Linear Technology DC1940A Quick setup guide

1
dc1940af
DEMO MANUAL DC1940A
DESCRIPTION
Low Quiescent Current,
High Voltage Step-Down
Converter
Demonstration circuit 1940A is a low quiescent current,
synchronousbuckconverterfeaturingtheLTC
®
3891EUDC.
This demo board converts a 16V to 60V voltage to a 12V
at 15A output.
The main features of this board include an internal LDO
for gate drive power from VIN or EXTVCC, RUN and
PGOOD pins, a mode selector that allows the converter
to run in constant current mode (CCM), pulse-skipping or
Burst Mode
®
operation, and selectable current limit. The
DC1940Asupportsanadjustableoutputvoltage,soft-start
andtracking. The wide input voltage range of 16V to60V is
suitable for double battery automotive and distributed DC
power systems where low quiescent current is important.
The LTC3891 data sheet gives a complete description of
this part, operation and application information. The data
sheet must be read in conjunction with this quick start
guide for demo circuit 1940A.
The 60V avalanche rated MOSFETs, which are used
on DC1940A, can be operated at their rated voltage.
However, if application derating requirements are
stricter, MOSFETs with higher voltage rating can be used.
L, LT, LTC, LTM, Burst Mode, Linear Technology and the Linear logo are registered trademarks
of Linear Technology Corporation. All other trademarks are the property of their respective
owners.
PERFORMANCE SUMMARY
Please note, MOSFETs with higher voltage ratings may af-
fect the efficiency. If 60V MOSFETs are used, the MOSFET
avalanche rating and testing is typically done with 30%
over voltage margin (78V for 60V rated MOSFET). Please
check with particular MOSFET manufacturer to ensure the
avalanche voltage rating.
The DC1940A supports the following MOSFET packages:
LFPAK, PowerPAK SO-8 and Power 56. The subsequent
logic level (SV gate) MOSFETs can be used with DC1940A.
Si7850DP Vishay
RJK0651DPB Renesas
HAT2266H Renesas
BSC100N06LS3 G Infineon
FDMS86520L Fairchild
For synchronization to an external clock, remove jumper
JP2 and apply sync signal on terminal SYNC.
Design files for this circuit board are available at
http://www.linear.com/demo
(TA= 25°C)
PARAMETER CONDITIONS VALUE UNITS
Minimum Input Supply Voltage 16 V
Maximum Input Supply Voltage 60 V
Output Voltage Range VIN = 16V to 60V, IOUT1 = 0A to 5A 12 ± 2% V
Typical Switching Frequency 125 kHz
Typical Output Ripple (VOUT, 12V) ILOAD = 15A 80 mV
Efficiency Typical (VOUT, 12V) 97 %
Supply Quiescent Current VIN = 24V; VOUT = 12V, IO= 0A, Burst Mode Operation 50.8 μA
Supply Shutdown Current VIN = 24V 14.7 μA

2
dc1940af
DEMO MANUAL DC1940A
QUICK START PROCEDURE
Figure 1. Proper Measurement Equipment Setup
Demonstration circuit 1940A is easy to set up to evaluate
the performance of the LTC3891EUDC. Refer to Figure 1
for proper measurement equipment setup and follow the
procedure below:
NOTE: When measuring the input or output voltage ripple,
care must be taken to avoid a long ground lead on the
oscilloscope probe. Measure the input or output voltage
ripple by touching the probe tip directly across the VIN or
VOUT and GND terminals. See Figure 2 for proper scope
probe technique.
1. Place jumper JP1 in the ON position.
2. With power off, connect the input power supply to VIN
and GND.
3. Turn on the power at the input. Check for the proper
output voltages:
V
OUT1 = 11.9V to 12.4V
NOTE: If there is no output, temporarily disconnect the
load to make sure that the load is not set too high.
4. Once the proper output voltages are established, adjust
the load within the operating range and observe the
output voltage regulation, ripple voltage, efficiency and
other parameters.
DC1940a F01

3
dc1940af
DEMO MANUAL DC1940A
Figure 2. Measuring Input or Output Ripple
Figure 3. 12V Output, Efficiency vs Load, Burst Mode Operation, VIN 16V, 24V, 48V
QUICK START PROCEDURE
DC1940a F02
GND VIN
LOAD (A)
89
93
92
91
90
EFFICIENCY (%)
95
94
97
96
98
99
DC1940a F03
0.01 0.1 1 10 100
16V
24V
48V

4
dc1940af
DEMO MANUAL DC1940A
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 3 C1, C2, C10 CAP, X7R, 2.2μF 100V 10%, 1812 TDK, C4532X7R2A225K
2 1 C3 CAP, EL, 56μF/63V, F4 SUN EL, 63HVH56M
3 1 C4 CAP, X7R, 0.1μF 100V 10%, 0603 MURATA, GRM188R72A104KA35D
4 1 C5 CAP, NPO,10pF, 50V, 5%, 0603 AVX, 06031A100JAT2A
5 2 C9, C13 CAP, X7R, 0.1μF 50V 10%, 0603 TDK, C1608X7R1H104K
6 1 C6 CAP, X5R, 4.7μF, 16V, 10%, 0805 MURATA, GRM219R61C475KE15D
7 2 C7, C17 CAP, X7R, 1μF 16V, 10%, 0603 TDK, C1608X7R1C105K
8 1 C8 CAP, NPO, 2.2pF 50V, ±0.25pF, 0603 AVX, 06035A2R2CAT
9 1 C12 CAP, X7R, 4700pF, 10V, 5%, 0603 AVX, 0603ZC472JAT2A
10 1 C14 CAP, NPO, 47pF 50V, 5%, 0603 NIC, NMC0603NPO470J50TRPF
11 1 C15 CAP, X7R, 10μF 16V 10%, 1206 MURATA, GCM31CR71C106KA64L
12 1 C16 CAP, SANYO, 150μF, 16V, 20% SANYO, 16TSVPC150
13 1 D1 DIODE, POWER DI-123 DIODES/ZETEX, DFLS1100-7
14 1 L1 IND, 10μH, 7443631000 WÜRTH, 7443631000
15 1 Q1 SILICON N CHANNEL POWER MOSFET LFPAK RENESAS, RJK0651DPB
16 1 Q2 SILICON N CHANNEL POWER MOSFET LFPAK RENESAS, RJK0653DPB
17 1 RS1 RES, 0.003Ω 1W 1% 2512 PANASONIC ERJM1WSF3M0U
18 1 R1 RES, 2.2 1% 1/10W, 0603 VISHAY, CRCW06032R20FNEA
19 3 R2, R8, R10 RES, 0Ω 1% 1/16W, 0603 VISHAY, CRCW06030000Z0EA
20 2 R4, R20 RES, 100k 1% 1/16W, 0603 VISHAY, CRCW0603100KFKEA
21 1 R5 RES, 511k 1% 1/16W, 0805 VISHAY, CRCW0805511KFKEA
22 1 R6 RES, 30.1k 1% 1/10W, 0603 VISHAY, CRCW060330K1FKEA
23 1 R7 RES, 35.7k 1% 1/16W, 0603 VISHAY, CRCW060335K7FKEA
24 1 R13 RES, 100 1% 1/10W, 0603 VISHAY, CRCW0603100RFKEA
25 1 R14 RES, 1M 1% 1/10W, 0805 VISHAY, CRCW08051M00FKEA
26 1 R15 RES, 2Ω 1% 1/16W, 0603 VISHAY, CRCW06032R00FNEA
27 1 R16 RES, 57.6k 1% 1/16W, 0603 VISHAY, CRCW060357K6FKEA
28 1 R17 RES, 15.4k 1% 1/10W, 0603 VISHAY, CRCW060315K4FKEA
29 1 R18 RES, 1k 1% 1/16W, 0603 VISHAY, CRCW06031K00FKEA
30 1 U1 IC, LTC3891EUDC, QFN20EUDC-3X4 LINEAR TECHNOLOGY, LTC3891EUDC
Additional Demo Board Circuit Components
1 R3, R9, R11, C11, R12,
C18, C19, R19, R21 RES, 0603 OPT
2 C20, C21, C22 CAP, 7343 OPT
3 Q3, Q4 (OPT) MOSFET, LFPAK OPT
Hardware
1 10 E1 TO E10 TESTPOINT, TURRET, 0.094" MILL-MAX, 2501-2-00-80-00-00-07-0
2 4 J1, J2, J3, J4 CONN, BANANA JACK, KEYSTONE-575-4 KEYSTONE 575-4
31JP1 JMP, 3PIN 1 ROW, 0.079" SULLINS, NRPN031PAEN-RC
41JP2 JMP, 3PIN 2 ROW, 0.079" SULLINS, NRPN032PAEN-RC
5 4 MTGS AT 4 CORNERS STANDOFF, NYLON 0.5 1/2" KEYSTONE, 8833(SNAP-ON)
6 2 XJP1, XJP2 SHUNT, 0.079" CENTER SAMTEC, 2SN-BK-G

5
