LIGMAN Mic 3 Manual

15
300
240
170
22
37
Ø114x150
310
80
4,000
1,000
963
1,195
INSTALLATION AND SERVICE MANUAL
Product drawing (dimensions)
TOOL
For Installation of Mic 3 medium indirect light column LED.
Model. MI-21071 and MI-21111
21
54
L N
4,5
IP65 IK04 CLASS I
MOUNTING DETAIL
SPIGOT POST TOP
3
v+
v-
6
20 30
CABLE SIZE : 3x1.0mm ²
Torque :4.5Nm.
Windage Area :0.67m².
Weight : 33.9Kg.
Torque :4.5Nm.
Torque :2.0Nm.
Torque :2.0Nm.
Torque :3.0Nm.
LigmanLighting
Technical amendments and modifications techniques reserved.
■LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■LIGMAN luminaires are designed to conform IEC 60598 2-1 standard.
FM-TS-13-1/13-03-2561/REV.4
M MI-21071/12/12/16/REV.2
1/2
