Lilliput T5 User manual

1

1
Important Safety Instructions:
Please read User Guide before using this product.
Please keep User Guide for future reference.
Please read the precaution to prevent possible danger and loss of property.
Precaution:
Please do not place the display screen towards the ground.
Please avoid heavy impact or drop onto the ground.
Please do not use chemical solutions to clean this product. Please wipe with a
clean soft cloth to maintain the brightness of the surface.
Please do not block any vent hole.
Please follow the instructions and trouble-shootings to adjust the product. Other
improper adjustment may result in damage. Any further adjustment must be
performed or conducted by a qualified technician.
Please unplug the power and remove the battery if long-term no-use, or thunder
weather.

2
Contents
1. Main Features......................................................................................... 3
2. Production Description........................................................................... 4
2.1 Back Housing.................................................................................. 4
2.2 DV Battery Mount Plate.................................................................5
3. Menu Setting...........................................................................................6
3.1 Shortcut Touch Gesture.................................................................6
3.2 Menu Operation.............................................................................8
3.2.1 Peaking Function..................................................................8
3.2.2 Color Adjustment...............................................................10
3.2.3 LUT......................................................................................11
3.2.4 Display................................................................................ 12
3.2.5 Audio.................................................................................. 14
3.2.6 Marker................................................................................15
3.2.7 Setting................................................................................ 16
4. Product Parameters.............................................................................. 17
5. Accessories............................................................................................18
6. Trouble Shooting...................................................................................19
7.Warranty................................................................................................ 19
7.1. Repair Procedure and Terms...................................................... 19
7.2. Free Repair Exclusions................................................................ 20

3
1. Main Features
Support HDMI 2.0 4K 60 HZ input
Support Touch Function
Peaking (Red/Green/Blue/White)
False Color( Off/Default/Spectrum/ARRI/RED)
Check Field( Off/Red/Green/Blue/Mono)
LUT : Camera LUT/ Def LUT/ User LUT
Scan: Aspect/Zoom/Pixel to Pixel
Aspect(16:9/1.85:1/2.35:1/4:3/3:2/1.33X/1.5X/2X/2XMAG)
H/V Delay Support (Off/H/V/ H/V)
Image Flip Support(Off/H/V/ H/V)
HDR Support(Off/ST2084 300/ST 2084 1000/ST 2084 10000/HLG)
Audio Out Support(CH1&CH2/CH3&CH4/CH5&CH6/CH7&CH8)
Aspect Mark(Off/16:9/1.85:1/2.35:1/4:3/3:2/Grid)
Safety Mark(Off/95%/93%/90%/88%/85%/80%)
Mark Color: Black/Red/Green/Blue/White
Marker Mat.( 0ff/1/2/3/4/5/6/7)
HDMI EDID：4K/2K
Color Bar support range: Off/100%/75%
User-definable button FN function can be set, default :Peaking
Color Temperature: 6500K, 7500K, 9300K, User.

4
2. Production Description
2.1 Back Housing
1) Menu button: when use button, it can be used as the option to determine
key.
2) " “Left button
When no menu, once press " " button, it will display shortcut menu:
Brightness, Contrast, Color, Tint, Backlight, Volume. After selecting one of
the options, press " " button to decrease the value.
3) " "Right button
When no menu, once press " " button, it will display shortcut menu:
Brightness, Contrast, Color, Tint, Backlight, Volume. After selecting one of
the options, press " " button to increase the value.
4) Exit Button
5) FN Button: default as peaking
6) : Power Button
Short press: power button
Long press: touch switch
7) Power Indicator: power on is green
8) Power output: DC 8V/1A
9) Earphone Jack

5
10) USB: for LUT load and update
11）HDMI 2.0 Input
12）DC 7-24V Input
2.2 DV Battery Mount Plate
First put battery into the plate,
Please slide LP-E6 battery to the left,
Please slide F970 battery to the right.
PUSH Botton:
Press the “PUSH “button to remove the battery.
Model NP-F series for battery of SONY DV:
DCR-TRV series, DCR-TRV E series, VX2100E PD P series, GV-A700,
GV-D800 FD/CCD-SC/TR3/FX1E/HVR-AIC, HDR-FX1000E, HVR-Z1C,
HVR-V1C, FX7EF330, etc.
Model LP-E6 for battery of Canon DSLR:
5D MarkII/5DMarkIII/EOS7D/EOS60D, etc.

6
3. Menu Setting
Before setting the functions, please make sure the device is connected correctly.
3.1 Shortcut Touch Gesture
Left slide up and down: back light control.
Right slide up and down: volume control.
Slide left and right: activate the shortcut menu

7
Two-finger zoom: no menu display, arbitrary zoom-in and zoom-out of image, and
support moving image when zooming-in.
Center slide up and down: activate or hide the menu
Power Button:
Short press: power button
Long press: touch switch

8
3.2 Menu Operation
3.2.1 Peaking Function
-Peaking
Use this item to activate or deactivate the peaking function.
- Peaking Color
Select one of the peaking colors: [Red], [Green], [Blue], [White], [Black].
- Peaking Level
Use this item to adjust the level of peaking from 1-100. The higher peaking level is,
the more obvious peaking effect is.
-False Color
Use this item to activate or deactivate the false color function.
When activated, [Default], [Spectrum], [ARRI], [RED] are for optional.
-False Color Table
Use this item to activate or deactivate the false color table. The range of the false

9
color table is between 0-100 IRE.
- Exposure
Use this item to activate or deactivate the exposure function.
Note! When activated, exposure works if the input signal exceeds the designated
exposure level.
- Exposure Level
Use this item to adjust the level of exposure among 1-100.
- Histogram
Use this item to activate or deactivate histogram.
- Check Field
Select one of check field modes: [Off], [Red], [Green], [Blue], [White].
