PRODUCT DATA
BUSINESS SERIES
Wireless-N
Business Notebook Adapter
Model: WPC4400N
High-speed Wireless-N Notebook
Network Adapter for your business
The Wireless-N Notebook Adapter is the simple way to add or upgrade wireless connectivity in
your notebook computer. Just slide it into your notebook’s PC Card slot and enjoy incredible
high-speed wireless network access while retaining true mobility.
The Wireless-N Notebook Adapter uses the very latest wireless networking technology,
Wireless-N (draft 802.11n). By overlaying the signals of multiple radios,Wireless-N’s ”Multiple
In, Multiple Out” (MIMO) technology multiplies the effective data rate. Unlike ordinary wireless
networking technologies that are confused by signal reflections, MIMO actually uses these
reflections to increase the range and reduce ”dead spots”in the wireless coverage area. The robust
signal travels farther, maintaining wireless connections significantly further than standard
Wireless-G.
With Wireless-N, the further away you are, the more speed advantage you get. It works great with
standard Wireless-G and -B equipment, but when both ends of the wireless link are Wireless-N, the
throughput can be increased even more by using twice as much radio band.
Once you’re connected you can keep in touch with your e-mail,access the Internet, and share files and
other resources, like printers and network storage, with other computers on the network. It doesn’t
matter where your work takes you, you can access the web or use instant messaging to communicate
with your virtual office. You will also be able to connect with any of the growing number of public
hotspots in coffee shops, airport lounges, hotels, and convention centers. Your wireless connection is
protected by industrial-strength WPA2 encryption. The included Setup Wizard will walk you through
configuring the adapter to your network’s settings, step by step.
The incredible speed of Wireless-N makes the Adapter ideal for media-centric applications, like streaming
video and Voice over IP telephony.You will have plenty of bandwidth to simultaneously run multiple
media-intense data streams through the network with no degradation in performance. Get your notebook
connected to Wireless-N,Wireless-G, and Wireless-B networks with the Wireless-N Notebook Adapter from
Linksys.
Used together with a Linksys WAP4400N, the New AP and New Client Detection functions detect and
alert you of a previously unseen AP or a new client.Visibility and protection combined with versatility and
performance make the Wireless-N Notebook Network Adapter ideal for your business needs.
High-speed Wireless-N
Notebook Adapter for your
business
MIMO technology uses
multiple radios to create a
robust signal that travels
farther and reduces dead spots
Significantly faster than
Wireless-G, but can also
connect to Wireless-G and -B
networks
Advanced wireless security
using Wi-Fi Protected Access™
(WPA2) with up to 256-bit
encryption, and New AP/Client
detection gives your business
the visibility and protection
it needs
WPC4400N

PRODUCT DATA
BUSINESS SERIES
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more
than 50 countries, supported by
12 Linksys Regional Offices throughout
the world.For a complete list of local
Linksys Sales and Technical Support
contacts, visit our Worldwide Web Site
at www.linksys.com.
Features
Wireless-N (Draft 802.11n)
wireless networking
technology
Increases range and speed
over Wireless-G (802.11g)
standard
Performance Investment
Protection: Compatibility
with Wireless-B (802.11b)
and Wireless-G (802.11g)
Standards
Easy-to-use Setup Wizard
Security Monitor (New
AP Detection, New Client
Detection - detected by AP)
Supports WEP,WPA-Personal,
WPA2-Personal,
WPA-Enterprise,
WPA2-Enterprise,
authentication (802.11i
ready)
32-bit CardBus Interface
Plug-and-Play operation
provides easy setup
Compatible with Microsoft
Windows 2000 SP4 (or later),
and XP SP2 (or later)
•
•
•
•
•
•
•
•
•
WPC4400N-DS-60719-SW
Check the product package and contents for specific features supported.Specifications are subject to change without notice. Linksys is a registered trademark or
trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems,Inc.All rights reserved.Other brands and
product names are trademarks or registered trademarks of their respective holders.
Model: WPC4400N
Wireless-N
Business Notebook Adapter
Specifications
Model WPC4400N
Standards Draft IEEE802.11n, IEEE802.11g, IEEE802.11b,
802.1x (Security Authentication), (802.1i),
802.11b/802.11g/Wireless-N (20MHz/40MHz)
Channels 11 channels (US, Canada)
13 channels (Europe)
LEDs Power, Link
Modulations 802.11b: DSSS: CCK, QPSK, BPSK
802.11g: OFDM
Wireless-N: OFDM
Transmitted Power 802.11b: 17 dBm@1TX; 20 dBm@2TX
802.11g: 13 dBm@1TX; 16 dBm@2TX
Wireless-N: 13 dBm@1TX/Span 20; 16 dBm@2TX/Span 20
Wireless-N: 13 dBm@1TX/Span 40; 16 dBm@2TX/Span 40
Tolerance: +/- 1.5dB
Receive Sensitivity -86dBm @ 802.11b, 11Mbps, PER <= 8%
-75dBm @ 802.11g, 54Mbps, PER <= 10%
-88dBm @ Wireless-N 6.5Mbps, PER <= 10%
-70dBm @ Wireless-N 65Mbps, PER <= 10%
-69dBm @ Wireless-N 135Mbps, PER <= 10%
Power Consumption TX: <600mA @ 2TX (Maximum)
RX: <550mA @ 3RX (Maximum)
Security features WEP, WPA-Personal, WPA-Enterprise, WPA2-Personal, WPA2
Enterprise, Security Monitor with New AP and New Client Detection
Environmental
Dimensions 4.88” x 0.53” x 2.13”
W x H x D (124 mm x 13.5 mm x 54 mm)
Unit Weight 0.11 lb (5 g)
Power 3.3V
Certification FCC
Operating Temp. 0 to 60ºC (32 to 140ºF)
Storage Temp. -20 to 80ºC (-4 to 176ºF)
Operating Humidity 10% to 80% non-condensing
Storage Humidity 5% to 90% non-condensing
Package Contents
Wireless-N Business Notebook Adapter
Setup Wizard CD-ROM
User Guide on CD-ROM
Quick Installation
Minimum Requirements
600 MHz or Faster PC
At Least 256 MB of RAM Memory
CD-ROM Drive
Available CardBus Slot for Wireless-N Business Notebook Adapter
Windows 2000 with Service Pack 4 (or later), or XP with Service Pack 2 (or later)
•
•
•
•
•
•
•
•
•
