Linksys NAS200 Operation manual

PRODUCT DATA
Easily add secure storage to
your network
Ethernet connected network
storage with two available SATA
hard drive bays adds shared
storage directly to your network
Add even more storage with two
USB 2.0 ports for hard drive or
ash USB storage devices
Securely share les locally or
through the Internet (FTP, HTTP)
with no dedicated PC needed
Advanced backup software
included
Built-in media server for streaming
to PC or UPnP AV digital media
adapter
Network Storage System with 2 Bays
Model: NAS200

PRODUCT DATA
Network Storage System with 2 Bays
Now you can quickly and easily add storage space onto your network with the Linksys
Network Storage System. This stand-alone network appliance features two available
SATA hard drive bays so you can attach as much storage as you need now, and add
more later as your storage needs grow. For even more expandability, there are two
USB ports that let you connect readily available USB 2.0 hard drives for even more
storage space—or plug in a USB ash disk for a convenient way of accessing your
portable data les.
Connecting the Storage System to your network is simple—just plug it directly into
an available 10/100 Ethernet port on your router or switch, and the storage is instantly
accessible by your whole network.
The Network Storage System features built-in one-touch backup—just push the
button to start a backup of your important les. There are other built-in disk utilities,
accessible through your web browser. You can run a self test or scan the disk(s) for
errors. If you’ve installed a second disk drive, you can back up one drive to the other,
either manually or on a schedule.
For even more exibility and utility, the Network Storage System can be set up to be
accessible directly from the Internet via a web browser or FTP. Files can be available
publicly, or create password-protected accounts for your authorized users.
The Linksys Network Storage System is the expandable and accessible storage solution
for your network.
Features
Provides 2 bays with SATA
interface, easy installation and
removal
Provides 2 USB ports, supports
USB memory devices such as
ash disk or USB hard drive
Flexible disk conguration:
1) combine 2 drives to be seen
as one, 2) disk-to-disk mirroring,
3) striping, or just 4) two
separate drives
Share storage with PCs
connected to the network
Push button for data backup
The built-in download manager
enables users to initiate an FTP
or HTTP download task from
a PC’s web browser. Once the
task is initiated, the PC may
be turned o, and the NAS200
will continue the download
independently.
•
•
•
•
•
•

PRODUCT DATA
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]
Web: www.linksys.com
Linksys products are available in more than
50 countries, supported by 12 Linksys Regional
Oces throughout the world. For a complete
list of local Linksys Sales and Technical Support
contacts, visit our worldwide website at
www.linksys.com
Check the product package and contents for specic features supported. Specications are subject to change without notice. Linksys is a registered
trademark or trademark of Cisco Systems, Inc. and/or its aliates in the U.S. and certain other countries. Copyright © 2007 Cisco Systems, Inc.
All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
7070610NC-JL Model: NAS200
Network Storage System with 2 Bays
Specications
Model NAS200
Standards IEEE 802.3, IEEE 802.3u
Ports Power, Ethernet, USB 1, USB 2
Buttons Power, USB 1, USB 2, RESET, BACK UP
LEDs Power, Ethernet, Disk (Act, Full, 1, 2), USB 1, USB 2
Cabling Type UTP CAT5 or Better
Security Features User Name and Password for Both System
Administration and File Access
Environmental
Dimensions 6.69" x 4.49" x 7.60" (170 x 114 x 193 mm)
Weight 1.97 lb (839 g)
Power 12V DC, 5A, Switching, 100-240V AC, 50-60 Hz,
Power Adapter Provided
Certication FCC, CE
Operating Temperature 41 to 104ºF (5 to 40ºC)
Storage Temperature 14 to 140ºF (-10 to 60ºC)
Operating Humidity 10 to 80%, Noncondensing
Storage Humidity 5 to 90%, Noncondensing
Package Contents
Network Storage System with 2 Bays
Setup CD-ROM
User Guide on CD-ROM
Quick Installation
Ethernet Network Cable
Power Adapter with Power Cord
Minimum Requirements
Windows 2000 or XP
CD-ROM Drive
Internet Explorer 5.5 or Firefox 1.0
Network Adapter
•
•
•
•
•
•
•
•
•
•
