LINET LATERA Parts list manual
LATERA
Universal hospital bed
D9U001L20-0101
Version: 04
Publication Date: 2022-10
Instructions for Use
and Technical Description
D9U001L20-0101_042
Manufacturer:
L I N E T spol. s r.o.
274 01 Slaný
Czech Republic
E-mail: [email protected]
http://www.linet.com
Latera
Author: L I N E T, s.r.o.
D9U001L20-0101
Version: 04
-
D9U001L20-0101_04
3
1 Symbols and Denitions .............................................4
..........................................................4
........................................4
...................................4
1.2 Instructions..................................................................4
1.3 Lists.............................................................................4
............................................
.................................
..................................................9
......................................................10
...........10
.....10
........................10
...................................................................11
..............................................................12
2 Safety Instructions.......................................................13
3 Intended use.................................................................16
3.1 User population...........................................................
........................................................
3.3 Operator......................................................................
4 Incorrect Use ................................................................ 16
5 Product Description.....................................................17
................................................................17
..............................................................
6 Technical Specication ...............................................19
...........................................19
..............................................19
..............................................19
.....................................20
..........................................................................................20
..........................................................................................21
7 Use and Storage Conditions ....................................... 22
8 Scope of Delivery and Bed Variants...........................22
........................................................22
................................................................22
9 Putting into Service .....................................................23
................................................24
9.1.1 Placement of Control Section ..................................24
......................................24
.............................................................24
.......................................
.............
9.3 Potential Equalisation .................................................27
..................................................................27
.....................................................................
.....................................................................
10 Power Cable ...............................................................28
11Accumulator ...............................................................29
........................................30
...............................30
...................................30
12 Manipulation...............................................................31
............................................32
.............................................32
..............................................32
....................................................33
..........................................................33
.....................................................33
.....................................................................
..........................................................................................
12.4 Foot Control Lateral Tilt.............................................
..........................................................37
......................................................37
.............................................
...........................39
............................40
12.10 Mattress support platform .......................................41
...........................41
12.10.2 Mattress Platform Extension ................................41
..........................................................42
............................................42
........43
13 Equipment .................................................................. 43
13.1Accessory Rails.........................................................43
......................................................43
..............................................................43
14 Mattress ......................................................................43
15Accessories ................................................................44
................................................................44
.....................................................................
....................
......................
............................................................
............................................................
....................................................47
....................................................47
.........................................................47
16 Cleaning/Disinfection ................................................48
.............................................49
................................................................... 49
........................................................ 49
.......................49
......................
....................................
17 Troubleshooting .........................................................51
18 Maintenance ...............................................................52
................................................
...............................................................
...........................................
19 Disposal ...................................................................... 53
.............................................
19.2 Disposal ....................................................................
19.2.1 Within Europe ........................................................
......................................................
20 Warranty......................................................................54
21 Standards and Regulations ......................................54
Table of Contents
D9U001L20-0101_044
1 Symbols and Denitions
1.1 Warning Notices
1.1.1 Types of Warning Notices
Warning notices are dierentiated by the type of danger using the following key words:
CAUTION
WARNING
DANGER
1.1.2 Structure of Warning Notices
SIGNAL WORDS!
Type and source of danger!
1.2 Instructions
Structure of instructions:
Results, if necessary.
1.3 Lists
Structure of bulleted lists:
■
□
●
D9U001L20-0101_04
1.4 Symbols on the Package
THIS WAY UP
DO NOT USE HAND TRUCK HERE
D9U001L20-0101_04
1.5 Symbols and Labels on the Bed
READ INSTRUCTIONS FOR USE.
THERMAL PROTECTION OF TRANSFORMER
-
STRUMENTS
CE MARK
JACK FOR ATTACHMENT OF CONDUCTOR FOR POTENTIAL EQUALISATION
D9U001L20-0101_04
7
DO NOT POLLUTE THE ENVIRONMENT
MANUFACTURER
D9U001L20-0101_04
(POSITION "—" MEANS LOCKED AND POSITION "I"
INSTRUCTIONS FOR CASTOR CONTROL
D9U001L20-0101_04
9
1.6 Acoustic signalisation
SOUND MEANING
CONTINUOUS SOUND
REPEATED BEEP: 0,6s sound / 2,6s silence
BEEP lasting 0,3s
-
BEEP lasting 0,5s
BEEP lasting 3s system error
REPEATED BEEP during 3 minutes: 1,1s sound / 1,1s silen-
ce
D9U001L20-0101_0410
ACCUMULATOR INDICATOR MEANING
lit
ashing: 1,6s lit / 0,2s not lit
ashing: 0,1s lit / 0,1s not lit
ashing: 0,2s lit / 1,6s not lit
not lit
MAINS POWER LED MEANING
lit
ashing: 0,6s lit / 0,6s not lit
ashing: 0,1s lit / 0,1s not lit
not lit
1.7 Visual signalisation
VISUAL
SIGNALISATION
LOCK LED
lit
ashing:
0,6s lit / 0,6s not lit not lit
Thighrest Lock LED
error
error
motion
Backrest Lock LED
error
error
motion
Bed Height, Lateral Tilt, Trende-
lenburg and Antitrendelenburg Tilt
Lock LED
error
error
motion
Foot Control Lock LED
error
error
motion
1.7.1 Mains Power LED (Attendant Control Panel)
1.7.2 Accumulator Indicator (Attendant Control Panel)
1.7.3 Lock LED (Attendant Control Panel)
D9U001L20-0101_04
11
1.8 Denitions
Basic Bed Conguration
Bed Weight
Clearance of Undercarriage
Duty Cycle
Ergoframe
-
Maximum Patient Weight
-
Safe Working Load
Siderail Height
Standard Bed Position ■
■
■
■
Adult
D9U001L20-0101_0412
AC ( ~)
ACP
CE European Conformity
CPR
dBA
DC ( ) Direct Current
CUC
EMC
FET
HF
HPL
HW
ICU
INT. Duty Cycle
IP
IV
LED
ME
ON
OFF
ppm
REF
SCU
SN Serial Number
SW Software
SWL
UDI
USB
WEEE
1.9 Abbreviations
D9U001L20-0101_04
13
2 Safety Instructions
WARNING!
Latera bed should be left in its lowest position when the patient is unattended in order to reduce risk of injury
due to falls!
WARNING!
Siderails of Latera should be located in the „up“ position to reduce the risk of the patient accidentally slipping
or rolling o the mattress!
WARNING!
Incompatible siderails and mattresses can cause an entrapment hazard!
WARNING!
Inappropriate handling of the power supply cord, e. g. by kinking, shearing or other mechanical damages is
hazardous!
WARNING!
When routing cables from other equipment in the Latera bed avoid squeezing those between parts of the Late-
ra bed!
WARNING!
Latera bed should not be used with bed hoists and bed lifts!
WARNING!
The bed is intended for adults.
WARNING!
Incompatible mattresses can create hazards.
WARNING!
To avoid the risk of electric shock, this equipment must only be connected
to a supply mains with protective earth.
WARNING!
No modication of this equipment is allowed.
WARNING!
Do not modify this equipment without authorization of the manufacturer.
WARNING!
If this equipment is modied, appropriate inspection and testing must be
conducted to ensure continued safe use of the equipment.
WARNING!
An additional MULTIPLE SOCKET-OUTLET or extension cord shall not be
connected to the MEDICAL ELECTRICAL SYSTEM.
D9U001L20-0101_0414
WARNING!
During specic investigations or treatments the signicant risks of reciprocal interference posed by ME equip-
ment may occur.
WARNING!
Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the
competent authority of the Member State in which the user and/or patient is established!
WARNING!
Only authorised and trained person using the tool is allowed to change fuses and power supplies!
WARNING!
This medical device is not intended for oxygen enriched environment!
WARNING!
This medical device is not intended for use with ammable substances!
WARNING!
This medical device is not portable medical electrical equipment!
WARNING!
Make sure the duty cycle (2 min ON/18 min OFF) is not exceeded during bed positioning!
WARNING!
Patient is allowed to use selected control elements only if hospital personnel had assessed that the patient´s
physical and psychological state is in accordance with use of them and only if the hospital personnel had
trained the patient in accordance with the instructions for use!
DANGER!
Risk of injury or death due to use of incorrect equipment!
D9U001L20-0101_04
use.
instructions.
manufacturer.
tear.
possible obstacles.
personnel.
■
■
■
D9U001L20-0101_04
3 Intended use
The intended use is the hospitalization of the patient in the acute and long-term care units, which includes above all the
following aspects:
-
hospitalization.
3.1 User population
-
3.2 Contraindications
-
3.3 Operator
4 Incorrect Use
The bed is not suitable for:
■ Patients
□
NOTE
-
■
■
D9U001L20-0101_04
17
5 Product Description
5.1 Latera Acute
7. Foot Control for Lateral Tilt
12. Linen Shelf
NOTE
Fig. Overview of Latera Acute
1
D9U001L20-0101_04
2. Satellite Panel
Fig. Overview of Latera Thema
NOTE
5.2 Latera Thema
D9U001L20-0101_04
19
6 Technical Specication
6.1 Mechanical Specication
Parameter Value
Outer dimensions 219 x 98,5 cm (Latera Acute)
219 x 102,5 cm (Latera Thema)
Mattress Platform Dimensions (Mattress) 200 x 86 cm
Maximum Mattress Height 14 cm (Latera Acute)
18 cm (Latera Thema)
Mattress Platform Extension/Shortening 12,5 cm (Latera Acute, Latera Thema)
Mattress Platform Height Adjustment 43 - 81 cm
Backrest Angle 60° +0/-4
Thighrest Angle 46° +0/-4
Auto-Regression (Length Compensation) of Backrest 11 cm
Lateral Tilt +15°/-15°
Max. Patient Weight for Lateral Tilt 135 kg
Trendelenburg/Antitrendelenburg Tilt +16°/-16°
Weight (Depending on Equipment) 160 kg
Safe Working Load (including Mattress and Accessories) 200 kg
Max. Lifting Pole Load 75 kg
6.2 Environment Conditions
Environmental Conditions - Operation
■ Temperature
■ Humidity
■ Atmospheric Pressure
10 °C — 40 °C
30 % — 75 %
795 hPa — 1060 hPa
Environmental Conditions - Storage and Transport
■ Temperature
■ Humidity
■ Atmospheric Pressure
-20°C — 50°C
20% — 90% (non-condensing)
795 hPa — 1060 hPa
6.3 Electrical Specications
Parameter Value
Input Voltage 230 V, 50/60 Hz
Maximum Power Input 370 VA
Ingress Protection IP54
Safety Class Class I (with type B applied parts)
Electrical Motor Operation Time max. 2 min ON / 18 min OFF
NOTE
D9U001L20-0101_0420
6.4 Electromagnetic compatibility
-
WARNING!
It is recommended to avoid the use of this device next to or in block with other device, because it could lead to
improper operation. If such use is needed, this device and the other equipment should be under surveillance
to verify proper operation.
List of used cables:
WARNING!
Use of the accessories, converters and other cables, than specied and provided by manufacturer of this bed
could lead to increase of electromagnetic emission or lower the electromagnetic immunity of this bed and lead
to improper operation.
WARNING!
Mobile RF communication device (including end use devices like antenna cables and external antenna) should
not be used closer than 30 cm (12 inches) from any part of this bed Latera, including cables specied by manu-
facturer. Otherwise this could lead to deterioration of functionality of this bed.
WARNING!
Do not overload the bed (SWL), respect the duty cycle (INT.) and consider chapter 18 Maintenance in order to
maintain the basic safety with regard to electromagnetic disturbances for the expected service life.
6.4.1 Manufacturer instructions - electromagnetic emissions
Emission Test Compliance
RF emissions
CISPR 11
RF emissions
CISPR 11
Class A
Harmonic emissions
Class A
Complies
Table of contents
Other LINET Medical Equipment manuals
LINET
LINET PRECIOSO 2 Series User manual
LINET
LINET ELEGANZA 5 User manual
LINET
LINET ELEGANZA 1 Parts list manual
LINET
LINET Praktika 2 Parts list manual
LINET
LINET GRACIELLA Parts list manual
LINET
LINET SELLA User manual
LINET
LINET MULTICARE 2015 User manual
LINET
LINET LATERA ACUTE User manual
LINET
LINET Sprint 100 User manual
LINET
LINET Image 3 B Parts list manual
LINET
LINET LINIS SafetyPort User manual
LINET
LINET ELEGANZA 5 Parts list manual
LINET
LINET Image 3 B Parts list manual
LINET
LINET EffectaCare 20 User manual
LINET
LINET Eleganza 1 LE Parts list manual
LINET
LINET Sprint 100 Parts list manual
LINET
LINET Praktika 1 User manual
LINET
LINET ELEGANZA 5 Parts list manual
LINET
LINET Multicare X Parts list manual
LINET
LINET Eleganza 2 Parts list manual
Popular Medical Equipment manuals by other brands
MedRx
MedRx Avant Training manual
ResMed
ResMed Stellar 150 quick start guide
Bridge Network
Bridge Network SmartCam Instructions for installing and using
KLS Martin group
KLS Martin group LIMAX 60 Instructions for use
Integra
Integra MAYFIELD A1109 instruction manual
Dentsply Sirona
Dentsply Sirona Cerec Guide 2 operating instructions
MedGuard
MedGuard SUPER VEGA User instruction manual
Albrecht
Albrecht CDS Knee Brace Flexion L/L User instructions
Chattanooga Group
Chattanooga Group Intelect Transport Combo Service manual
Phcbi
Phcbi MDF-U443 operating instructions
Fukuda Denshi
Fukuda Denshi HJ-500 Service manual
Ergotron
Ergotron StyleView quick reference
