LIM INFINITE SOCKET TT-S User manual

INFINITE
SOCKET
TM
TT S
PATIENT INSTRUCTIONS

Contents
About the Infinite Socket™TT-S
Legend
Putting on your socket
Adjusting your socket
Removing your socket
Maintaining your socket
Troubleshooting
Notes
3
5
6
10
11
12
13
14
2

Welcome
Congratulations on
becoming a #LIMlegend!
The following steps will
guide you through the use
of the Infinite Socket™TT-S.
For additional support or
questions, please contact
your prosthetist.
3

The Infinite Socket™TT-S
is a human-inspired
transtibial socket
designed for daily
adjustments. It optimizes
knee flexion without
sacrificing performance or
aesthetics, providing new
levels of force transitions
that dynamically conform
with the patient’s every stride.
Introduction
4

Legend
Lace Housing
Lace
Release Button
Suspension
Mechanism
Note: For suction and seal in
suspension, the release button
will be on the side of your socket
Cover Attachment
Rear Upper Pad
Peninsula
5
BOA®Fit System
optimized by
Click Medical™

Loosen the back BOA®dial
by pulling it away from the
socket.
Pull the upper rear pad away
from socket.
Note: An audible click occurs when
the BOA®dial disengages.
Putting On Your
Socket
6

Make sure that the green
ring is placed over the pin on
your liner.
After putting on your liner,
insert your limb into the
socket (seated or standing).
Listen for a minimum of 3
clicks.
Note: This will ensure engagement
of the lock.
Putting On Your
Socket
Pin Lock Suspension
Note: The pin should be in
a straight line with limb
Example of a pin liner
7

Putting On Your
Socket
Seal In Suspension
After putting on your liner,
apply alcohol based lubricant
on the liner seals and on the
inside of the socket.
Insert your limb into the
socket (seated or standing).
Press the valve button on the
side of the socket to allow
your limb to sink deeper if
needed.
Example of a seal in liner
8

Putting On Your
Socket
Sleeve Suspension
After putting on your liner,
insert your limb into the
socket (seated or standing).
Roll your suspension sleeve
over your socket and thigh.
If a valve is present, press
the valve button on the side
of the socket to allow your
limb to sink deeper into the
socket if needed.
Example of a suspension sleeve
9

Note: The socket may need to be adjusted
multiple times throughout the day based
volume changes or activity. For example,
tightening may be required as your
activity level increases or you need to
carry any additional weight.
Adjusting Your
Socket
The Closure System
Push the BOA®dial towards
your leg and listen for a click.
Rotate the BOA®dial by
spinning the dial in a
clockwise direction.
Continue turning the BOA®
dial until the socket fits
snugly around your limb.
A good starting point is to
have less than a finger’s
width allowed to fit between
the back of the socket and
your limb.
To release the closure, pull
the BOA®dial away from your
leg.
Photo courtesy of Click Medical™
10

Removing Your
Socket
Loosen the closure system by
pulling the BOA®dial away
from your limb.
Push the pin lock
button in the front
of socket.
Hold the button and
remove your limb
until it is clear from
the lock.
Pin Lock Seal In Suspension Sleeve
Push the valve
button on the side
of the socket.
Hold the valve while
removing your limb
from the socket.
Roll your suspension
sleeve down.
Remove your limb
from the socket.
11

Maintaining Your
Socket
The socket can be cleaned
with gentle soap and
water.
Avoid using alcohol based
cleaners on the exterior of
the socket.
If salt water contacts
the socket, make sure to
immediately rinse with
fresh water.
Remove the cover using
2.5 mm hex key.
The cover can be machine
washed on cold.
Air dry.
Cleaning
Cover care
12

Troubleshooting
Problem Possible Solution(s)
Feeling like walking
on the end of your
limb
• Turn the BOA®dial clockwise
• Remove the socket, add a limb sock
• Remove the socket, put your liner on again to ensure the pin
orientation is correct
• If unresolvable, see your prosthetist
Severe pain or skin
breakdown on the
limb
• Discontinue usage and see your prosthetist
Socket rotation • Turn the BOA®dial clockwise
• Remove the socket, add a limb sock
• Make sure the socket is donned correctly
• If unresolvable, see your prosthetist
• Your limb may be swollen; continue to wear a liner and elevate limb
• Make sure the tensioning system is released and posterior pad is
pushed back
• If unresolvable, see your prosthetist
Socket feels loose or
is pistoning
• Turn the BOA®dial clockwise
• Add a limb sock
• If unresolvable, see your prosthetist
Clicking sounds • Make sure you are fully engaged in the lock (if wearing pin system)
• Make sure the green ring is on the pin
• If wearing Seal In, EV, or Suspension Sleeve systems, see your
prosthetist
• If unresolvable, see your prosthetist
Removal issues • Cannot release the pin lock: Push your limb into the socket while
simultaneously pressing the release button
• Cannot release BOA®dial: Re-engage, turn clockwise, then
disengage
• Other systems or if unresolvable: see your prosthetist
Can’t get all the way
into the socket
13

Notes
14
