High-speed Wireless-N networking for your desktop computer
Product Data
Model WMP300N
Wireless-N
PCI Adapter
The Linksys Wireless-N PCI Adapter installs in most desktop and tower PCs, and
lets you put your computer almost anywhere in the building without the cost and
hassle of running network cables. Now you don't have to drill holes in your walls
and climb through the attic or cellar to get connected to the network.
The Wireless-N PCI Adapter uses the very latest wireless networking technology,
Wireless-N (draft 802.11n). By overlaying the signals of multiple radios,
Wireless-N's “Multiple In, Multiple Out” (MIMO) technology multiplies the
effective data rate. Unlike ordinary wireless networking technologies that are
confused by signal reflections, MIMO actually uses these reflections to increase
the range and reduce “dead spots” in the wireless coverage area. The robust
signal travels farther, maintaining wireless connections up to 4 times farther than
standard Wireless-G.
With Wireless-N, the farther away you are, the more speed advantage you get. It
works great with standard Wireless-G and -B equipment, but when both ends of
the wireless link are Wireless-N, the throughput can be increased even more by
using twice as much radio band, yielding speeds up to 12 times as fast as
standard Wireless-G.
Once you're connected, you can surf the web, keep in touch with your e-mail, and
share files and other resources such as printers and network storage with other
computers on the network. To protect your data and privacy, your wireless
connection is secured by up to 256-bit encryption. The included Setup Wizard will
walk you through configuring the adapter to your network's settings, step by step.
The incredible speed of Wireless-N makes it ideal for media-centric applications
like streaming video, gaming, and Voice over IP telephony, and gives you plenty of
headroom to run multiple media-intense data streams through the network at the
same time, with no degradation in performance. So don't hassle with running
cables through your house — get your desktop connected the easy way with the
Linksys Wireless-N PCI Adapter.
High-speed Wireless-N (draft
802.11n) networking for your
desktop computer
MIMO technology uses multiple
radios to create a robust signal that
travels up to 4 times farther and
reduces dead spots
Up to 12 times faster than
Wireless-G, but can also connect to
Wireless-G and -B networks
Advanced wireless security with up
to 256-bit encryption

PCI Adapter
Wireless-N
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or trademark of
Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands and product names are
trademarks or registered trademarks of their respective holders.
Model WMP300N
WMP300N-DS-PSK-60425NC JL
Features
• Increases Range up to 4X, and Speed up to
12X, over Wireless-G (802.11g) Standard
• Performance Investment Protection:
Compatibility with Wireless-B (802.11b)
and Wireless-G (802.11g) Standards
• Easy-to-Use Setup Wizard
• Supports up to 256-bit wireless encryption
• 32-bit PCI Interface
• Plug-and-Play Operation Provides Easy
Setup
• Compatible with Microsoft Windows 2000
and XP
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]m
Web: http://www.linksys.com
Linksys products are available in more than
50 countries, supported by 12 Linksys Regional Offices
throughout the world. For a complete list of local
Linksys Sales and Technical Support contacts, visit our
Worldwide Web Site at www.linksys.com.
Minimum Requirements Package Contents
• 600 MHz or Faster PC
• 256 MB of RAM Memory
• CD-ROM Drive
• Available PCI Slot for Wireless-N PCI Adapter
• Windows 2000 or XP with Service Pack 1 (or later)
• Wireless-N PCI Adapter
• External Antenna
• Setup Wizard CD-ROM
•UserGuideonCD-ROM
• Quick Installation
Specifications
Model WMP300N
Standards IEEE 802.11b, IEEE 802.11g, Draft IEEE 802.11n, PCI 2.3
Channels 802.11b / 802.11g / Wireless-N (20MHz)
11 Channels (US, Canada)
13 Channels (Europe)
LED ACT
Protocols 802.11b: CCK, QPSK, BPSK
802.11g: OFDM
Wireless-N: BPSK, QPSK, 16-QAM, 64-QAM
Transmitted Power 802.11g: 12±1dBm (Typical); Wireless-N: 10±1dBm (Typical)
Receive Sensitivity 54Mbps @ -70dBm (Typical); Wireless-N @ -70dBm (Typical)
Security Features Up to 256-bit wireless encryption
Environmental
Dimensions 5.24" x 0.87" x 4.76" (133 x 22 x 121 mm)
Weight 2.19 oz. (0.062 kg)
Certification FCC
Operating Temp. 0ºC to 50ºC (32ºF to 122ºF)
Storage Temp. -25ºC to 70ºC (-13ºF to 158ºF)
Operating Humidity 10% to 80% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing
