BUSINESS SERIES
PRODUCT DATA
Model: WET200
Wireless-G Business
Ethernet Bridge
High-Speed Wireless Bridging for Small
Businesses
The Linksys WET200 Wireless Bridge seamlessly bridges separate Ethernet networks
together wirelessly and is ideal for small businesses with offices and resources that
are in different office suites of a building or a closely adjacent building. The WET200
is a Power over Ethernet (PoE) end device so it can be installed anywhere an Ethernet
cable can be run if there is not ready access to a power outlet. PoE enables delivery
of both data and power to the WET200. An AC adapter is also included if the device
installation site has a power outlet nearby.
Advanced security features include Wi-Fi Protected Access™ (WPA2 Enterprise) with up
to 256-bit AES encryption using EAP (Extensible Authentication Protocol) giving small
businesses the protection they need to communicate and transfer data securely. The
integrated QoS features provide consistent voice and video quality on both the wired
and wireless networks, enabling the deployment of business qualilty VoIP and video
applications.
Additional support for VLANs, SNMP, Spanning Tree, and Port Mirroring make this an ideal
solution for network administrators to incorporate into larger organizations.
RangeBooster technology is a compatible add-on to standard Wireless-G that increases
wireless signal range up to two times and throughput by up to 35%. Unlike ordinary wireless
technologies that are hampered by signal reflections, RangeBooster devices use smart
antennas and embedded processors to detect and decode reflected signals to enhance and
boost data throughput. This capability also helps to reduce or eliminate “dead spots” within the
wireless coverage area as well.
.
5-port Wireless Bridge
for securely connecting
separate wired networks
Standards-based POE (IEEE
802.3af) or External DC
power provides flexible
installation
RangeBooster technology
for up to twice the range,
reduced dead spots,
and up to 35% more
throughput than standard
802.11g
Advanced wireless
security using Wi-Fi
Protected Access™ (WPA2
Enterprise) with up to
256-bit AES encryption
WET200

PRODUCT DATA
BUSINESS SERIES
Features
5 port 10/100 Base-T
Ethernet Managed Switch,
Autosensing half/full duplex
& MDI/MDI-X
Supports 802.11b and
802.11g wireless connection
to Access Point
Easy installation and
configuration Web Interface
Supports WEP,WPA-PSK,
WPA2-PSK,WPA-ENT, WPA2-
ENT wireless encryption
Supports 802.1X, EAP-TLS,
PEAP authentication with
Radius server
SMA detachable Dipole
antennas with 1x2 MIMO to
increase coverage
Supports Power over
Ethernet (PoE) or external
DC power
Supports SNMP and
intuitive Web-based
interface
Support 802.1Q and port-
based VLAN on LAN switch
- 1 VLAN bridged over
wireless
Support 802.1p, IP TOS, and
DSCP based QoS on LAN
switch,WMM on wireless Tx
Support Rate Limiting on
both wired switch and
wireless interface
Support Spanning Tree
protocol, port mirroring, and
MAC-based ACL
3 year limited warranty
•
•
•
•
•
•
•
•
•
•
•
•
•
Wireless-G Business Ethernet Bridge
Specifications
Model WET200
Standards IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u, IEEE802.3af (Power
Over Ethernet), 802.1p (QoS priority), 802.1Q (VLAN), 802.1X (Security
Authentication), 802.11i - Ready (Security WPA2), 802.11e - Ready (Wireless QoS)
Ports 5x 10/100 Base-T Ethernet, 12 VDC Power
Buttons Reset
Cabling Type UTP CAT 5
LEDs Power, POE, Wireless, Ethernet 1-5
Operating System Linux
Setup/Config
WebUI Built in Web UI for Easy browser-based configuration (HTTP/HTTPS)
Management
SNMP Version SNMP Version 1, 2c, 3
Web F/W upgrade Firmware Upgradable Through Web-Browser
DHCP DHCP Client
Operating Modes
Wireless Client Infrastructure or Ad-Hoc
Wireless
Spec/Modulation Radio and Modulation Type: 802.11b/DSSS, 11g/OFDM
Channels Operating Channels: 11 North America, 13 Most of Europe (ETSI and Japan)
# of Internal Ant. None
# of External Ant. 2 (Omni-Directional) SMA detachable
Transmit Power Transmit Power (Adjustable) @ Normal Temp Range:
11b: 12± 1 dBm; 11g: 16± 1 dBm
Antenna Gain in dBi 2
Receiver Sensitivity 11g: 54Mbps@ -69dBm, 11b: 11Mbps@ -82dBm
Security
WEP/WPA/WPA2 WEP 64bit/128bit, WPA-PSK, WPA2-PSK, WPA-ENT, WPA2-ENT
Access Control MAC-Based ACL between wired and wireless interfaces
802.1X IEEE 802.1X support
Quality of Service
QoS 4 queues
Queue mapping on ingress based on default priority, 802.1p tag, DSCP & IP ToS
Rate limiting on both ingress and egress direction
General
16 VLAN groups
256 MAC address entries across wireless bridge
1024 MAC address entries in the switch
Environmental
Dimensions 6.69" x 8.07" x 7.68" (170 x 205 x 195 mm)
Weight 12.17 oz (345 g)
Power 12V 0.5A DC input, and IEEE802.3af Compliant PoE
Max. power draw: 4.2 Watt
Certification FCC, ICES-003, CE
Operating Temp. 32ºF to 104ºF (0ºC to 40ºC)
Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)
Operating Humidity 10% to 85% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing

PRODUCT DATA
BUSINESS SERIES
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]
Web: www.linksys.com
Linksys products are available in more
than 50 countries, supported by
12 Linksys Regional Offices throughout
the world. For a complete list of local
Linksys Sales and Technical Support
contacts, visit our worldwide website
at www.linksys.com
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or
trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2007 Cisco Systems, Inc. All rights reserved. Other brands
and product names are trademarks or registered trademarks of their respective holders.
70716A-BW Model: WET200
Package Contents
Wireless-G Business Ethernet Bridge
2 x SMA detachable Dipole antennas
User Guide on CD-ROM
Quick Installation Guide
Ethernet Network Cable
Power Adapter
Product Stands
Registration Card
Minimum Requirements
PC or devices with Ethernet port
802.11b or 802.11g Wireless Access Point
Switch/Router with Power Over Ethernet (PoE) Support Or PoE Injector when used with POE
Web-Based Configuration Java-Enabled Web Browser
•
•
•
•
•
•
•
•
•
•
•
•
