2GIG-PAD3-433
WIRELESS KEYPAD
INSTALL INSTRUCTIONS
TheWirelessKeypad(2GIG‐PAD3‐433)isawall‐mountedunit
designedforuseasasecondarykeypadforthe2GIGalarmsystem.It
communicateswiththeGo!ControlPanelusingthe433MHz
frequencyandprovidesuserswiththefollowingfeatures:
•ArmthesysteminStayorAwaymode
•Disarmthesystem
•ActivateFireandPanicemergencyfunctions
Figure 1 Wireless Keypad
Box Contents
Verifythatthepackageincludesthefollowing:
•1—WirelessKeypad
• 4—PlasticWallAnchorsandPhillipsHeadScrews
•2—3VLithiumCoinBatteries(installed)
Mounting the Wireless Keypad
Tomountthewirelesskeypad:
1Pressthehingedtabsontopofthekeypadtoseparatethe
mountingplatefromtheunit(seeAbelow).
Figure 2 Wireless Keypad—HingedTabs
2Placemountingplateinthedesiredlocationonthewalland
ensuretheplateislevel.
3SecurethemountingplatetothewallusingthePlasticWall
Anchorsandscrews.
Figure 3 Wireless Keypad—Mounting Plate
4Activatethebatteriesbyremovingthetwobatterypulltabs(seeA
below)locatedunderthemetalclipsoneachbattery(seeB
below).
Figure 4 Wireless Keypad—Battery Compartment
5Reattachthemountingplatetotheunitbyaligningthebottomof
theplatewiththeunitandtiltingtheunitupuntilitsnapsinto
place.
NOTE: TolearnhowtoprogramtheWirelessKeypadintothe
ControlPanel,seetheControlPanel’sInstallation&
ProgrammingGuide.

2Copyright © 2014 Linear LLC
Installing and Replacing Batteries
Toinstallandreplacethebatteries:
1Pressthehingedtabsontopofthekeypadtoseparatethe
mountingplatefromtheunit.SeeFigure2WirelessKeypad—
HingedTabs.
2Placeasmallflatheadscrewdriverintheslotbetweenthemetal
clipandthebattery.Thentwistthescrewdriverslightlywhile
holdingtheblackplasticedgesholdingthebattery.SeeFigure
4WirelessKeypad—BatteryCompartment.
3Insertthereplacementbatteries(seeSpecificationsonpage2)
withtheplus(+)sidefacingup.
4Ensurethattheprogrammingsettingsarecorrect.
5TesttheunitforgoodRFcommunications.SeeTestingthe
WirelessKeypadonpage2.
WARNING: Failuretofollowthesewarningsandinstructionscan
leadtoheatgeneration,rupture,leakage,explosion,fire,or
otherinjury,ordamage.Donotinsertthebatteryintothe
compartmentinthewrongdirection.Alwaysreplacethe
batterywiththesameorequivalenttype(seeSpecifications
onpage4).Neverrechargeordisassemblethebattery.Never
placethebatteryinfireorwater.Alwayskeepbatteriesaway
fromsmallchildren.Ifbatteriesareswallowed,promptlysee
adoctor.
Testing the Wireless Keypad
Beforemountingthekeypadtothedesiredlocation,performatestto
verifythatitcanestablishgoodradiofrequency(RF)communications
withthecontrolpanel.
1Onthekeypad,pressandholdanynumerickeyforatleasttwo(2)
seconds.
Figure 5 Wireless Keypad
2Listenforthevoicedescriptorannouncingthekeypad.
3Exitsensortestmode.
NOTE: Tofullytestthekeypad,seethecontrolpanel’sInstallation
andProgrammingGuide.
SPECIFICATIONS
WirelessSignalRange 350ft(106.7m),openair,withWireless
ControlPanel
CodeOutputs KeyPress0‐9;*;#;Stay;Away;Fire;Police;
Supervisory;LowBattery
TransmitterFrequency 433.92MHz(crystalcontrolled)
UniqueIDCodes Overone(1)milliondifferentcode
combinations
SupervisoryInterval 70minutes
Dimensions(LxWxH) 5.73x4.25x1.00in(14.6x0.8x2.5cm)
Weight(includingbattery) 7.75oz(219.7g)
HousingMaterial ABSPlastic
Color Whitewithgraytrim
OperatingTe mperat ure 32°to120°F(0°to49°C)
RelativeHumidity 5‐90%Non‐Condensing
Battery(installed) Two(2)PanasonicCR2032orequivalent
Lithiumbatteries
Certification CEandRCM
REGULATORY INFORMATION
LIMITED WARRANTY
ThisLinearproductiswarrantedagainstdefectsinmaterialand
workmanshipfortwo(2)years.Thiswarrantyextendsonlyto
wholesalecustomerswhobuydirectfromLinearLLCorthrough
LinearLLC’snormaldistributionchannels.LinearLLCdoesnotwarrant
thisproducttoconsumers.Consumersshouldinquirefromtheir
sellingdealerastothenatureofthedealer’swarranty,ifany.
TherearenoobligationsorliabilitiesonthepartofLinearLLCfor
consequentialdamagesarisingoutoforinconnectionwithuseor
performanceofthisproductorotherindirectdamageswithrespectto
lossofproperty,revenue,orprofit,orcostofremoval,installation,or
reinstallation.Allimpliedwarrantiesforfunctionality,arevalidonly
untilthewarrantyexpires.ThisLinearLLCWarrantyisinlieuofall
otherwarrantiesexpressedorimplied.
