Linksys WAG54GP2 Operation manual

Model No.
Product Data
Wireless
WAG54GP2
The All-In-One Solution for Internet
Connectivity and Telephony!
ADSL2+ Modem,
Internet-sharing
Router, 4-Port Switch
and Wireless-G Access
Point in one box
Two standard phone
jacks enable feature-
rich telephone service
over your DSL Internet
connection
High-speed ADSL2+
Modem gives you a
fast, "Always On"
connection to the
Internet
Connect your home PCs and other
wireless devices to the Gateway and
the Internet using the built-in Wireless-
G Access Point, or connect directly
with the 4-port Ethernet Switch
The Linksys Wireless-G ADSL Gateway with 2 Phone Ports is the all-
in-one solution for Internet connectivity. The ADSL Modem func-
tion gives you a blazing fast connection to the Internet, far faster
than a dial-up, and without tying up your phone line.
Connect your computers to the Gateway via the built-in 4-port
10/100 Ethernet Switch. Attach four PCs directly, or connect
more hubs and switches to create as big a network as you
need. The built-in Wireless-G (802.11g) Access Point lets you
connect up to 32 wireless devices to your network at up to a
blazing 54Mbps, without running cables through the building. It's
also compatible with Wireless-B (802.11b) devices, at up to
11Mbps. Once your PCs are hooked up, you can share files,
printers, hard drive space and other resources and the Gate-
way's Router function lets your whole network share your high-
speed Internet connection.
Finally, there's a built-in phone adapter which enables high-
quality feature-rich telephone service through your high-speed
connection even while you're surfing the Internet. There are two
standard telephone jacks, each operating independently -- like
having two phone lines. With an appropriate Internet telephone
service provider, you'll get low domestic and international
phone rates and lots of other available special phone features.
To protect your data and privacy, the Wireless-G ADSL Home
Gateway features an advanced firewall to keep Internet intrud-
ers and attackers out. Wireless transmissions can be protected
by powerful WPA data encryption. Configuration is a snap with
any web browser.
With the Linksys Wireless-G ADSL Gateway with 2 Phone Ports at
the heart of your network, you're connected to the future.
ADSL Gateway with 2 Phone Ports
Wireless-G

Model No.
Product Data
Model No.
Linksys
A Division of Cisco Systems, Inc.
18582 Teller Avenue
Irvine, CA 92612 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more than 50 coun-
tries, supported by 12 Linksys Regional Offices
throughout the world. For a complete list of local Link-
sys Sales and Technical Support contacts, visit our
Worldwide Web Site at www.linksys.com.
WAG54GP2
Package Contents
• Wireless-G ADSL Gateway with 2 Phone Ports
• Power Adapter
•UserGuideonCD-ROM
•NetworkCable
• Phone Cable (2)
• Quick Installation
• Registration Card
Wireless-G
Minimum Requirements
• PC with a Network Adapter and the TCP/IP Pro-
tocol installed
• CD-ROM Drive
• Internet Explorer 4.0 or Netscape Navigator 4.7
or Higher for Web-based Configuration
• Activated ADSL line
• Activated Voice over IP service
Specifications
Model Number WAG54GP2
Standards IEEE 802.11g, IEEE 802.11b, IEEE 802.3u, G.992.1 (G.dmt),
G.992.2 (G.lite), T1.413i2 Issue 2, G.992.3 (Annex A), G.992.5 (Annex A)
Ports Power, ADSL, Ethernet (1-4), Phone (1-2)
Button Reset
Cabling Type CAT 5 UTP, RJ11
LEDs Power, Wireless-G, Ethernet (1-4), Phone (1-2), DSL, Internet
Transmit Power 18 dBm
UPnP able/cert Able
Security features Password protected configuration for web access
PAP and CHAP authentication, Denial of Service (DoS) Prevention
URL filtering, and keyword, Java, ActiveX, Proxy, Cookie blocking
ToD filter (Blocks Access by Time)
VPN Passthrough for IPSec, PPTP, and L2TP Protocols
128, 64 bits WEP with Passphrase WEP key generation
SSID Broadcast Disable
Access restriction by MAC and IP addresses, WPA
WEP Key Bits 64, 128
Environmental
Dimensions 6.69" x 6.69" x 1.22"
W x H x D (170 mm x 130 mm x 31 mm)
Unit Weight 0.90 lbs. (0.408 kg)
Power 12VDC 1.25A
Certifications FCC Part 15B Subpart B Class B, FCC Part 15C Subpart B, FCC Part 68,
CE, UL, A-tick, WiFi, UPnP
Operating Temp. 32ºF to 104F (0ºC to 40ºC)
Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)
Operating Humidity 10% to 85% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing
Warranty 3-Years Limited
WAG54GP@-DS-51005 KL
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2005
Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
ADSL Gateway with 2 Phone Ports
Features
• Supports 802.11g and 802.11b wireless LAN
• Built-in ADSL modem with G.lite, G.dmt, and T1.
413 support
• Supports 4 10/100 Auto MDI/MDI-X LAN switch
ports
• Enhanced security management functions: Port
Filtering, MAC and IP Address Filtering, DMZ Host-
ing, and NAT Technology
• Build-in web graphical user interface for easy
configuration from any web browser
• Support for RFC1483, PPPoE and PPPoA con-
nections
• Statefull Packet Inspection (SPI) firewall with
Denial of Service (DoS) prevention
• Wireless Access Lists to enhance wireless secu-
rity
• Supports VPN Passthrough for IPSec, PPTP, and
L2TP Protocols
• Supports Static and Dynamic Routing (RIP1 and
2)
• DHCP Server capability to assign IP addresses
automatically
• Remote administration and remote upgrades
available over the Internet
• Email and Web-based Logging of Security
Events
• Supports traffic and event logging
• Support for NTP (Network Time Protocol) for Syn-
chronizing with a Real-Time Server
• Support for Broadcast SSID Disable
• Supports Session Initiation Protocol (SIP)
• Supports DTMF tone detection and generation
• Supports Echo Cancellation (G.168)
• Supports multiple voice compression G.711,
G.726, G.729, G.723
