Lincat EB3F Operating instructions

IS339 ECN3539
User and Installation Instructions
Electric Auto-Fill Water Boilers
EB3F, EB4F, EB6F, EB6TF

IS339 ECN3539
2
Dear Customer
Thank you for purchasing this Lincat product.
With correct use and careful maintenance as described in these instructions,
your Lincat product will give years of trouble free use.
We produce over 450 different items of catering equipment and our range is
constantly being extended and improved. Find out more about Lincat
products from your local distributor or direct from us.
CONTENTS
CONTENTS .....................................................................................................2
SAFETY INFORMATION.................................................................................3
DELIVERY CHECKLIST..................................................................................3
TECHNICAL SPECIFICATION ........................................................................4
ACCESSORIES...............................................................................................4
INSTALLATION ...............................................................................................4
CLEANING.......................................................................................................8
MAINTENANCE...............................................................................................9
DIAGNOSTIC MESSAGES............................................................................11
SERVICE INFORMATION .............................................................................11
GUARANTEE.................................................................................................12

IS339 ECN3539
3
SAFETY INFORMATION
To prevent injury to yourself or your staff, and to avoid
damaging the product, please read and follow the safety
precautions below before setting up and using the unit:
•Remove all plastic coatings and clean the unit before use.
•Ensure that the electrical supply cable is not damaged. If it is,
it must be replaced by Lincat Ltd or by qualified personnel.
•Always disconnect the unit from the electricity supply before
servicing.
•The unit must be earthed.
•Do not try to modify this unit.
•Never clean the unit with a water jet or steam cleaner.
•Inform staff that the surfaces will become hot.
•Keep these instructions in a safe place near the unit for future
reference.
DELIVERY CHECKLIST
If an item is missing please contact your dealer immediately.
•Electric water boiler
•Drip tray and insert
•White water inlet hose with ¾” BSP connection
•User instructions
•Guarantee card
•Filterflow badge
•Sample of descaling agent

IS339 ECN3539
4
TECHNICAL SPECIFICATION
Model EB3F EB4F EB6F EB6TF
Width mm 290 290 455 455
Depth mm 465 465 465 465
Height mm 655 655 655 655
Power Rating kW 3.0 4.5 6.0 6.0
Net weight net kg 13 13 17 17
Ambient temperature
o
C 5 to 30
Water inlet pressure Bar 1 to 8
ACCESSORIES
Wall mounting kit for EB3F, EB4F BR49
Wall mounting kit for EB6F, EB6TF BR50
Replacement filter cartridge FC02
INSTALLATION
The boiler must be installed on a horizontal surface in a location where it can
be supervised by trained personnel.
Inform all users that the surfaces may become hot.
For safety regulations the plug or means of disconnection must always be
accessible.
Connecting to the electricity and water and waste supplies
The boiler must be earthed.
Check that the voltage of your electricity supply corresponds to the voltage
shown on the serial plate.
EB3F
The boiler is supplied with a 13 amp plug. If replacing the plug, connect the
terminals as follows:
•Green and yellow wire Earth E
•Blue wire Neutral
N
•Brown wire Live L
For safety regulations the plug or means of disconnection must always be
accessible.

IS339 ECN3539
5
EB4F
The boiler is supplied with a bulkhead cable connector and must be fitted with
2.5mm
2
3-core cable.The supply end of the cable must be fitted with an all-
pole disconnection isolator switch with a minimum of 3mm contact separation.
For safety regulations the means of disconnection must always be accessible.
EB6F / EB6TF
The boiler is supplied with a bulkhead cable connector and must be fitted with
4mm
2
single or 3-phase cable. The supply end of the cable must be fitted with
an easily accessible all-pole disconnection isolator switch with a minimum of
3mm contact separation. For safety regulations the means of disconnection
must always be accessible.
Water supply and waste connection: all models
Connect the supplied white water inlet hose to the inlet connection point on
the base of the boiler and the other end to the mains water supply via an
accessible isolating tap with a ¾” BSP thread.
The drip tray has a large capacity but if required it can be connected to a
waste water outlet using a ½” bulkhead connector (not supplied)
If cables are required to exit at either side of the boiler the thinner section
between the moulded feet may be cut away using a junior hacksaw.

IS339 ECN3539
6
1 Control panel
2 Water dispensing tap
3 Filter cartridge
4 Drip tray and cover
5 Serial plate

IS339 ECN3539
7
OPERATION
First use
1 Switch on the mains water supply and the electricity supply
2 Leave the boiler for 30 minutes to allow it to fill completely
3 Drain off approximately 5 litres of water to remove any loose carbon
particles from the filter.
Regular operation
The boiler starts automatically when the mains water supply is turned on. After
a short delay it fills with water and heats up. During the heating cycle small
quantities of water are added to ensure that hot water is always available at
the tap.
The water temperature, screen backlight and screen contrast can be adjusted
as required.
The boiler is designed to be left permanently switched on: it is only necessary
to turn it off for descaling or maintenance.
Changing water temperature, screen backlight and contrast.
1 Turn power off and on again. The Filter Flow screen is displayed
2 Press and hold the power button until the software version is displayed.
Press Fn and the temperature will be displayed
3 Press the power button to cycle through the values 70 to 96 deg C.
Press the Fn button to select the required value
4 The backlight adjustment screen is displayed next
5 Press the power button to cycle through the values 1 to 25. Press the Fn
button to select the required value
6 The contrast adjustment screen is displayed next
Power /
Standby button Fn (Function)
button

IS339 ECN3539
8
7 Press the power button to cycle through the values 35 to 60. Press the
Fn button to select the required value
8 Press the power button to exit.
Standby
If the boiler is to be left unused for a long period, the element can be turned
off by pressing the power button.
Filter replacement
The FILTER display shows the estimated remaining life in the current filter
cartridge. When the filter needs replacing, a reminder message is displayed.
This is followed by the change filter screen.
The boiler can be used without a filter but scale may build up more quickly
and water taste may be affected.
Replace the filter as follows:
1 Twist the base of the filter 90 degrees to the left and carefully lower the
filter cartridge out of the unit. It will contain a small amount of water
2 Remove the black cap and place on the new filter
3 Insert the filter fully into its recess and twist to the right to lock in place
4 Press and hold the “Fn” button for 5 seconds to reset the filter life
monitor
5 Drain off approximately 5 litres of water to remove any loose carbon
particles from the filter

IS339 ECN3539
9
CLEANING
Clean the external surfaces of the unit regularly to maintain hygiene.
Empty the drip tray regularly.
Wipe the dispensing tap daily to remove any limescale deposits and check
that the water outlet is clear.
Wipe the unit down with a damp soft cloth.
Do not allow excess water to run into the unit.
Do not use abrasive creams or scourers.
MAINTENANCE
Drip Tray: Slide tray out to remove and empty
Filter: Twist to the left and remove. See section on filter
replacement.
Descaling
The descaling procedure must be performed by trained personnel as it
requires the removal of panels from the boiler and access to live
electrical components.
The boiler should be descaled regularly to maintain efficient operation and
water quality. The frequency depends on the hardness of the local water and
timely replacement of the filter.
The boiler is best descaled at the end of the working day to allow the
descaling agent several hours to work. Lincat recommends its own descaling
agent, available from Lincat spares department, part code MS19.
1 Wear protective clothing
2 Isolate the boiler from the electricity supply
3 Turn off the power and let the water cool to approximately 60ºC to avoid
injury
4 Using a 3mm Allen key, remove the screw on the top of the boiler
5 Remove the insulation on top of the tank, then unscrew and remove the
tank lid
6 Add the descaling agent a little at a time as some types can cause hot
water to erupt. Always follow the manufacturer’s instructions
7 Replace the tank lid and outer lid, and attach an “Out of Use” notice to
the boiler to prevent use during descaling
8 Turn on the electricity and allow the boiler to heat and run normally for
approximately 30 minutes
9 Isolate the boiler and allow the water to cool

IS339 ECN3539
10
10 Remove the outer and tank lids again and inspect the tank and level
sensor housings for scale deposits. If necessary repeat the descaling
process
11 Drain and flush all descaling agent from the tank completely as follows
i Remove the two screws behind the drip tray that secure the lower
front panel
ii Connect a hose from the overflow pipe to a bucket and turn the
service valve to drain the remainder of the water from the tank
iii Flush out the tank with clean water
iv When empty shut the valve and replace the cover
12 Replace the tank lid, ensuring that the gasket is sealing the top of the
tank correctly
13 Fit the outer lid and turn on the boiler.

IS339 ECN3539
11
DIAGNOSTIC MESSAGES
The control panel displays messages and information that can help with fault
diagnosis.
Before calling for service, draw off a litre of water, clear the fault code by
pressing the Fn button and turn the boiler off and on again at the mains
supply. If the fault persists call service for advice.
Message Displayed Possible cause Corrective action
•Scale on level sensors
•Boiler overfilling
•Descale.
•Check water inlet
valve
•Water turned off
•Inlet hose bent or blocked
•Water pressure too high
or low
•Drain valve open
•Check water
supply and drain
valve.
•Call service if fault
persists
•Boil-dry / overheat
protector tripped
•Temperature sensor fault
•Element failed
•PCB fault
•Faulty / loose connection
•Check
connections.
•Call service if fault
persists
•Temperature set too high
•Temperature sensor fault
•Boiler not filling
•Excessive scale in tank
•PCB fault
•Reduce
temperature
setting and try
again.
•Call service if fault
persists
•Temperature sensor fault •Call service

IS339 ECN3539
12
SERVICE INFORMATION
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:


UK: 01522 875520
All service work, other than routine cleaning should be carried out by one of
our authorised service agents. We cannot accept responsibility for work
carried out by other persons.
To ensure your service enquiry is handled as efficiently as possible, please
tell us:
•Brief details of the problem
•Product code
•Type number
•Serial number
}
From serial plate (beside dispensing tap)
Lincat reserve the right to carry out any work under warranty during normal
working hours, Monday to Friday, 08:30 am to 17:00 pm.
GUARANTEE
This unit carries a comprehensive UK twelve-month warranty. The guarantee
is in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the instructions in
these instructions
Consumable items
Damage due to incorrect installation, modification, unauthorised service work
or damage due to scale
The manufacturer disclaims any liability for incidental, or consequential
damages

IS339 ECN3539
13
This page intentionally left blank
