Linksys WUSB54GC EU Operation manual

Model No.
Product Data
Wireless
WUSB54GC
The easy way to connect your desktop or
notebook to a high-speed wireless network!
Connect your USB-equipped desktop or notebook computer to a wireless
network at incredible speeds with the Linksys Compact Wireless-G USB Adapter.
By incorporating USB 2.0 and Wireless-G the Adapter delivers data rates up to
54Mbps (5 times as fast as 802.11b), without the trouble of opening up the
case of your desktop computer.
To install, simply plug the Adapter into any available USB port. (It's compatible
with both USB 1.1 and 2.0 ports, but 2.0 will yield the fastest speeds.) You can
plug it directly into your PC, or use the included USB extension cord to put the
Adapter anywhere you'd like, up to five feet away.
The new push button setup feature makes it easy to configure your wireless
devices. Just push the button on the Access Point and on your other
SecureEasySetup-enabled wireless device to automatically create a safe
connection, protected by the industrial-strength security of Wireless Protected
Access (WPA). It gets its power through the USB connection, so no power cord is
necessary. The included Setup Wizard walks you through configuring the
Adapter to your wireless network settings, step by step. The Compact Wireless-G
USB Adapter is also compatible with the Wireless-B (802.11b) network standard,
with data rates up to 11Mbps.
The Compact Wireless-G USB Adapter lets you put your computer almost
anywhere in the building, without the cost and hassle of running cables. Now
you don't have to drill holes in your walls and climb through the attic or cellar to
get connected to the network. Once you're connected, you can keep in
touch with your e-mail, access the Internet, use instant messaging to chat with
friends, and share files and other resources such as printers and hard disk
storage space with other computers on the network. You'll also be able to
connect with any of the growing number of public hotspots springing up in
coffee shops, airport lounges, hotels and convention centers.
So don't hassle with running cables through your house—get connected the
easy way with the Compact Wireless-G USB Adapter.
USB Adapter
Wireless-G
Connects your desktop or
notebook to a wireless
network at up to 54Mbps
when used with a
USB 2.0 port
Wireless communications
are protected by WPA and
up to 128-bit data
encryption
Easy, no-tools setup on
any desktop or notebook
computer with USB support
Push button setup feature
makes wireless
configuration secure
and simple
Compact

Model No.
Product Data
Model No.
Linksys
A Division of Cisco Systems, Inc.
18582 Teller Avenue
Irvine, CA 92612 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more than
50 countries, supported by 12 Linksys Regional
Offices throughout the world. For a complete list of
local Linksys Sales and Technical Support contacts,
visit our Worldwide Web Site at www.linksys.com.
WUSB54GC
Package Contents
• Compact Wireless-G USB Adapter
• USB Extension Cable
• Setup Wizard CD-ROM
•UserGuideonCD-ROM
• Quick Installation
Wireless-G
Minimum Requirements
• 400 MHz or Faster PC
• 128 MB of RAM Memory
• CD-ROM Drive
• Available USB Port
• Windows 98SE, Me, 2000 or XP with
Service Pack 1 (or later)
Specifications
Model Number WUSB54GC
Standards IEEE 802.11g, IEEE 802.11b, USB 1.1, USB 2.0
Channels 802.11b / 802.11g
11 Channels (US, Canada)
13 Channels (Europe)
14 Channels (Japan)
LEDs Link
Protocols 802.11b: CCK (11 Mbps), DQPSK (2 Mbps),
DBPSK (1 Mbps); 802.11g: OFDM
Transmitted Power 802.11g: 13 ± 1 dBm (Typical)
802.11b: 17 ± 1 dBm (Typical)
Receive Sensitivity 11Mbps @ -80dBm (Typical)
54Mbps @ -65dBm (Typical)
Security features WEP and WPA Encryption
WEP Key Bits 64 Bit and 128 Bit
Environmental
Dimensions 3.86" x 0.43" x 1.10"
W x H x D (98 mm x 11 mm x 28 mm)
Unit Weight 0.05 lbs. (0.023 kg)
Certifications FCC, Wi-Fi (802.11b/g)
Operating Temp. 0ºC ~ 45ºC (32ºF ~ 113ºF)
Storage Temp. -20ºC ~ 60ºC (-4ºF ~ 140ºF)
Operating Humidity 10% ~ 85% Non-Condensing
Storage Humidity 5% ~ 90% Non-Condensing
WUSB54GC-DS-51103NC JL
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc.
and/or its affiliates in the U.S. and certain other countries. Copyright © 2005 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their
respective holders.
USB Adapter
Features
• Compatible with 802.11g
and 802.11b (2.4GHz)
Standards
• Supports USB 2.0 with up to
54Mbps, High-Speed Data
Transfer Rate with Automatic
Fallback
• Plug-and-Play Operation
Provides Easy Setup
• Supports up to 128-bit WEP
and WPA Encryption Security
• Plug-and-Play Operation
Provides Easy Setup
• Compatible with Microsoft
Windows 98SE, Me, 2000,
and XP
Compact
