Linksys RV082 Operation manual

Model No.
Product Data
WIRED
RV082
The heart of your connection-redundant
secure small office network
A high-reliability
Internet connection-
sharing router and
8-port switch for small
business
Advanced SPI firewall
protects your PCs from
most known Internet
attacks
Features dual Internet
ports for load balancing
and connection redun-
dancy
Securely connects
up to 50 remote
office or traveling
users to your office
network via VPN
The Virtual Private Network (VPN) capability
creates encrypted "tunnels" through the
Internet, allowing up to 50 remote office or
traveling users to securely connect into your
office network from off-site. Users connecting
through a VPN tunnel are attached to your
company's network -- with secure access to
files, e-mail, and your intranet -- just as if they
were in the building. You can also use the VPN
capability to allow users on your small office
network to securely connect out to a
corporate network.
The 10/100 8-Port VPN Router can serve as a
DHCP Server, and has a powerful SPI firewall to
protect your PCs against intruders and most
known Internet attacks. It can be configured
to filter internal users' access to the Internet,
and has IP address filtering so you can specify
exactly who has access to your network.
Configuration is a snap with the web browser-
based configuration utility.
As the heart of your small office network, the
connection-redundant Linksys 10/100 8-Port
VPN Router gives you the connection reliability
your business needs.
8-Port VPN Router
The Linksys 10/100 8-Port VPN Router is an advanced
Internet-sharing network solution for your small business
needs. Like any router, it lets multiple computers in your
office share an Internet connection. But the unique dual
Internet ports on the 10/100 8-Port VPN Router let you
connect a second Internet line as a backup to insure that
you're never disconnected. Or, use both Internet ports at
the same time, and let the router balance your office's
requirements between them for maximum bandwidth
efficiency.
The 10/100 8-Port VPN Router also features a built-in 8-port
full-duplex 10/100 Ethernet switch to connect eight PCs
directly, or you can connect more hubs and switches to
create as big a network as you need.
10/100

Product Data
Model No.
Features
• Stateful Packet Inspection
Firewall for maximum security
• 2 WAN ports for load bal-
anced connectivity to the
Internet
• 8-Port 10/100 Switch supports
Auto-MDI/MDIX and up to
200Mbps of throughput per
port
• IP filtering allows for restricted
access to the Internet and
other network resources
• Full IPSec Virtual Private
Network (VPN) Capability
using DES and 3DES
Encryption Algorithms
• Support for MD5 and SHA
Authentications Algorithms
• Create up to 50 simultaneous
IPSec VPN Tunnels
• Management via Web, Telnet,
SNMP, and Setup Wizards
make setup easy for
Administrators
Linksys
A Division of Cisco Systems, Inc.
18582 Teller Avenue
Irvine, CA 92612 USA
E-mail: [email protected]
[email protected]
Web: http://www.linksys.com
Linksys products are available in more than 50
countries, supported by 12 Linksys Regional Offices
throughout the world. For a complete list of local
Linksys Sales and Technical Support contacts, visit
our Worldwide Web Site at www.linksys.com.
RV082
Specifications
Model Number RV082
Standards IEEE 802.3, IEEE 802.3u
Ports 8 10/100 RJ-45 Ports, 1 10/100 RJ-45 Internet Port,
1 10/100 RJ-45 DMZ/Internet Port
Buttons Reset
Cabling Type Category 5 Ethernet
LEDs
System, Internet, DMZ/Internet, DMZ Mode, Diag, 1-8
UPnP able/cert Yes
Security Features SPI Firewall, DES and 3DES Encryption for IPSec
VPN Tunnel
Environmental
Dimensions 11" x 1.75" x 9.50"
(W x H x D) (279 mm x 44 mm x 241 mm)
Unit Weight 3.25 lbs. (1.5 kg)
Power Input: AC100~240V, 0.2A; Output: DC 3.3V / 3A
Certifications FCC Class B, CE Class B
Operating Temp. 32ºF to 104ºF (0ºC to 40ºC)
Storage Temp. 32ºF to 158ºF (0ºC to 70ºC)
Operating Humidity 10% to 85%, Non-Condensing
Storage Humidity 5% to 90%, Non-Condensing
RV082-DS-31208NC-BW
Package Contents
• One 10/100 8-Port VPN Router
• One AC Power Cable
• One Setup CD with User Guide in PDF format
• One Registration Card
• Rackmounting Kit
Minimum Requirements
• Broadband Connection for Interent
Connection Sharing
• TCI/IP Protocol installed on each PC
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2003
Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
8-Port VPN Router
10/100
