is a Philips group brand
The E2 Series combines high wattage output with an attractive housing. Available with up to 72 watts, the E2 Series provides powerful emergency lighting suitable for the
Side View
Front View
16.5”
(41.9 cm)
5.5”
(14.0 cm)
4.8”
(12.2 cm)
Features
1. Illumination: Includes two high performance lamp reflector systems inte-
gral to the housing. Each lamp reflector system can be adjusted 180° verti-
cally and 90° horizontally.
2. Housing: Constructed of impact resistant, UL 94 V-0, 5VA white or black
thermoplastic. Easy to install with its snap-together backplate and housing.
3. Electronics: 120/277 VAC dual voltage input with surge-protected, solid-
state circuitry. Charging system is complete with low voltage disconnect, AC
lockout, brownout protection, AC indicator lamp and test switch.
4. Battery: Maintenance free, sealed lead calcium battery has an estimated
service life of 5 years, and an operating temperature range of 65°F (19°C) to
85°F (30°C). Maintenance free, sealed nickel cadmium battery has an esti-
mated service life of 10 years, and an operating temperature range of 20°F
(-7°C) to 95°F (35°C).
5. Input Power Requirements: 120 VAC - 0.36 amps (6v, 36w), 0.11
amps (12v, 36w); 277 VAC - 0.10 amps (6v, 36w), 0.04 amps (12v, 36w)
Code Compliance
UL 924 listed, UL damp location listing on select units only
Options
SD = Self-Diagnostics 4
SDTD = Self-Diagnostics with Time Delay 4
V= Voltmeter (not available with Ammeter (A) option) 2
A = Ammeter (not available with Voltmeter (V) option) 2
LCK1 = Line Cord (6’, 120 VAC field installed)
F1 = 120 VAC Fuse
Options (continued)
F2 = 277 VAC Fuse
P1 = 120 VAC Power Switch
P2 = 277 VAC Power Switch
DC = DCP Power Switch
ST = Special Input Transformer (specify voltage and frequency)
DL = UL Damp Location Listing
Multiple option configurations may void UL listing. Consult factory for specifics.
Accessories
WG5 = Wire Guard
PCS1 = Polycarbonate Vandal Shield
How to Specify:
E2 1
SERIES VOLTAGE BATTERY/ LAMP HOUSING
WATTAGE TYPE 1COLOR
W = White
B = Black
6V
T9 = Tungsten 9W
H7 = Halogen 7W
H10 = Halogen 10W
H12 = Halogen 12W
12V
T9 = Tungsten 9W
T12 = Tungsten 12W
T18 = Tungsten 18W
H12 = Halogen 12W
H20 = Halogen (MR16) 20W
Lead Calcium
36L = 36W Unit 3
50L = 50W Unit
72L = 72W Unit
Nickel Cadmium
50N = 50W Unit 3
1 = 6V
2 = 12V 3
E2 = Thermoplastic
Emergency Lighting Unit
NOTES:
1) Selected lamp wattage cannot exceed unit output
rating.
2) Not available for use with SD and SDTD options.
3) Selected models are available with damp location
listing option.
4) Not available for use with DL option.
Complete Fixture consists of unit and two lamp reflector systems. Select options and accessories below. For additional lamp heads, see RH Specification
sheet.

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • E0308
E2 Series Emergency Lighting E2
Page 2 of 2 6 and 12 Volt 36 to 72 Watts Thermoplastic Housing
Lightolier is a Philips group brand
HORIZONTAL
VERTICAL
�
HORIZONTAL
VERTICAL
60
50
40
30
20
10
0-20 -5 0510
.1
.5
1
.2
.3
70
80
-10-15 15
60
50
40
30
20
10
0-5 0510
.1
.5
1
.2
.3
70
80
-10-15
80
60
40
20
0-5 0 10
.1
.5
1
.2
.3
100
120
-10 20
80
60
40
20
0-5 0 10
.1
.5
1
.2
.3
100
120
-10 20
HORIZONTAL
VERTICAL
80
60
40
20
0-5 0 10
.1
.5
1
.2
.3
100
120
-10
140
-15 5
80
60
40
20
0-5 0 10
.1
.5
1
.2
.3
100
120
-10-15 5
Lamp Head Photometrics
T9 - 6 Volt, 9 Watt, Tungsten H7 - 6 Volt, 7 Watt, Halogen
H12 - 6 Volt, 12 Watt, Halogen
Warranty
Electronics: 3 years
Battery: 1 year full, 4 years pro-rata (lead calcium);
5 year full, 5 years pro-rata (nickel cadmium)
H10 - 6 Volt, 10 Watt, Halogen
* Per NEC Specifications
Unit Battery Capacity
DC Suggested Watts to 871⁄2
Voltage Unit Lamp Head of Rated Voltage*
11⁄2 hrs. 2 hrs. 4 hrs. 8 hrs.
6 E2136L T9 36.0 27.0 14.0 7.2
6 E2150L T9 50.0 37.5 19.0 10.0
6 E2172L T9 72.0 56.5 28.5 15.0
6 E2150N T9 50.0 37.5 19.0 10.0
