Lincat LPB Owner's manual

IS 317 ECN 3607 Page 1 of 9
Installation, Operating and Servicing
Instructions
Lynx 400 Pasta Boiler
LPB
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________

IS 317 ECN 3607 Page 2 of 9
CONTENTS
Important Information
2
Warnings and Precautions
3
Technical Data
3
Checklist of Enclosures
3
Installation and Commissioning
3-4
Operating Instructions
5-7
Cleaning
7
Servicing, Maintenance and Component Replacement
7
Fault Finding
7
Spare Parts List
8
Accessories
8
Service Information and Guarantee
9
IMPORTANT INFORMATION
Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.
WARNING!
This symbol is used whenever there is a risk of personal injury.
CAUTION!
This symbol is used whenever there is a risk of damaging your Lincat product.
NOTE:
This symbol is used to provide additional information, hints and tips.
KEEP THIS MANUAL FOR FUTURE REFERENCE

IS 317 ECN 3607 Page 3 of 9
WARNINGS AND PRECAUTIONS
This appliance must be installed, commissioned and serviced by a qualified person
in accordance with national and local regulations in force in the country of
installation.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.
Ensure that the plug/socket is accessible at all times.
Strip plastic coating and clean the appliance before use.
During operation parts may become hot - avoid accidental contact.
Disconnect this appliance before servicing, maintenance or cleaning.
Do not move the appliance when the tank is full of hot water.
TECHNICAL DATA
Model
Height (mm)
Width (mm)
Depth (mm)
Weight (kg)
LPB
315
270
417
11.0
CHECK LIST OF ENCLOSURES
Warranty card
Instructions manual
Feet
Base plate
Lid
Basket
Lid knob
INSTALLATION AND COMMISSIONING
This appliance must be earthed.
If replacing the plug connect the terminals as follows:
Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L

IS 317 ECN 3607 Page 4 of 9
Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary
polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57)
Push the feet into the base holes provided. Install this appliance beneath an
extractor on a level surface ensuring all vents are unobstructed. Any partitions,
walls or furniture must be of non-combustible material. Minimum distances A
100mm B 1000mm –see Fig 1.
Fig 1
Fit the lid knob to the lid.
Power Ratings
Model
kW
Amps
LPB
3.0
13.0

IS 317 ECN 3607 Page 5 of 9
OPERATING INSTRUCTIONS
Only qualified or trained personnel should use this appliance.
Before first use, clean the tank. Firstly remove the base plate, then lift the control
head out by sliding the rear guide Fig 2 (A) out of the channel (B). Using warm
water and mild detergent clean the tank and dry thoroughly.
Fig 2
Replace the control head and base plate, ensuring the base plate Fig 3 (A) slots
behind the basket support (B).

IS 317 ECN 3607 Page 6 of 9
Fig 3
Add water to a level between the markers on the base plate.
Connect the appliance to an electrical supply –the green neon illuminates to
indicate power to the appliance.
Turn the control knob to the desired setting –the amber neon illuminates.
The amber neon extinguishes when the set temperature is reached, and then
operates with the cycling of the element.
Lower the basket of food carefully into the boiling water –the water level will rise
considerably. After cooking place the basket into the slots provided on the basket
support and allow to drain.
Always maintain the water level between the markers, topping up with boiling water
if necessary. One kilo of pasta uses approximately 1.5 litres of water.
This appliance is fitted with a safety thermostat to cut off the power in the event of a
fault. If the green neon illuminates but the element does not heat, re-set the safety
thermostat by pushing up the red button located through the access hole in the
back panel Fig 2 (C). The appliance must be cool before the safety thermostat can
be re-set.

IS 317 ECN 3607 Page 7 of 9
Maximum cooking quantities
Product
BA157 Large basket
BA158 Small basket
Fusilli - Fresh
600g
200g
Spaghetti - Fresh
600g
200g
Penne - Fresh
600g
200g
Tagliatelle - Fresh
500g
200g
Potato Gnocchi - Fresh
500g
250g
Macaroni - Fresh
500g
200g
Pasta Shells - Fresh
400g
200g
Penne - Dried
600g
200g
Spaghetti - Dried
400g
150g
Tagliatelle - Dried
300g
125g
CLEANING
Do not use a water jet or steam cleaner, and do not immerse this appliance.
Clean all panels with warm water and mild detergent, do not use abrasive
materials. Dry with a soft cloth.
Ensure that the thermostat capillary and bulb is not damaged during cleaning.
SERVICING, MAINTENANCE AND
COMPONENT REPLACEMENT
All servicing, maintenance and component replacement on this appliance should be
carried out by one of our recommended service engineers.
Please refer to the Service Help Desk number on the final page of this manual.
FAULT FINDING

IS 317 ECN 3607 Page 8 of 9
Part Number
Description
EL227
Element
EN10
Energy regulator
FA36
Thermostat bulb clip
KN10
Lid knob
KN240
Control knob
NE42
Amber neon
NE43
Green neon
PL202
Mains cable
SW38
Cut out switch
TA38
Tank
TH81
Safety thermostat
Part Number
Description
BA158
Half size basket insert (pair)
SPARE PARTS LIST
ACCESSORIES

IS 317 ECN 3607 Page 9 of 9
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out by
other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
GUARANTEE
This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is
in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
Consumable items (such as filters, glass, bulbs, slot toaster elements and door
seals.)
Damage due to incorrect installation, modification, unauthorised service work or
damage due to scale, food debris build-up, etc.
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.
Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for
within the warranty. Any requirement for staff attending the call to spend greater time
than 15 minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
SERVICE INFORMATION
