Lincat WMBFX Series Owner's manual

IS 745 ECN 4386 Page 1 of 12
Installation, Operating and Servicing
Instructions
Wall Mounted Water Boiler –Glass Front
WMBFX/B
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________

IS 745 ECN 4386 Page 2 of 12
CONTENTS
Important Information
2
Warnings and Precautions
3
Technical Data
3
Check list of Enclosures
Accessories
3
3
Installation and Commissioning
4-5
Operating Instructions
6-8
Cleaning
9
Servicing, Maintenance and Component Replacement
10
Fault Finding
10
Spare Parts List
Service Information and Guarantee
10
11
IMPORTANT INFORMATION
Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.
WARNING!
This symbol is used whenever there is a risk of personal injury.
CAUTION!
This symbol is used whenever there is a risk of damaging your Lincat product.
NOTE:
This symbol is used to provide additional information, hints and tips.
KEEP THIS MANUAL FOR FUTURE REFERENCE

IS 745 ECN 4386 Page 3 of 12
WARNINGS AND PRECAUTIONS
This appliance must be installed, commissioned and serviced by a qualified person
in accordance with national and local regulations in force in the country of
installation.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.
Ensure wall construction is suitable see Installation and commissioning.
Ensure that the plug/socket is accessible at all times.
Strip plastic coating and clean the appliance before use.
During operation parts may become hot - avoid accidental contact.
Disconnect this appliance before servicing, maintenance or cleaning.
This appliance is not suitable for outdoor use.
Waste connection to the condensate overflow pipe with use of a Tundish is
advisable.
TECHNICAL DATA
Model
Height
(mm)
Width
(mm)
Depth
(mm)
Weight
(kg)
Weight (kg)
Inc. full tank
WMB5FX
464
353
218
11.2
16.4
CHECK LIST OF ENCLOSURES
Instructions manual
Warranty card
Connection hose
Wall bracket
Silicone drain hose assembly
ACCESSORIES
DR97
Drip tray
FC02
Filter cartridge
MS19
De-scaler

IS 745 ECN 4386 Page 4 of 12
10
215
INSTALLATION AND COMMISSIONING
This appliance must be earthed.
If replacing the plug connect the terminals as follows:
Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L
Means of isolation with at least 3mm contact separation in all poles must be
incorporated into the fixed wiring of this appliance.
The fixed wiring insulation must be protected by insulated sleeving having a
temperature rating of at least 60°C.
Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary
polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57).
Do not re-use old hose sets.
Wall installation
The boiler must be installed on a vertical concrete/brick wall with the base in a
horizontal position. The location must be frost free.
Using the wall bracket provided mark the position of the mounting holes. The top of
the wall bracket is 10mm below the height of the fitted unit lid (Fig.1). Drill the holes
and insert suitable wall plugs.
Fig. 1

IS 745 ECN 4386 Page 5 of 12
Hang the unit onto the bracket and mark the position of the lower fixing screw on
the underside of the unit. Remove the boiler and drill the hole and insert suitable
wall plug. The water boiler is now ready to mount and connect services.
Please allow 400mm clear space above the unit to allow removal of the cover and
300mm below the unit to allow for filter removal.
Electrical supply
The WMBFX wall mount series are supplied with a 13 amp plug to BS1363
Power Ratings
Model
kW
Amps
WMB5FX
3.0
13.0
Water Installation
Connect the supplied white water inlet hose to the inlet connection point on the
base of the boiler and the other end to the mains supply via an accessible isolating
tap with a ¾” BSP thread.
Use the hose set supplied with the appliance –any previous hose set is not to be
re-used.
Connect the condensate/overflow pipe (Fig. 2 C) to a suitable drain, considering
any applicable local water regulations.
Potable water. If solid particles are known to be in the supply, add an extra inline
filter or strainer.
Ambient temp °C
Water inlet pressure Bar
Water inlet pressure kPa
5 to 30
1 to 8
100 to 800
Turn on the water supply and check for leaks.

IS 745 ECN 4386 Page 6 of 12
464
353 218
A DISPLAY
B DISPENSE BUTTON
C OVERFLOW RESET
D WATER FILTER
EDRAIN VALVE
F CONDENSATE/OVERFLOW
G WATER INLET CONNECTION
H ELECTRICAL CONNECTION
29 50
54
28
152
49
74
D
E
96
F
G
H
A
B
C
37
OPERATING INSTRUCTIONS
Only qualified or trained personnel should use this appliance.
First Use
Switch on both mains water and electricity supplies and leave the boiler for 13 mins
to fill completely. Unit will display READY when set temperature is reached.
New filters have a small amount of loose, harmless, carbon particles. Drain off
approximately 3 litres of water when first setting up or replacing filter.
Regular operation
The appliance starts automatically shortly after the electrical supply is turned on,
filling with water and heating.
The unit will display ‘WAIT’ whilst it fills and heats. It will display ‘READY' when
water can be drawn off.
To ensure that water is always hot, only small quantities are added constantly
during the heating cycle. The appliance is designed to be left on permanently, only
to be turned off for descaling or maintenance.
Fig. 2

IS 745 ECN 4386 Page 7 of 12
A
D
F
B
EG
H
Touchscreen display configuration
KEY
Pressing allows
A
Power button
On, off, and Timed modes
B
Timed operation
Access to timer settings
D
Clock
Access to clock settings
E
Ready, Wait
Clock, temperature and PIN lock
F
Element on
G
Filter life icon
Reset filter life after replacement
H
Water in
Adjustment - Clock.
At any point press the WAIT or READY on the display. Now press Settings.
Then press Clock followed by Set Time. Now press day followed by arrow keys to
set day. Repeat for hours and minutes. Now press <ENTER> to return to main
display.
Adjustment - Water temperature.
At any point press the WAIT or READY on the display. Now press Settings.
Then press Temperature at this point press arrow keys to select desired
temperature. Now press <ENTER> to return to main display.

IS 745 ECN 4386 Page 8 of 12
A
B
Adjustment –Pin Lock.
All units are fitted with a settings PIN LOCK. Press READY and then Settings to
access the PIN setting screen. The unit is fitted with an extra setting to lock the
dispense tap operation and an additional time setting that is used to set the
maximum time after the last dispense that the boiler is unlocked for. A master PIN
code is available from Lincat Service should you forget the user set PIN.
Standby
If the appliance is to be left unused for any length of time, turn the element off by
pressing the ON/OFF button on the display.
Then press OFF. Now press <ENTER> to return to main display.
Filter replacement
The filter display shows the estimated life left in the filter cartridge. A reminder
message is displayed when the filter needs changing.
Fig. 4
To replace the filter
From the underside of the boiler loosen off screw Bthen slide and lift off cover A.
Twist the base of the filter 90° to the left and carefully lower the filter cartridge out of
the appliance. It will contain a small volume of water.
Re-insert new filter into the recess and lock into place by twisting to the right.
Replace cover A and tighten screw B.
Press the filter life icon and follow the on-screen instructions to reset the filter life.
Drain off approximately 3 litres of water to remove any loose carbon particles from
the filter.
The boiler will not fill if the filter is removed as the filter head incorporates a shut-off
valve.

IS 745 ECN 4386 Page 9 of 12
CLEANING
Do not use a water jet or steam cleaner, and do not immerse this appliance.
Clean all panels with warm water and mild detergent, do not use abrasive
materials. Dry with a soft cloth.
Wipe the dispensing nozzle daily to remove lime scale deposits.
De-scaling
The boiler should be de-scaled regularly to maintain efficient operation and water
quality. The frequency depends on the hardness of the water and the timely
replacement of the filter.
In common with all water boiler manufacturers, service calls resulting from lime
scale are not covered by warranty.
The de-scaling procedure must be performed by trained personnel as it
requires the removal of panels from the boiler giving access to live electrical
components.
De-scaling the boiler at the end of the working day gives the de-scaling agent
several hours to work. Lincat recommend our own de-scaling agent DP10, available
from our Spares department.
Wear protective clothing.
Isolate the boiler from the electrical supply.
Turn off the power and allow the water to cool to 60°C.
Remove the outer surround secured by 3 screws.
Remove the top cover secured by 5 screws.
Remove the insulation from the top of the tank, then unscrew and remove
the tank lid secured by 8 screws.
Add the de-scaling agent slowly to avoid eruption of the water. Follow the
manufacturer’s instructions.
Replace the tank lid, top cover and outer surround. Attach an ‘Out of Use’
notice to the boiler to prevent use during de-scaling.
Turn on the electricity and allow the boiler to run normally for 30 minutes.
Isolate the boiler and allow the water to cool.
Remove the outer surround, top cover and tank lid and inspect the tank and
level sensor housings for scale deposits. If necessary, repeat the de-scaling
process.
In hard water areas manual descale may be required. Remove as much scale as
possible by hand paying particular attention to the level sensors and element.
Drain and flush all de-scaling agent from the tank completely as follows:
Drain all the water out of the tank (Fig. 2 E)
Failure to descale a unit may result in the boiler overfilling and leaking from the
overflow.

IS 745 ECN 4386 Page 10 of 12
SERVICING, MAINTENANCE AND
COMPONENT REPLACEMENT
All servicing, maintenance and component replacement on this appliance should be
carried out by one of our recommended service engineers.
Please refer to the Service Help Desk number on the final page of this manual if
fault persists.
For spare parts contact Lincat Spares department on 01522 875510. Refer to the
serial plate for the model and serial number, as this will help us quickly identify the
part you require.
Part Number
Description
Used on
DV02
Drain valve
EL277
Element
FC04
Water filter
FH04
Filter head only
GA83
Tank gasket
GF04/S
Glass front c/w display/pcb
LE57
Level sensor insulator
M3F, M5F and M7F
LE48
Upper level sensor
LE51
Lower level sensor
LE68
Upper level sensor
PR100
Power board
PR118
Display/Circuit board
SI01
Sensor isolator
SO24
Solenoid
SV03
Dispense solenoid
SW108
Switch
TH123
90° cut-out
TH124
Thermistor
TH88
120° cut-out
WL15
Sensor loom
FAULT FINDING
SPARE PARTS LIST

IS 745 ECN 4386 Page 11 of 12
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out by
other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
GUARANTEE
This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is
in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
Scale related issues
Consumable items (such as filters, glass, bulbs, slot toaster elements and door
seals.)
Damage due to incorrect installation, modification, unauthorised service work or
abuse
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.
Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for
within the warranty. Any requirement for staff attending the call to spend greater time
than 15 minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
SERVICE INFORMATION

IS 745 ECN 4386 Page 12 of 12
