Linksys USB200M User manual

Model No.
Quick Installation Guide
A Division of Cisco Systems, Inc.
®
WIRED
USB200M (EU/UK/LA)
Compact USB 2.0
Package Contents
• Compact USB 2.0 10/100 Network
Adapter
• Installation CD with User Guide
•NetworkCable
• Quick Installation
Network Adapter
10/100

2
1
AWith your PC turned off, insert
the Adapter’s USB end (or the
end of the USB extension cable
connected to the Adapter)
into your PC’s USB port or USB
hub.
BInsert one end of an Ethernet
network cable into the
Adapter’s RJ-45 port.
CInsert the other end of the
Ethernet network cable into an
Ethernet networking device.
Proceed to Step 2.
Connecting the Compact USB 2.0
10/100 Network Adapter to Your PC
NOTE: For maximum speed,
connect the Adapter to a USB
2.0 port on your PC. If you are
using a hub, make sure it is a
USB 2.0 hub.

3
2
C
B
Windows XP
AIf you haven’t already, start your
computer.
BWindows XP will detect the
Adapter connected to your
computer and display the Wel-
come to the Found New Hard-
ware Wizard screen. Select
Install from a list or specific
location (Advanced), and insert
the Driver CD into the CD-ROM
drive. Then Click Next.
CSelect Search for the best
driver in these locations. Only
select Include this location in
the search:, and enter D:\winxp
in the field. Click Next.
DWhen you are notified that the
driver has not passed Windows
Logo testing, click Continue
Anyway.
Installing the Driver for the Compact
USB 2.0 10/100 Network Adapter
NOTE: Do not click Cancel at any time during the installation process. Doing so
will prevent your driver from being properly installed on your PC..
NOTE: Throughout this document, it is assumed that “D” is the letter of your
CD-ROM drive.
After connecting the Adapter to your computer’s USB port or hub, follow these
instructions to install the hardware device driver.
The installation procedures for the device driver vary depending on your PC’s oper-
ating system, so make sure to follow the instructions for your operating system.
D

4
C
E
D
E
EThe Completing the Found
New Hardware Wizard screen
will appear. Click Finish.
Remove the Driver CD from the
drive.
Congratulations! The installation of
the Compact USB 2.0 10/100
Network Adapter is complete.
Windows 2000
AIf you haven’t already, start
your computer.
BWindows 2000 will automati-
cally detect the Adapter con-
nected to your computer.
When the Welcome to the
Found New Hardware Wizard
screen appears, insert the
Driver CD into the CD-ROM
drive. Then Click Next.
CSelect Search for a suitable
driver for my device (recom-
mended). Click Next.
DSelect Specify a location to
find the correct driver. Click
Next to continue.
EIn the Copy manufacturer’s
files from: field, enter
D:\win2000. Then click OK.

5
F
B
FThe Driver Files Search Results
screen will appear. Click Next.
For Windows 2000, you may be
informed that a digital signa-
ture has not been found. Click
Yes.
GThe Completing the Found
New Hardware Wizard screen
will appear. Click Finish, and
remove the Driver CD from the
CD-ROM drive.
Congratulations! The installation of
the Compact USB 2.0 10/100
Network Adapter is complete.
Windows Millenium
AIf you haven’t already, start
your computer.
BWindows Millennium will auto-
matically detect the Adapter
connected to your PC. When
the Add New Hardware Wizard
screen appears, insert the
Driver CD into your CD-ROM
drive, and select Specify the
location of the driver
(Advanced). Click Next.

6
D
C
E
CSelect Search for the best
driver for your device (Rec-
ommended). You MUST
remove the checkmark from
the box next to Removable
Media. Select Specify a loca-
tion:, and enter D:\winME in
the field provided. Then click
Next.
DWhen Windows notifies you
that it is ready to install the
driver files, click Next.
When Windows has completed
copying the driver files, click
Finish.
EWhen asked if you want to
restart your computer, remove
the Driver CD from the CD-
ROM drive, and click Yes. If
Windows does not ask you to
restart your PC, restart your PC
anyway.
Congratulations! The installation of
the Compact USB 2.0 10/100
Network Adapter is complete.

7
C
D
E
Windows 98
AIf you haven’t already, start your
computer.
BWindows 98 will automatically
detect the Adapter con-
nected to your PC. When the
first Add New Hardware Wizard
screen appears, insert the
Driver CD into your CD-ROM
drive, and Click Next.
CSelect Search for the best
driver for your device (Recom-
mended), and click Next.
DSelect Specify a location: to
find the correct driver, and
enter D:\win98 in the field pro-
vided. Click Next to continue.
EWhen Windows notifies you that
it is ready to install the driver
files, Click Next to continue.

8
F
For additional information or troubleshooting
help, refer to the User Guide on the Setup CD-
ROM. You can also email for further support.
Website
http://www.linksys.com/international
Registration
http://www.linksys.com/registration
Linksys is a registered trademark or trademark of
Cisco Systems, Inc. and/or its affiliates in the U.S.
and certain other countries. Copyright © 2005
Cisco Systems, Inc. All rights reserved.
USB200Mv2-EU-QIG-50711A BW
FWindows will begin copying the
driver files to your computer. If
Windows asks you for the origi-
nal Windows CD-ROM, insert
the CD-ROM, and direct Win-
dows to the proper location for
the CD-ROM (e.g., D:\). If you
have the Windows 98 setup
files already installed in a direc-
tory, click OK, and enter C:\win-
dows\options\cabs (if “C” is the
letter of your hard drive) in the
windows that appears. When
Windows has completed copy-
ing the files, Click Finish.
GWhen asked if you want to
restart your computer, remove
the Driver CD from the CD-
ROM drive, and Click Yes. If
Windows does not ask you to
restart your PC, restart anyway.
Congratulations! The installation of
the Compact USB 2.0 10/100
Network Adapter is complete.

Modelnr.
Installationsvejledning
A Division of Cisco Systems, Inc.
®
KABEL-
BASERET
USB200M (DK)
Kompakt USB 2.0
Pakkens indhold
• Kompakt USB 2.0 10/100-adapter
• Installations-cd med brugervejledning
• Netværkskabel
• Installationsvejledning
Adapter
10/100

2
1
AMens pc'en er slukket skal du
indsætte kortets USB-ende
(eller enden af det USB-
forlængerkabel, som er
tilsluttet adapteren) i pc'ens
USB-port eller USB-hub.
BSlut den ene ende af et
Ethernet-netværkskabel til RJ-
45-porten på adapteren.
CSlut den anden ende af
Ethernet-netværkskablet til en
Ethernet-netværksenhed.
Fortsæt til trin 2.
Tilslutning af den kompakte USB 2.0
10/100-adapter til din pc
BEMÆRK: Den maksimale
hastighed opnås ved at tilslutte
adapteren til en USB 2.0-port på
pc'en. Hvis du bruger en hub,
skal du kontrollere, at det er en
USB 2.0-hub.
