Lindab WK45 Series User manual

English
Installation type with re resistance class
PATENTED FIRE DAMPER
RECTANGULAR SERIES WK45 - 500 Pa / 300 Pa
Cert. N° 1812-CPR-1006
Technical Manual
WK45

This is a 56page manual.

TABLE OF CONTENTS
WK45
3/56
Overview � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�4
Description � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�4
General characteristics � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�4
European Standards applied � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�4
Certications and approvals � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�4
Components � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�4
Available dimensions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�5
Paired re dampers wall opening � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�6
Fire dampers pairing � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�6
Performances � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�8
Fire resistance classication according to EN 13501-3-2009 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�9
Mechanism type � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�11
Technical data � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�13
Dimension � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�13
Weights � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�14
Installation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�15
Intended use � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�15
Not allowed uses � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�15
Blade rotation axis positioning � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�15
Positioning brackets before xing � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�15
Installation of exible connectors in order to balance out the ventilation ducts expansion � � � � � � � � � � � � � � � p�15
Transfer Application (application not connected to air ducts on one or both sides) � � � � � � � � � � � � � � � � � � p�17
Minimum distances � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�19
Construction supports characteristics � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�21
Installations within vertical rigid wall � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�22
Installations within vertical light wall (plasterboard) � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�24
Installations within vertical light wall (gypsum blocks wall) � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�26
Installations within oor � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�27
Installations within vertical wall with Fire Batt (Weichschott) sealing � � � � � � � � � � � � � � � � � � � � � � � � � p�28
Installation within oor with Fire Batt (Weichschott) sealing � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�29
Electrical connections � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�30
Electrical wiring � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�30
Electrical specications � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�32
Maintenance and inspections � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�33
Periodic inspection and cleaning � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�33
Repair � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�33
Disposal � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�33
Selection � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�34
Air ow rates in relation to the diameter � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�34
Air ow rates as a function of the pressure drop � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�37
Air ow rates as a function of generated sound levels � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�40
Pressure drop and sound level graph for base 400 mm � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�43
Correction for base dierent than 400 mm � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�44
Sound spectrum table � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�44
Accessories and spare parts � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�45
How to order � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�48
Motorized re dampers � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�48
Fire damper with manual control � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�48
Electric motor driven actuators � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�49
Specication Text � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�51
Series WK45 rectangular re damper � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�51
Revision Index � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � p�52
WK45
3/56

OVERVIEW
WK45
4/56
OVERVIEW
Description
Fire dampers WK45 are devices for use in heating, ventila-
tion and air-conditioning (HVAC) systems at re bounda-
ries to maintain compartmentation and protect means of
escape in case of re. They satisfy integrity, insulation and
smoke leakage criteria for the declared time of re resist-
ance.
Tested and classed in accordance with EN 1366-2 and EN
13501-3 regulations with 500 Pa depression (300 Pa for in-
stallations with Weichschott sealing).
Studied and optimized for medium and big size ducts fo-
cusing on aeraulic and acoustical performance.
Equipped with various dierent mechanisms completely
outside the wall, easily interchangeble even after installa-
tion.
General characteristics
• Casing made from galvanized carbon steel.
• Intumescent sealing gasket.
• Opening/closing mechanism with IP42 protection box
(IP54 for motorized version).
• 40 mm thick closing blade made with refractory material.
• Cold smoke air seal gasket
• Internal intumescent gasket for hot smoke seal.
European Standards applied
Test EN 1366-2
Thermal fuse reliability ISO 10294-4
Classication EN 13501-3
Air Seal EN 1751
Resistance to corrosive enviro-
ments EN 60068-2-52
CE certication EN 15650
Certications and approvals
CE Certicate of Constancy of Performance n° 1812-CPR-1006 Efectis
German approval n° Z-56.4212-987 DIBt
NF certication n° 09/03.03 AFNOR
Swiss approval n° 23220 VKF-AEAI
Swedish approval n° SC0185-16 SP
Components
1. Casing made from 2 galvanized carbon steel ducts.
2. Mineral ber gasket between the 2 re damper casings.
3. Damper blade made from refractoring material
4. Blade rotation axis, pivots housing.
5. Blade drive with crank and slotted link mechanism
6. Protection box
7. Manual closing device (Test button)
8. Temperature controlled closing device (thermal fuse)
9. OPTIONAL Inspection opening side "A"
10. OPTIONAL Inspection opening side "C"
WK45
4/56

OVERVIEW
WK45
5/56
Available dimensions
Single re dampers
Fire dampers are avaible in all base-height combination indicated below, excluded sizes: 200x650, 200x700, 250x700,
200x750, 250x750, 300x750, 350x750, 200x800, 250x800, 300x800, 350x800.
Avaible height mm 200 250 300 350 400 450 500 550 600 650 700 750 800
Avaible base mm 200 250 300 350 400 450 500 550 600 650 700 750 800 850
Avaible base mm 900 950 1000 1050 1100 1150 1200 1250 1300 1350 1400 1450 1500
Fire dampers pairing for big ducts dimensions
1. Side by side paired re dampers
2. Vertically paired re dampers
Side by side paired re dampers
Required base mm 1600 1600 1700 1700 1800 1800 1900 1900 2000 2000 2100 2100 2200 2200 2300 2300
B tot mm 1570 1620 1670 1720 1770 1820 1870 1920 1970 2020 2070 2120 2170 2220 2270 2320
B1 mm 750 800 800 850 850 900 900 950 950 1000 1000 1050 1050 1100 1100 1150
B2 mm 750 750 800 800 850 850 900 900 950 950 1000 1000 1050 1050 1100 1100
Side by side paired re dampers
Required base mm 2400 2400 2500 2500 2600 2600 2700 2700 2800 2800 2900 2900 3000 3000 3100 3100
B tot mm 2370 2420 2470 2520 2570 2620 2670 2720 2770 2820 2870 2920 2970 3020 3070 3070
B1 mm 1150 1200 1200 1250 1250 1300 1300 1350 1350 1400 1400 1450 1450 1500 1500 1500
B2 mm 1150 1150 1200 1250 1250 1250 1300 1300 1350 1350 1400 1400 1450 1450 1500 1500
Vertically paired re dampers
Required height mm 900 900 1000 1000 1100 1100 1200 1200 1300 1300 1400 1400 1500 1500 1600 1600 1650
H tot mm 870 920 970 1020 1070 1120 1170 1220 1270 1320 1370 1420 1470 1520 1570 1620 1670
H1 mm 400 450 450 500 500 550 550 600 600 650 650 700 700 750 750 800 800
H2 mm 400 400 450 450 500 500 550 550 600 600 650 650 700 700 750 750 800
From the requested dimensions, it is possible to identify the closest eective achievable sizes.
WK45
5/56

OVERVIEW
WK45
6/56
1. It is allowed to pair two re dampers. Maximum paired size: 1670x1500, 3070x800, 1500x1670.
2. It is forbidden to pair three or more re dampers.
3. It is forbidden to vertically pair two re dampers with vertical axis.
Paired re dampers wall opening
1. Hole and installation for two re dampers paired side by side with horizzontal axis
2. Hole and installation for two re dampers paired vertically with horizzontal axis
X1 X2 Y1 Y2
vertical rigid wall EI 120 S B1 + 80 mm Btot + 80 mm H1 + 80 mm Htot + 80 mm
light vertical plasterboard wall EI 120 S B1 + 100 mm Btot + 100 mm H1 + 100 mm Htot + 100 mm
light vertical plasterboard wall EI 90 S B1 + 75 mm Btot + 75 mm H1 + 75 mm Htot + 75 mm
light vertical gypsum blocks wall EI 120 S B1 + 80 mm Btot + 80 mm H1 + 80 mm Htot + 80 mm
light vertical gypsum blocks wall EI 90 S B1 + 80 mm Btot + 80 mm H1 + 80 mm Htot + 80 mm
horizontal oor EI 180 S B1 + 130 mm Btot + 130 mm H1 + 130 mm Htot + 130 mm
horizzontal oor EI 120 S B1 + 130 mm Btot + 130 mm H1 + 130 mm Htot + 130 mm
horizzontal oor EI 90 S B1 + 130 mm Btot + 130 mm H1 + 130 mm Htot + 130 mm
Fire dampers pairing
The WK45 patented rectangular re dampers can be
paired side-by-side or vertically (not more than two) using
the custom connection kit (see section Accessories and
spare parts p.45). Two insulating layers must be inserted
between the two re dampers.
The pair of dampers, may be installed in vertical wall in the
same way as a single damper.
WK45
6/56

OVERVIEW
WK45
7/56
1. WK45 Fire damper
2. Steel plate
3. Fixing screws
4. Rock wool strip 100 kg/m³ 80 x 65 x nominal re damper base + 70
mm (not included in the connection kit WKBA2)
5. Rock wool strip 100 kg/m³ 80 x 65 x nominal re damper height +
70 mm (not included in the connection kit WKBA2)
6. Nut
• It is forbidden to pair three or more re dampers.
WK45
7/56

OVERVIEW
WK45
8/56
1. WK45 Fire damper
2. Steel plate
3. Fixing screws
4. Rock wool strip 100 kg/m³ 80 x 65 x nominal re damper base +
70 mm (not included in the connection kit WKBA2)
5. Nut
• It is forbidden to pair three or more re dampers. • It is forbidden to vertically pair two re dampers with ver-
tical axis.
Performances
Performance Reference standard Class
Thermal fuse testing ISO 10294-4 Compliant
Open and Close cycle reliability EN 15650 Compliant
Resistance to corrosion in humid and saline environments EN 60068-2-52 Degree of severity 2
Casing tightness EN 1751 Class C
Blade seal EN 1751 Class 2 minimum
WK45
8/56

OVERVIEW
WK45
9/56
Fire resistance classication according to EN 13501-3-2009
EI 180 S
(500 Pa) EI 120 S (500 Pa) EI 90 S (500 Pa) EI 60 S (500 Pa) EI 30 S (500 Pa)
Rigid wall
EI 120 S Installation within vertical rigid wall p.22
Wall minimum thickness 100 mm
Wall minimum density 500 kg/m³
Mortar or plaster putty sealing
ve (i↔o)
W - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
EI 120 S Installation within vertical rigid wall p.22
Wall minimum thickness 100 mm
Wall minimum density 500 kg/m³
Plasterboard and rock wool 100 kg/m³ sealing
ve (i↔o)
D - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
EI 180 S Installation within vertical rigid wall p.22
Wall minimum thickness 140 mm
Wall minimum density 500 kg/m³
Mortar sealing
ve (i↔o)
WB X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
Flexible wall
EI 120 S Installation within vertical light wall (plasterboard) p.24
Wall minimum thickness 100 mm
Wall rock wool density up to 100 kg/m³ (optional)
Mortar or plaster putty sealing
ve (i↔o)
W - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
EI 90 S Installation within vertical light wall (plasterboard) p.24
Wall minimum thickness 100 mm
Wall rock wool density up to 100 kg/m³ (optional)
Plasterboard and rock wool 100 kg/m³ sealing
ve (i↔o)
D - - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
EI 120 S Installation within vertical light wall (gypsum blocks wall) p.26
Wall minimum thickness 100 mm
Wall minimum density 995 kg/m³
Plaster putty sealing
ve (i↔o)
W - B X H min 200 X 200
max 1000 X 600
B X H
min 200 X 200
max 1000 X 600
B X H
min 200 X 200
max 1000 X 600
B X H
min 200 X 200
max 1000 X 600
EI 90 S Installation within vertical light wall (gypsum blocks wall) p.26
Wall minimum thickness 70 mm
Wall minimum density 995 kg/m³
Plaster putty sealing
ve (i↔o)
W - - B X H min 200 X 200
max 1000 X 600
B X H
min 200 X 200
max 1000 X 600
B X H
min 200 X 200
max 1000 X 600
Floor
EI 180 S Installation within oor p.27
Floor minimum thickness 140 mm
Floor minimum density 2200 kg/m³
Mortar sealing
ho (i↔o)
WB X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
EI 120 S Installation within oor p.27
Floor minimum thickness 150 mm
Floor minimum density 650 kg/m³
Mortar sealing
ho (i↔o)
W - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
EI 90 S Installation within oor p.27
Floor minimum thickness 100 mm
Floor minimum density 650 kg/m³
Mortar sealing
ho (i↔o)
W - - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H are re damper minimum and maximum nominal dimensions (base x height) in mm
ve Vertical installation
ho Horizontal installation
(i↔o) Origin of re irrelevant
Pa Pascal of depression
E Integrity
I Thermal insulation
S Smoke seal
W Wet method sealing
D Dry method sealing
Cert. N° 1812-CPR-1006
WK45
9/56

OVERVIEW
WK45
10/56
Fire Batt (Weichschott) sealings
EI 120 S
(300 Pa) EI 90 S (300 Pa) EI 60 S (300 Pa) EI 30 S (300 Pa)
Rigid wall
EI 90 S Installation within vertical rigid wall with Fire Batt (Weichschott) sealing p.28
Wall minimum thickness 100 mm
Wall rock wool minimum density 500 kg/m³
Rock wool 140 kg/m³ and endothermic varnish sealing
ve (i↔o)
W - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
Flexible wall
EI 90 S Installation within vertical light wall (plasterboard) with Fire Batt (Weichschott) sealing p.28
Wall minimum thickness 100 mm
Wall rock wool density up to 100 kg/m³ (optional)
Rock wool density 140 kg/m³ and endothermic varnish sealing
ve (i↔o)
W - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
EI 90 S Installation within vertical light wall (gypsum blocks wall) with Fire Batt (Weichschott) sealing p.28
Wall minimum thickness 100 mm
Wall minimum density 995 kg/m³
Rock wool 140 kg/m³ and endothermic varnish sealing
ve (i↔o)
W - B X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
Floor
EI 120 S Installation within oor with Fire Batt (Weichschott) sealing p.29
Floor minimum thickness 150 mm
Floor minimum density 650 kg/m³
Rock wool 140 kg/m³ and endothermic varnish sealing
ho (i↔o)
WB X H min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H
min 200 X 200
max 1500 X 800
B X H are re damper minimum and maximum nominal dimensions (base x height) in mm
ve Vertical installation
ho Horizontal installation
(i↔o) Origin of re irrelevant
Pa Pascal of depression
E Integrity
I Thermal insulation
S Smoke seal
W Wet method sealing
D Dry method sealing
Cert. N° 1812-CPR-1006
WK45
10/56

OVERVIEW
WK45
11/56
Mechanism type
Manual / Manual with magnet
1. Manual opening lever
2. Protection box
3. Lever position when the blade is open
4. Lever position when the blade is closed
5. Magnet knob (for magnetic version)
6. Closed blade indicator
7. Open blade indicator
8. Manual closing button
Blade closing mode
Automatic closing with thermal fuse.
The control mechanism has a thermosensitive element
that automatically closes the blade when the temperature
in the duct exceeds 70°C (or 95°C for the re damper with
95°C thermal fuse).
It is possible to close the damper by pressing the indicated
button.
If the manual mechanism is equipped with electromagnet
it is possible to remotely close the re damper.
The manual command mechanism with magnet is
equipped with an electromagnet which, in case power is
interrupted (interuption magnet version) or when power
is supplied (input magnet version), comands the closing of
the damper.
Blade opening mode
The damper must be opened when the ventilation system
if switched o.
In case of closed damper by pressing the closing button or
remotely by electromagnet (magnetic version), it is possi-
ble to manually open the re damper blade by rotating the
lever antyclockwise.
For power supply interruption electromagnet, provide
power supply and pull the magnet knob before opening
the re damper.
In case of closed damper as a result of the action of the
thermosensitive element, it is possible to manually reopen
the damper by rotating the lever counterclockwise once
the element has been replaced.
Position indication microswitches
On request, the re damper can be supplied with posi-
tion microswitches (SA/SC/S2 optional) that signal the
blade position (open or closed). Refer to Electrical connec-
tions p.30 paragraph for more details.
Closing by remote control
With power supply input or interruption magnet (WK45M
version only).
Temperature calibration of thermosensitive element for
automatic damper closing
70 °C±7 °C (Standard)
95 °C±9 °C (On request).
Belimo motorized version
1. Manual closing switch
2. Manual opening lever
3. Position indicator
4. Blade locking lever
Blade closing mode
Automatic closing with thermal fuse.
The control mechanism has a thermosensitive element
that automatically closes the blade when the temperature
in the duct or in the room exceeds 72°C (or 95°C for the
95°C version).
To close the damper when the motor is connected, press
the switch on the temperature sensor or cut o the power
supply.
Blade opening mode
The damper must be opened when the ventilation system
if switched o.
To open the damper with the electric motor driven actua-
tor, provide power supply to the motor. Refer to the section
Electrical connections p.30 for further information.
To manually open the damper, use the handle supplied
and carefully rotate clockwise to the 90° indicator. To hold
the damper in open position operate on the lever indicat-
ed in gure.
For VGB/DGB versions to hold the damper in open posi-
tion, carefully rotate the handle counterclockwise.
During the manual opening of the damper, power must
not be supplied to the motor.
Position indication microswitches
The motorized versions are supplied with two microswitch-
es to show the blade's position (open or closed). Refer to
the section Electrical connections  p. 30 for further in-
formation.
Closing by remote control
If power to the motor is cut o, the blade will close.
WK45
11/56

OVERVIEW
WK45
12/56
Temperature calibration of thermosensitive element for
automatic damper closing
72 °C±7 °C (Standard)
95 °C±9 °C (On request).
Siemens motorized version
1. Manual closing switch
2. Manual opening lever
3. Screwdriver
4. Position indicator
Blade closing mode
Automatic closing with thermal fuse.
The control mechanism has a thermosensitive element
that automatically closes the blade when the temperature
in the duct or in the room exceeds 72°C (or 95°C for the
95°C version).
To close the damper when the motor is connected, press
the switch on the temperature sensor or cut o the power
supply.
Blade opening mode
The damper must be opened when the ventilation system
if switched o.
To open the damper with the electric motor driven actua-
tor, provide power supply to the motor. Refer to the section
Electrical connections p.30 for further information.
To manually open the damper, use the handle supplied
and carefully rotate counterclockwise to the 90 °C indica-
tor. To hold the damper in open position, rotate the screw
anticlockwise as shown in the picture.
During the manual opening of the damper, power must
not be supplied to the motor.
Position indication microswitches
The motorized versions are supplied with two microswitch-
es to show the blade's position (open or closed). Refer to
the section Electrical connections  p. 30 for further in-
formation.
Closing by remote control
If power to the motor is cut o, the blade will close.
Temperature calibration of thermosensitive element for
automatic damper closing
72 °C±7 °C (Standard)
95 °C±9 °C (On request).
WK45
12/56

TECHNICAL DATA
WK45
13/56
TECHNICAL DATA
The sizes shown are in mm.
Dimension
Hmm 200 250 300 350 400 450 500 550 600 650 700 750 800
S blade exposition mm 0 0 0 0 0 0 0 9 34 59 84 109 134
Manual
Manual with magnet
Siemens motorized version
Belimo motorized version
WK45
13/56

TECHNICAL DATA
WK45
14/56
Weights
Base
Height 200 250 300 350 400 450 500 550 600
200 9,0 10,0 11,0 12,0 13,0 15,0 16,0 18,0 20,0
250 10,0 11,0 12,0 13,0 14,0 16,0 18,0 20,0 22,0
300 11,0 12,0 13,0 14,0 17,0 19,0 21,0 22,0 24,0
350 12,0 13,0 14,0 15,0 18,0 19,0 22,0 24,0 26,0
400 14,0 15,0 16,0 17,0 19,0 21,0 23,0 26,0 28,0
450 15,0 16,0 17,0 18,0 21,0 23,0 25,0 27,0 29,0
500 17,0 18,0 19,0 20,0 23,0 25,0 27,0 28,0 31,0
550 18,0 19,0 20,0 21,0 24,0 26,0 29,0 31,0 33,0
600 19,0 20,0 21,0 22,0 25,0 27,0 31,0 33,0 35,0
650 20,0 22,0 23,0 24,0 29,0 31,0 33,0 36,0 38,0
700 24,0 25,0 31,0 33,0 35,0 38,0 40,0
750 32,0 35,0 37,0 40,0 42,0
800 34,0 37,0 39,0 42,0 44,0
Base
Height 650 700 750 800 850 900 950 1000 1050
200 22,0 24,0 25,0 26,0 27,0 27,0 27,0 28,0 30,0
250 24,0 26,0 27,0 28,0 28,0 29,0 30,0 31,0 33,0
300 26,0 28,0 29,0 30,0 31,0 32,0 33,0 35,0 36,0
350 28,0 30,0 31,0 34,0 34,0 34,0 36,0 38,0 39,0
400 30,0 32,0 34,0 36,0 37,0 37,0 39,0 41,0 42,0
450 32,0 34,0 36,0 38,0 38,0 40,0 42,0 44,0 45,0
500 34,0 36,0 38,0 40,0 41,0 43,0 45,0 47,0 49,0
550 36,0 38,0 40,0 42,0 44,0 46,0 48,0 50,0 52,0
600 38,0 40,0 42,0 44,0 46,0 49,0 51,0 53,0 55,0
650 40,0 42,0 45,0 47,0 49,0 51,0 54,0 56,0 58,0
700 42,0 45,0 47,0 49,0 52,0 54,0 56,0 59,0 61,0
750 45,0 47,0 50,0 52,0 54,0 57,0 59,0 62,0 64,0
800 47,0 49,0 52,0 55,0 57,0 60,0 62,0 65,0 67,0
Base
Height 1100 1150 1200 1250 1300 1350 1400 1450 1500
200 31,0 32,0 33,0 34,0 36,0 37,0 38,0 39,0 40,0
250 34,0 35,0 37,0 38,0 39,0 41,0 42,0 43,0 45,0
300 37,0 39,0 40,0 42,0 43,0 45,0 46,0 47,0 49,0
350 41,0 42,0 44,0 45,0 47,0 48,0 50,0 51,0 53,0
400 44,0 46,0 47,0 49,0 51,0 52,0 54,0 56,0 57,0
450 47,0 49,0 51,0 53,0 54,0 56,0 58,0 60,0 61,0
500 50,0 52,0 54,0 56,0 58,0 60,0 62,0 64,0 66,0
550 54,0 56,0 58,0 60,0 62,0 64,0 66,0 68,0 70,0
600 57,0 59,0 61,0 63,0 65,0 68,0 70,0 72,0 74,0
650 60,0 62,0 65,0 67,0 69,0 71,0 74,0 76,0 78,0
700 64,0 66,0 68,0 71,0 73,0 75,0 78,0 80,0 82,0
750 67,0 69,0 72,0 74,0 77,0 79,0 82,0 83,0 85,0
800 70,0 73,0 75,0 78,0 80,0 83,0 86,0 86,0 88,0
Weights in kg
Manual version. Motorized version: +1 kg
WK45
14/56

INSTALLATION
WK45
15/56
INSTALLATION
The sizes shown are in mm.
It is recommended to perform a functional test before
Installation to exclude possible damage during transport
and another test immediately after installation to exclude
accidental damage to the product and interference with
mounting components.
Intended use
The MP3 re dampers are “Devices for use in heating, ven-
tilation and air conditioning (HVAC) systems at re bound-
aries to mantain compartmentation and protect means of
escape in case of re”according to the 3.1 paragraph of EN
15650:2010 standard.
It is compulsory to install the re damper according to the
instructions indicated in the technical data sheet and man-
ual to maintain the declared performances and, in particu-
lar, the re classes.
The double test (with the mechanism inside and outside
the re area) demonstrated that there is no preferred direc-
tion for the position of the damper, both in relation to air
ow and the side with the higher probability of exposure
to re, as indicated in standard EN1366-2:2015 (paragraph
6.2).
Use permitted in any civil and industrial building.
Use permitted in saline atmosphere, for example:
• maritime and port enviroments;
• sh markets;
• slaughterhouses;
• cheese makers.
Not allowed uses
• Use with installations dierent to those described in the
technical data sheet and manual;
• use as smoke control damper;
• use as shut o damper;
• use in external environments without adequate protec-
tion from atmospheric conditions;
• use in explosive environments;
• use on board of ships;
• use in cooker extraction hoods;
• use in pneumatic conveying systems of dust or corn;
• use in ventilation systems within locations subject to
chemical contamination;
• use in non inspectable enviroments;
• Installation in suspended ceilings.
Blade rotation axis positioning
The re damper can be installed both with the blade axis
positioned vertically or horizontally.
Positioning brackets before xing
1. WKGY100 xing brackets (accessory to order separately, one size
valid for all re dampers kind)
WKGY100 xing brackets are obligatory for intallations
within plasterboard walls and suggested for walls with 100
mm thickness.
They are not usable for installations with Fire Batt (Weich-
schott) sealing.
Installation of exible connectors in order
to balance out the ventilation ducts
expansion
CAUTION: Refer anyway to law and national standardiza-
tion�
Flexible connectors compensate any duct thermal expan-
sion and wall bending in case of re.
Flexible connectors are used to limit re damper stresses
due to external forces in case of re and to preserve re
resistance class.
In general it is always appropriate the use of exible con-
nectors for the followings installations:
– light walls;
– Plasterboard and rock wool or Fire Batt (Weichschott)
sealing;
– Applique xing system.
Flexible connector must be normal ammability and in
case of re the grounding bonding should disconnet to
guarantee the complete separation between re damper
and connected air duct.
When exible connectors made of conductive material
(e.g. aluminum) are used, no additional grounding bond-
ing is required.
WK45
15/56

INSTALLATION
WK45
16/56
Despite exible connector installation, the re damper
must be installed in the construction support so that its
weight does not aect damper’s installation position both
during normal operation and in case of re.
It is recommended not to compress exible connectors in
the installation phase.
Flexible connector must be at least 100mm long and in
order that possible duct thermal expansions are balanced.
Take care that the exible connector does not interfer with
opening / closing movement of the blade.
Refer to the section Technical data p.13 for blade expo-
sition values.
WK45
16/56

INSTALLATION
WK45
17/56
Transfer Application (application not connected to air ducts on one or both sides)
Following tests performed as per EN 1366-2, section 6.3.6 Standard, it is possible to install the re damper free from air duct
from one or both sides.
• Attention: re resistance classication for transfer appli-
cation is conform to section Fire resistance classication
according to EN 13501-3-2009  p. 9limited to EI 120S
if the ducted classication is higher.
• End cap with mesh shall be mounted on the side not
connected to air duct.
• End cap with mesh is made from galvanized steel sheet
and includes nuts and screws for xing on re damper.
• End cap with mesh is supplied loose from the re damp-
er.
• Refer to the section How to order (transfer Applica-
tion) p.18 for codes to use.
Components (Transfer Application)
1. End cap with mesh
2. Fire damper
3. M10 nut
4. M10 screw
WK45
17/56

INSTALLATION
WK45
18/56
Technical data (Transfer Application)
1. Mechanism side
2. Mechanism opposite side
3. End cap with mesh
L1 End cap length mechanism side
L2 End cap length mechanism opposite side
H Nominal height of re damper
Length of end cap with mesh depending on re damper height H.
H L1 L2
200 50 50
250 50 50
300 50 50
350 50 50
400 50 50
450 50 50
500 50 50
550 50 50
600 50 50
650 100 100
700 100 100
750 150 150
800 150 150
H Nominal height of re damper
L1 End cap length mechanism side
L2 End cap length mechanism opposite side
How to order (transfer Application)
Type FMWK005V End cap with mesh with ange 35 mm
Base XYZ Nominal base dimension (mm)
Height XYZ Nominal height dimension (mm)
Length XYZ Length dimension (mm)
Examples Code
End cap with mesh length 50 mm for re damper 400x300 not connected to air ducts on 1 side FMWK005V400-300-050
End cap with mesh length 150 mm for re damper 800x600 not connected to air ducts on 1 side FMWK005V800-600-150
End caps with mesh length 50 mm for re damper 500x400 not connected to air ducts on both sides FMWK005V500-400-050 (x2)
WK45
18/56

INSTALLATION
WK45
19/56
Minimum distances
It is recommended to keep enough space for using the
control mechanism or for maintenance.
In accordance with Articles 7 and 13 of EN 1366-2 respect
the minimum distances indicated below.
Minimum distances
1. Side vertical wall
2. Floor
a. Distance between re dampers installed within vertical wall
b. Distance between re damper and vertical lateral wall / oor
c. Distance between re dampers installed within oor
d. Distance between re damper and vertical lateral wall
Fire dampers installed within
vertical wall Fire dampers installed within oor
Installation a [mm] b [mm] c [mm] d [mm] Paired instal-
lation
Rigid wall
EI 180 S Installation within vertical rigid wallp.23
Mortar sealing 70 75 - - Yes. One air duct
EI 120 S Installation within vertical rigid wall p.23
Mortar or plaster putty sealing 70 75 - - Yes. One air duct
EI 120 S Installation within vertical rigid wall p.23
Plasterboard and rock wool 100 kg/m³ sealing 70 75 - - Yes. One air duct
Flexible wall
EI 120 S Installation within vertical light wall (plasterboard) p.24
Mortar or plaster putty sealing 70 75 - - Yes. Separate air duct
EI 90 S Installation within vertical light wall (plasterboard) p.24
Plasterboard and rock wool 100 kg/m³ sealing 70 75 - - Yes. Separate air duct
EI 120 S Installation within vertical light wall (gypsum blocks
wall) p.26
Plaster putty sealing 70 75 - - Yes. Separate air
duct
EI 90 S Installation within vertical light wall (gypsum blocks
wall) p.26
Plaster putty sealing 200 75 - - No
Floor
EI 180 S Installation within oor p.27
Mortar sealing - - 70 75 Yes. Separate air duct
EI 120 S Installation within oor p.27
Mortar sealing - - 70 75 Yes. Separate air duct
EI 90 S Installation within oor p.27
Mortar sealing - - 70 75 Yes. Separate air duct
The minimum distance between two or more paired installations is 200 mm�
It is forbidden to pair three or more re dampers�
WK45
19/56

INSTALLATION
WK45
20/56
Fire Batt (Weichschott) sealings
Fire dampers installed within
vertical wall Fire dampers installed within oor
Installation a [mm] b [mm] c [mm] d [mm] Paired instal-
lation
Rigid
wall
EI 90 S Installation within vertical rigid wall with Fire Batt
(Weichschott) sealing p.28
Rock wool 140 kg/m³ and endothermic varnish sealing 70 50 - - Yes. One air duct
Flexible wall
EI 90 S Installation within vertical light wall (plasterboard) with Fire
Batt (Weichschott) sealing p.28
Rock wool 140 kg/m³ and endothermic varnish sealing 70 50 - - Yes. One air duct
EI 90 S Installation within vertical light wall (gypsum blocks wall)
with Fire Batt (Weichschott) sealing p.28
Rock wool 140 kg/m³ and endothermic varnish sealing 70 50 - - Yes. One air duct
Floor
EI 120 S Installation within oor with Fire Batt (Weichschott)
sealing p.29
Rock wool 140 kg/m³ and endothermic varnish sealing - - 200 75 No
The minimum distance between two or more paired installations is 200 mm�
It is forbidden to pair three or more re dampers�
1. One air duct 2. Separate air ducts
WK45
20/56
